LG LTCS24223B /04 Service Manual page 36

CONTENTS
1. PCB Picture
1) Main PCB
2) Display PCB
3) LED Lighting
2. Troubleshooting
1) RT Sensor Error
2) Refrigerator Sensor Error
3) Defrost Sensor Error
4) Defrost Error
5) Water Dispenser not working
6) Freezer Room LED Module doesn't work
7) Refrigerator Room LED Module doesn't work
8) Poor cooling in Refrigerator room
9) Over cooling in Refrigerator room
10) Freezer BLDC FAN Motor Error
11) Cooling BLDC FAN Motor Error
3. Reference
1) Temperature compensation
2) TEST MODE and Removing TPA
3) TEMPERATURE CHART - REF AND DEFROST SENSOR
4) TEMPERATURE CHART - RT SENSOR
- 36 -
