  • Page 1: User Manual

    HSP500 Wireless HotSpot Gateway with Printer HSP500 Wireless HotSpot Gateway with Printer User Manual...
  • Page 2 HSP500 Wireless HotSpot Gateway with Printer Copyright Notice Copyright © 2013-2022 Xentino Technologies Inc. All rights reserved. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission. Disclaimer We shall not be liable for technical or editorial errors or omissions contained herein;...

  • Page 3: Table Of Contents

    HSP500 Wireless HotSpot Gateway with Printer Contents Introduction ......................4 Package Contents ................... 5 Features ....................5 Precautions .................... 6 Outlook ....................6 1-4-1 Printing a test page ................0 1-4-2 How to load paper rolls ..............0 Technical Specifications ................. 1 1-5-1 Hardware Specifications ..............
  • Page 4 HSP500 Wireless HotSpot Gateway with Printer 3-2-2-3 Credit Card................21 3-2-3 Management .................. 25 3-2-3-1 Syslog ..................25 3-2-3-2 Session Trace ................ 33 3-2-3-3 Bandwidth ................35 3-2-3-4 SNMP ..................36 3-2-4 Security ................... 37 3-2-4-1 Pass Through ................ 37 3-2-4-2 Filtering ................

  • Page 5: Introduction

    It’s completely Plug’ Play with any browser. The HSP500 provides QR code service. You can install any QR code APP to your mobile device, and then scan QR code on the ticket to get access of the Internet! You...

  • Page 6: Package Contents

    HSP500 Wireless HotSpot Gateway with Printer 1-1 Package Contents Please inspect your package. The following items should be included: HSP500  One HSP500  One Thermal papers (50 meter)  One Power Adapter  One Ethernet Cable (1.5 meter) ...

  • Page 7: Precautions

    Use only the original fitting AC power adapter otherwise there is a danger of severe electrical shock.  Avoid exposing the HSP500 to direct sunlight or another heat source.  Choose a well-ventilated area to position your HSP500. 1-4 Outlook...
  • Page 8 Yellow Blinking: 10/100 Mbps traffic is traversing the port.  Reset Button: The HSP500 has a reset button at the rear panel of the device. Use this function to reset the system back to factory defaults.  Power Jack: Used to connect the external power supply with the HSP500.

  • Page 9: Printing A Test Page

    HSP500 Wireless HotSpot Gateway with Printer 1-4-1 Printing a test page After you have installed your printer, you should print a test page to make sure the printer is functioning properly. To do this act as follows: 1. Turn the printer off.

  • Page 10: Technical Specifications

    HSP500 Wireless HotSpot Gateway with Printer 1-5 Technical Specifications 1-5-1 Hardware Specifications Network Specification  IEEE802.3 10BaseT Ethernet  IEEE802.3u 100BaseTX Fast Ethernet  IEEE802.11b/g/n Wireless LAN  ANSI/IEEE 802.3 NWay auto-negotiation  Wi-Fi Compatible Connectors  One WAN Port (10BaseT/100BaseTX Auto cross-over) ...

  • Page 11: Software Specifications

    HSP500 Wireless HotSpot Gateway with Printer  Operating Humidity: 20~80% non-condensing  Storage Humidity: 20% to 90% non-condensing Certifications  FCC part 15 Class B, CE , C-Tick , VCCI Dimension  Size: 109×155×90 (W×D×H )mm  Weight: About 340g (Net) Printer Tray ...
  • Page 12 HSP500 Wireless HotSpot Gateway with Printer  HTTP Proxy Support  WEP64/128bit  WPA-PSK (TKIP)  WPA2-PSK(AES)  WPA/WPA2 Mix mode  SMTP Server Redirection  DHCP Server(RFC 2131)  DHCP Relay(RFC 1542)  Static IP WAN Client  DHCP WAN Client ...
  • Page 13 HSP500 Wireless HotSpot Gateway with Printer  Pass Through IP/MAC/URL Address  Restricted Destination Filtering IP/URL  VPN (IPSec/PPTP) Pass through  PPTP VPN Client    WPA2  WPA/WPA2 Mix mode Management  Web-based Management Tool  Firmware Upgrade via HTTP/TFTP ...

  • Page 14: Installation

    HSP500 Wireless HotSpot Gateway with Printer 2 Installation 2-1 Connecting the Antennas The HSP500 provides two antenna connectors on the rear of the unit. 2-2 Installation Requirements Before installing the HSP500, make sure your network meets the following requirements. System Requirements The HSP500 requires one of the following types of software: ...
  • Page 15 2. The gateway’s default subnet mask setting is “255.255.255.0”. The Dynamic IP settings for the PC We recommend that you leave your IP settings as automatically assigned. By default, the HSP500 is a DHCP server, and it will give your PC the necessary IP settings.

  • Page 16: Getting Start

    HSP500 Wireless HotSpot Gateway with Printer 2-3 Getting Start HSP500 Connection 1. Connect the DC power adapter to the HSP500 and plug it into a power socket. 2. Connect HSP500 and xDSL modem with an Ethernet Cable.
  • Page 17 HSP500 Wireless HotSpot Gateway with Printer Configure TCP/IP of your computer For Windows user, 1. Click Start > Control Panel, click Switch to Classic View and double click on Network Connections. 2. Right click on the Local Area Connection and click Properties.

  • Page 18: Configuring The Hsp500

    Press Enter. Figure 3-1-1 Web Browser Location Field (Factory Default) Step 3: The HSP500 configuration tools menu will appear. In the Username and Password field, type the factory default user name admin and password admin and click Login.
  • Page 19 HSP500 Wireless HotSpot Gateway with Printer DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP. If your xDSL/Cable comes with this feature, please enable Use DHCP Client.
  • Page 20 HSP500 Wireless HotSpot Gateway with Printer Static IP Setting If Static IP Setting is selected, then this screen will appear. Enter the IP address information provided by your ISP. Figure 3-1-4 Internet Connection Setting Screen—Static IP Setting Item Default Description 0.0.0.0...
  • Page 21 64 alphanumeric characters and is case sensitive. Connect on Demand and Max Idle Time Connect on You can configure your HSP500 to cut your connection with your ISP after a Enable Demand specified period of time (Max Idle Time). If you have been disconnected due...
  • Page 22 HSP500 Wireless HotSpot Gateway with Printer Keep alive and Redial Period This option keeps your PPPoE enabled Internet access connected Keep alive Disable indefinitely, even when it sits idle. The Redial Period maximum value is 65535 30 Seconds Redial Period seconds.
  • Page 23 Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your HSP500 to cut your connection with your ISP after a specified period of time (Max Idle Max Idle Time Time). If you have been disconnected due to inactivity, Connect on Demand...
  • Page 24 HSP500 Wireless HotSpot Gateway with Printer Step 5: Wireless Setting This page allows you to choose Country, Channel ID and 802.11 Mode for wireless connection. Figure 3-1-7 Wireless Setting Screen Item Default Description Country ETSI Enter the Country for wireless connection.
  • Page 25 HSP500 Wireless HotSpot Gateway with Printer Step 6: Authentication Setting This page allows you to choose whether the users need to be authenticated before the Internet access. If users need the account and password to get access of Wi-Fi, please choose Yes.
  • Page 26 HSP500 Wireless HotSpot Gateway with Printer Step 7: Billing Profile Setting This page allows you to set your service and price plan. If you would like to provide “FREE” Wi-Fi for users, please activate “No Billing Mode” the price and the tax won’t be showed on the ticket.
  • Page 27 HSP500 Wireless HotSpot Gateway with Printer Item Default Description If you would like to provide FREE Wi-Fi for users, please activate“No No Billing Mode Disabled Billing Mode”the price and the tax won’t be showed on the ticket. Currency The administrator can decide the currency printed out on the ticket.
  • Page 28 HSP500 Wireless HotSpot Gateway with Printer Step 8: Accounting Setting Following the Billing Profile Setting, the page allows to set the billing profiles for each button of the printer. Figure 3-1-11 Accounting Setting Item Default Description Setting Button A/Button B/Button C You could choose the billing profile via the dropdown list for each button on the printer.
  • Page 29 HSP500 Wireless HotSpot Gateway with Printer Step 9: Firmware Upgrade Notice Setting If you would like to receive the information about firmware upgrade, please activate it and leave your email. Figure 3-1-12 Firmware Upgrade Notice Setting...
  • Page 30 HSP500 Wireless HotSpot Gateway with Printer Step 10: System Setting System Setting: The HSP500 allows changing the administrator’s Username and Password, and system time setting. Figure 3-1-13 System Setting Screen Item Default Description Username admin Enter the user name. The user name can consist of up to 80 alphanumeric characters and is case sensitive.
  • Page 31 2. Username and Password can consist of up to 20 alphanumeric characters and are case sensitive. 3. If for some reason your password is lost or you cannot gain access to the HSP500 Configuration Program, please press the reset button to load the device to manufacturer defaults.

  • Page 32: Advanced Setup

    HSP500 Wireless HotSpot Gateway with Printer 3-2 Advanced Setup The Advanced Setting enables you to configure advanced settings related to accessing the Internet, including, AUTHENTICATION  AUTHENTICATION  RADIUS BILLING  BILLING  ACCOUNTING  CREDIT CARD MANAGEMENT  SYSLOG ...

  • Page 33: Authentication

    HSP500 Wireless HotSpot Gateway with Printer 3-2-1 Authentication 3-2-1-1 Authentication Figure 3-2-2 Authentication Item Default Description Authentication Type Built-in Option: No Authentication, Built-in Authentication or Authentication User Agreement. No Authentication Subscriber can direct access the Internet without enter username and password.

  • Page 34: Security

    HSP500 Wireless HotSpot Gateway with Printer Internet crime investigation. If you would like to activate PIR function, please refer to Chapter 5 Personal ID Recognition. The default is Disable. User Agreement Subscriber must accept the service usage agreement before they can access the Internet.

  • Page 35: Radius

    Subscriber can direct access the Internet without entering username and password. Enable (RADIUS Authentication) HSP500 provides “RADIUS Authentication” for service provider to build up an Internet service with RADIUS server. If RADIUS Authentication is enabled, all subscribers’ authentication will send to RADIUS Server by RADIUS protocol (RFC 2865, 2866).
  • Page 36 HSP500 Wireless HotSpot Gateway with Printer match with the RADIUS server setting. The allowed numbers are from 0 to 65535. Share Secret Key Empty The share secret key, the key number also has to match with the Server setting. Up to 64 characters are allowed.

  • Page 37: Billing

    HSP500 Wireless HotSpot Gateway with Printer 3-2-2 Billing 3-2-2-1 Billing The function is used to setup a billing profile. A billing profile is a description of how you want to charge your customer. Figure 3-2-5 Billing Setting Screen...

  • Page 38: System

    HSP500 Wireless HotSpot Gateway with Printer Item Default Description Enable Credit Card Service Disable Enables or disables the credit card service. Before you enable credit card service, make sure that your credit service is configured to work and the currency is American dollars. You must be converting all prices on your billing page into American dollars (U.S.
  • Page 39 HSP500 Wireless HotSpot Gateway with Printer Figure 3-2-6 Accumulation and Time to Finish Figure 3-2-7 Pre-paid Procedure Diagram...

  • Page 40: Accounting

    HSP500 Wireless HotSpot Gateway with Printer 3-2-2-2 Accounting This function allow service provider to generate the subscriber accounts. Figure 3-2-8 Accounting Setting Screen Item Default Description Expiration Un-used account will be deleted 24 hours Enter the number of hours/minutes/days. The field maximum after ~hours automatically value is 30 hours/minutes/days.
  • Page 41 The gratuitous usage amount of “free Trial” is on a periodic Reset Time 00:00 time basis. The “Reset Time” defines the periodic cycle time. Based on the configuration, HSP500 grants users the gratuitous usage amount (time or volume) on each periodic cycle time.
  • Page 42 HSP500 Wireless HotSpot Gateway with Printer Figure 3-2-10 Account Process Diagram Can be topped up by subscriber=Enable Item Default Description Define each button’s billing profile. Select one billing profile Button A~C by clicking in the list box. Use ~ for Discount...
  • Page 43 HSP500 Wireless HotSpot Gateway with Printer  Discount Price Plan based on “Button Presses” is enabled.  The Charge by level is disabled. Figure 3-2-12 Example 2 Amount: 7 x $ 1 = $ 7.00  Discount Price Plan based on “Button Presses” is enabled.
  • Page 44 HSP500 Wireless HotSpot Gateway with Printer Amount: 2 x $2.00 + 4 x$ 1.50+1x$1= $11.00  Discount Price Plan based on “Button Presses” Figure 3-2-14 Discount Price Plan Setting Screen Item Default Description Charge by levels Enable Enables or disables the charge by levels function.
  • Page 45 HSP500 Wireless HotSpot Gateway with Printer 3-2-2-3 Credit Card HSP500 provides three credit card services (Authorize.net, iValidate.net, Secure Pay, Paypal and WorldPay) that allow service provider to authorize, process, and manage credit transactions directly from Internet. Figure 3-2-15 Credit Card Setting Screen...

  • Page 46: Server

    HSP500 Wireless HotSpot Gateway with Printer Item Default Description Authorize.net Version This field displays the merchant version. Merchant ID Empty Enter your Merchant ID. This is a Merchant Identification Number that you’re received from your Merchant Provider. The maximum character of the Merchant ID is 50.
  • Page 47 HSP500 Wireless HotSpot Gateway with Printer Item Default Description Secure Pay Merchant ID Empty Enter your Merchant ID. This is a Merchant Identification Number that you’re received from your Merchant Provider. The maximum character of the Merchant ID is 7.
  • Page 48 HSP500 Wireless HotSpot Gateway with Printer Item Default Description Credit Card icons to be Click on check box to display credit card icon on the login displayed on the login page page. Click Apply button to save the new settings and the success dialog box appears. Click on Back to return to Accounting setting screen.

  • Page 49: Syslog Setting

    Send to Syslog Server Disable Enables or disables the syslog server function. Syslog on LAN Enter syslog server’s IP address. The HSP500 will send all of its Server IP Address Empty logs to the specified syslog server. Enter the syslog server’s MAC address. The HSP500 will send all of...

  • Page 50: Portal

    HSP500 Wireless HotSpot Gateway with Printer Item Default Description Syslog on WAN Server 1 IP Address Empty Enter IP address of first syslog server. Server 2 IP Address Empty Enter IP address of second syslog server. Send to Email Disable Enables or disables the send to e-mail function.
