3. DISASSEMBLY

WARNING
Excessive Weight Hazard:
Use two or more people to remove and install the
refrigerator doors. Failure to do so can result in back or
other injury.
TOOLS NEEDED
‡  PP RU  LQFK VRFNHW ZUHQFK ZLWK  LQFK H[WHQVLRQ
for bottom door hinge).
‡ 1R  3KLOOLSV KHDG VFUHZGULYHU
‡ )ODWKHDG VFUHZGULYHU IRU SU\LQJ
‡ $GMXVWDEOH ZUHQFK

REMOVING THE FREEZER DOOR

Remove the top-hinge cover by gently prying it with a flat
head screwdriver.
Fig. 1
8VLQJ HLWKHU D  PP RU  LQFK VRFNHW ZUHQFK UHPRYH
the three bolts and lift off the top hinge. Set parts aside.
Fig. 2
Carefully lift up the freezer door. Place the door on a non-
scratching surface.
Middle Hinge Bracket
Fig. 3
Hinge Pin
Electrical Shock Hazard
‡ 'LVFRQQHFW WKH HOHFWULFDO VXSSO\ WR WKH UHIULJHUDWRU
before installing. Failure to do so could result in serious
injury or death.
‡ 'R QRW SXW KDQGV IHHW RU RWKHU REMHFWV LQWR WKH DLU YHQWV
EDVH JULOOH RU ERWWRP RI WKH UHIULJHUDWRU <RX PD\ EH
injured or receive an electrical shock.

REMOVING THE REFRIGERATOR DOOR

Loosen and remove the two bolts using a phillips head
screwdriver.
Fig. 4
Remove the middle hinge bracket.
Fig. 5
Carefully lift up the door. Place the door on a non scratching
surface.
Fig. 6
- 5 -
WARNING
Middle
Hinge Bracket
