Alpha Modular Switched Mode Rectifier System
Rectifier Models: Cordex CXRF 48-3.6kW
Cordex HP CXRF 48-4kW
Cordex HP CXRF 48-12kW
Installation and Operation Manual
Part #9400000-J0
Effective 12/2012
Your Power Solutions Partner
member of The
Group
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC-H476 and is the answer not in the manual?

Questions and answers

Related Manuals for Speech Technology Center STC-H476

Summary of Contents for Speech Technology Center STC-H476

  • Page 1 Alpha Modular Switched Mode Rectifier System Rectifier Models: Cordex CXRF 48-3.6kW Cordex HP CXRF 48-4kW Cordex HP CXRF 48-12kW Installation and Operation Manual Part #9400000-J0 Effective 12/2012 Your Power Solutions Partner member of The Group ™...
  • Page 3 Modular Switched Mode Rectifier System Models: Cordex CXRF HP 48-12kW Cordex CXRF HP 48-4.0kW Cordex CXRF 48-3.6kW NOTE: Photographs contained in this manual are for illustrative purposes only. These photo- graphs may not match your installation. NOTE: Operator is cautioned to review the drawings and illustrations contained in this manual before proceeding.

  • Page 4: Table Of Contents

    Table of Contents 1. Safety ............................5 1.1 Safety Symbols .......................... 5 1.2 General Safety ........................... 5 1.3 Mechanical Safety ........................5 1.4 Electrical Safety ......................... 6 1.5 Battery Safety ..........................6 2. Introduction ...........................7 2.1 Scope of the Manual ........................7 2.2 Product Overview ........................
  • Page 5 4.6 Alarm and Control Output Relays .................... 17 4.7 System Fail Alarm/Relay ......................17 5. Inspection..........................18 5.1 Packing Materials ........................18 5.2 Check for Damage ........................18 5.3 General Receipt of Shipment ....................18 6. Installation ...........................19 6.1 Safety Precautions ........................19 6.2 Tools Required .........................
  • Page 6 10.4 Fan and Fan Filter Replacement ................... 33 10.5 MOV Replacement ......................... 37 11. Acronyms and Definitions ....................41 12. Warranty and Service Information ..................42 12.1 Technical Support ........................42 12.2 Warranty ..........................42 12.3 Battery Warranty ........................42 12.4 Return of Material ........................42 List of Figures Figure 1 —...

  • Page 7: Safety

    1. Safety SAVE THESE INSTRUCTIONS: This manual contains important safety instructions that must be followed during the installation, servicing, and maintenance of the product. Keep it in a safe place. Re- view the drawings and illustrations contained in this manual before proceeding. If there are any questions regard- ing the safe installation or operation of this product, contact Alpha Technologies or the nearest Alpha representa- tive.

  • Page 8: Electrical Safety

    1.4 Electrical Safety WARNING! Hazardous voltages are present at the input of power systems. The DC output from rec- tifiers and batteries, though not dangerous in voltage, has a high short-circuit current capacity that may cause severe burns and electrical arcing. •...

  • Page 9: Introduction

    2. Introduction 2.1 Scope of the Manual This instruction manual explains the installation, interconnection, and operation of the Alpha Cordex 48-3.6kW, 48-4.0kW and 48-12kW modular switched mode rectifier systems. 2.2 Product Overview A complete Cordex rectifier system consists of one or more power modules in a common shelf enclosure. The shelf has connections for AC inputs, DC output, and system communications.

  • Page 10: Part Numbers And List Options

    2.3 Part Numbers and List Options The product, options, and accessories can be ordered by using the following part numbers: Description List Option Cordex 48-12kW rectifier power module 0100002-002 Basic module *List 0 Fan, spare for Cordex 48-12kW 747-679-20 Fan filter, spare for Cordex 48-12kW 747-652-20-060 MOV assembly, spare for Cordex 48-12kWt 707-813-20...
  • Page 11 Description List Option Kydex rear cover List 89 Module blank List 90 CXCM4 Cordex Controller, Modular, 4RU, takes the space of one rectifier (pre-RoHS # 018-574-20) 018-586-20 Basic unit *List 0 48 V system [requires a connection interface (747-271-20) for modular installation] List 2 Standard temperature (0 to 65ºC) List 40...

  • Page 12: Rectifier Features

    3. Rectifier Features 3.1 Front Panel The three LEDs on the rectifier front panel indicate status: • AC ON (1) • DC ON (2) • Alarm (3) LEDs LEDs Thumbscrew 3.6kW LEDs LEDs LEDs Thumbscrews Figure 2 — Rectifier front panel LEDs 9400000-J0 Rev C...
  • Page 13 3.1.1 Rectifier LEDs The front panel LEDs indicate: • Rectifier status summary • Rectifier software upgrade in progress • Patterned response to Locate Module command The rectifier status summary shows the rectifier alarm status, communication fail status, and rectifier on/off status. AC ON (1) The green LED is illuminated when the AC input voltage is within its allowable range.

  • Page 14: Rectifier Rear Panel

    3.2 Rectifier Rear Panel A single connector for shelf power and communications is located on the rear panel of each rectifier. The 12kW rectifier has three connectors. 3.3 True Module Fail Alarm The power modules have a “true” fail alarm that provides a true indication of the power module’s ability to source current.

  • Page 15: Ac Inrush/Transient Suppression

    3.7 AC Inrush/Transient Suppression To prevent a surge on the AC inout line, the inrush current of a rectifier module is limited to the full load steady state line current. Modules are also protected from input lightning and transient surges in accordance with IEEE/ ANSI C62.41 Category B3 standards.

  • Page 16: Cordex System Controller (Cxc)

    4. Cordex System Controller (CXC) 4.1 CXCM4 Features The CXCM4 (Cordex Controller, Modular, 4RU) is mounted in the rectifier system shelf and brings advanced monitoring technology to the Cordex series of rectifiers. This compact system controller is designed for seamless operation and set up for Alpha power systems.

  • Page 17: Reset Button

    LEDs The three LEDs, located on the CXCM4 front panel, display the alarm status of the power system, CXCM4 prog- ress and status during startup, and file transfers. Alarm Conditions The CXCM4 illuminates the LED that corresponds to the system alarm status. Each LED color corre- sponds to a specific alarm status (only one LED is illuminated at a time during alarm conditions.) OK, no alarms present.

  • Page 18: Rectifier Report From Controller Display

    4.3 Rectifier Report from Controller Display To display the installed rectifiers and their status, logon through the controller interface. From the , select to generate the report screen for all acquired modules in Main Menu Rectifiers > Rectifier Report the system (Figure 4). Tapping on a rectifier in the screen generates a command that causes the Rectifier Locate rectifier's LEDs to flash briefly.

  • Page 19: Digital Input Channels

    4.5 Digital Input Channels The CXCM4 can accommodate up to four channels and can monitor digital alarm/control signals from rectifiers, converters, and other types of equipment. 4.6 Alarm and Control Output Relays The CXCM4 contains eight Form-C digital alarm output relays that are used to extend alarms and to control external apparatus.

  • Page 20: Inspection

    5. Inspection 5.1 Packing Materials All Alpha products are shipped in rugged, double walled boxes and suspended via solid inserts to minimize shock that may occur during transportation. Packaging assemblies and methods are tested to International Safe Transit Association standards. Rectifiers and batteries are shipped on individual pallets and are packaged according to the manufacturer’s guidelines.

  • Page 21: Installation

    6. Installation The equipment is suitable for installation in Network Telecommunication Facilities. WARNING! This system is designed to be installed in a restricted access location that is inacces- sible to the general public. The following procedure is written for qualified personnel to install this product in a clean and dry environment. For the battery installation, refer primarily to the manufacturer’s manual.

  • Page 22: Power System Assembly And Mounting

    6.3 Power System Assembly and Mounting 6.3.1 Shelf Preparation/Mounting NOTE: Mount the shelf in a clean and dry environment. Allow at least 1.75” of free space in front of the unit for unrestricted cooling airflow. Sufficient free space must be provided at the front and rear of the power system.

  • Page 23: Wiring

    7. Wiring This chapter provides cabling details and notes on cable sizing for DC applications using the Cordex 48-3.6kW, 4.0kW and 12kW modular switched mode rectifier systems. Refer to the Safety section on page 5 for safety precautions. WARNING! Ensure that the power at the AC service panel is off is switched off. Remove battery line fuses or connections before attempting work on the wiring.

  • Page 24: Dc Output Connections

    7.3 AC Input Connections CAUTION! To minimize EMI disturbances, route the AC input wires in flexible or rigid conduit and located as far away as possible from the DC power wires. WARNING! Use care when removing or replacing the covers for the AC input connections. Never assume that an electrical connection or conductor is not energized.

  • Page 25: Can Serial Ports (Rectifier Shelf)

    7.5 CAN Serial Ports (Rectifier Shelf) Two CAN Serial ports (modular jacks with offset latches), are provided for communications with Alpha’ Cordex rectifiers and other CAN-enabled equipment. These are located on the left side of the rectifier shelf as viewed from the front.

  • Page 26: Inserting The Cxcm4 Module

    7.6 Inserting the CXCM4 Module NOTE: Do not force a module into position if it does not seat properly. All modules are keyed to ensure that the correct module (voltage/polarity) type is used. 1. Insert by placing the controller on the shelf bottom and sliding the module into the CXCM4 connection interface (inside of the shelf, see drawing 747-271-08).

  • Page 27: Figure 7 - Digital Input Connection Method

    7.7.2 Digital Inputs The digital input channels are used to monitor various alarm and control signals. All input channels are voltage activated and accept a bipolar (negative or positive) DC signal directly. Connection Method Typical Alpha systems use the “reset with Hot and trigger with Ground” connection. The digital input is wired in such a way that the Hot is wired directly into one of the input terminals.

  • Page 28: Network Connection And Remote Communications Via Cxc

    Voltage Input #2 (battery voltage per CXC software) is wired internally (V2) to the rectifier output voltage of the shelf. This is used as the reference for system alarming (such as high voltage) and control (such as low voltage disconnect). Temperature Sensing Temperature Probe input channels provide connections for temperature sensors.

  • Page 29: System Startup

    8. System Startup Visually inspect the installation thoroughly. After completing the system installation and power system wiring, perform the following startup and test proce- dure to ensure proper operation: 8.1 Check System Connections 1. Make sure that the AC input power is switched off, the batteries are disconnected, and all the power modules are removed from the shelf.

  • Page 30: Rectifier States, Modes And Factory Defaults

    9. Rectifier States, Modes and Factory Defaults 9.1 Main Rectifier States The rectifier operation can be broken up into five main states: 1. Off. 2. Start delay. 3. Soft start. 4. Normal operation. 5. Switching off. Each state is characterized as being distinct and necessary for the operation of the rectifier. These states are briefly described below.

  • Page 31: Main Rectifier Modes

    9.2 Main Rectifier Modes In addition to the main rectifier states, there is a set of main rectifier modes. These modes can be divided into two categories, the output voltage mode and the output current/power mode. 9.2.1 Output Voltage Modes Voltage modes can be thought of as modes that, under software control, can directly adjust the output voltage.

  • Page 32: Factory Ranges And Defaults

    9.3 Factory Ranges and Defaults Table D shows the rectifier settings/ranges/defaults. Changes are made through the CXC interface. Table D — Rectifier factory ranges and defaults Setting Range (minimum to maximum) Default Float (FL) Voltage 47.5 – 58.2 V 54 V Equalize (EQ) Voltage 49.8 –...

  • Page 33: Maintenance

    10. Maintenance Although very little maintenance is required with Alpha systems, routine checks and adjustments are recom- mended to ensure optimum system performance. Qualified service personnel should do the repairs. The following table lists a few maintenance procedures for this system. These procedures should be performed at least once a year.

  • Page 34: Replacing The Cxcm4 Module

    10.3 Replacing the CXCM4 Module WARNING! Before removing a CXCM4 from a live system, an external LVD override is required to avoid a disruption of service. Figure 8 — LVD override control and distribution alarm card The LVD Control functions can be hardwired directly from the assigned relay output to an optional LVD override control and distribution alarm card (707-307-20).

  • Page 35: Fan And Fan Filter Replacement

    10.4 Fan and Fan Filter Replacement 10.4.1 4.0kW Rectifier Fan and Filter Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement fan assembly and filter. Top screw (1) Front panel Side screws (2) 1.

  • Page 36: Figure 9 - 4Kw Rectifier Fan Removal

    4. Disconnect the fan cables from the module by pulling out the fan cable connector. 5. Remove the two screws that secure the fan to the front panel. 6. Note the direction of the airflow and remove the fan from the front panel. Fan screws Figure 9 —...

  • Page 37: Figure 11 - Fan Assembly - Screw Removal

    10.4.2 12kW Rectifier Fan Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement fan. 1. Switch off the unit and unscrew the front fastener that secures the power module to the shelf. 2.
  • Page 38 10.4.3 3.6kW Rectifier Fan or Filter Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement fan. 1. Shut off the unit and unscrew the front fastener that secures the power module to the shelf. 2.

  • Page 39: Mov Replacement

    10.5 MOV Replacement 10.5.1 4.0kW Rectifier MOV Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement MOV. The MOVs (metal oxide varistor) are used to protect the power modules from power line surges and surges caused by lightning strikes.
  • Page 40 4. Remove the cover and find the MOV printed circuit board (PCB). Insulating mat MOV PCB screws 5. Fold the insulating mat out of the way and remove the three screws that secure the MOV PCB to the module. MOV PCB 6.
  • Page 41 10.5.2 12kW Rectifier MOV Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement MOV. The MOVs (metal oxide varistor) are used to protect the power modules from power line surges and surges caused by lightning strikes.
  • Page 42 10.5.3 3.6kW Rectifier MOV Replacement Refer to "2.3 Part Numbers and List Options" on page 8 for the part number of the replacement MOV. The MOVs (metal oxide varistor) are used to protect the power modules from power line surges and the surges caused by lightning strikes.

  • Page 43: Acronyms And Definitions

    11. Acronyms and Definitions Alternating current ANSI American National Standards Institute American Wire Gauge British thermal unit Controller area network Canadian Electrical Code Canadian Standards Association Cordex™ series; e.g., CXC for Cordex System Controller Direct current DHCP Dynamic Host Configuration Protocol Electronic Industries Alliance Electromagnetic compatibility Electromagnetic interference...

  • Page 44: Warranty And Service Information

    12. Warranty and Service Information 12.1 Technical Support Free Technical Support 24/7/365 is part of the Alpha customer satisfaction commitment. The phone numbers below can also be used to access a wide range of service solutions both at your premise and at the Alpha facility nearest you.
  • Page 45 Specifications for Alpha Switched Mode Rectifier Cordex 48-4kW Power Module Output Voltage: 44 to 60 Vdc within rated limits Current: 74 A @ 54 Vdc nominal (83 A maximum @ 48 V) Maximum Power: 4000 W continuous/module Static Load Regulation: Better than ±0.5% for any load change within rated limits Dynamic Load Regulation: Better than ±2% for 40% - 90% load step...
  • Page 46 Specifications for Alpha Switched Mode Rectifier Cordex 4kW Power Module Input Voltage: 208, 220, 230, 240, 277 Vac nominal Operational Range: 187 to 320 Vac Extended Operation: Low: 187 to 90 Vac (derated power) Frequency: 45 to 66 Hz Current: 17.5 A @ 240 Vac 21.5 A @ 208 Vac 23.5 A @ 176 Vac (maximum)
  • Page 47 Specifications for Alpha Switched Mode Rectifier Cordex 4kW Weight: Module: 3.9 kg (8.6 lb) 23" Shelf: 14.5 kg (32 lb) 19" Shelf: 12.7 kg (28 lb) Safety EN 60950-1: 2006 Rectifier output shall be rated SELV suitable for connection to TNV-1 circuits 60950-1: 2 C22.2 No.
  • Page 48 Specifications for Alpha Switched Mode Rectifier Cordex 48-12kW Power Module Output Voltage: 44 to 60 Vdc within rated limits Current: 222 A @ 54 Vdc nominal (249 A maximum @ 48 V) Maximum Power: 12kW continuous/module Static Load Regulation: Better than ±0.5% for any load change within rated limits, under control of Cordex Controller Dynamic Load Regulation: Better than ±2% for 40% - 90% load step...
  • Page 49 Specifications for Alpha Switched Mode Rectifier Cordex 48-12kW Power Module Input Voltage: 208-240 Vac (3Φ – 3 Wire + PE) Nominal 360-480Vac (3Φ – 3 Wire + N + PE) Nominal 208-277Vac (1Φ) Nominal Operational Range: 187 to 320 Vac (Per Connector AC Input on Module) Extended Operation: Low: 187 to 95 Vac (Per Connector AC Input on Module, Derated Power) Frequency:...
  • Page 50 Specifications for Alpha Switched Mode Rectifier Cordex 48-12kW Dimensions (inches): W10.3 x H6.25 x D11.8 (W10.3 x H7 x D14.38 including front panel and handle) Dimensions (mm): W261 x H160 x D300 (W261 x H177 x D365 including front panel and handle) Weight: Module: 12 kg (27 lb) 23"...
  • Page 51 Specifications for Alpha Switched Mode Rectifier Cordex 48-3.6kW Power Module Output Voltage: 42 to 60Vdc within rated limits Current: 66.5A @ 54Vdc nominal (75A maximum @ 48V) Maximum Power: 3600W continuous/module Static Load Regulation: Better than ±0.5% for any load change within rated limits Dynamic Load Regulation: Better than ±2% for 40% - 90% load step (output shall recover to static limits within 30ms)
  • Page 52 Specifications for Alpha Switched Mode Rectifier Cordex 48-3.6kW Continued Power Module Input Voltage: 208, 220, 230, 240, 277Vac nominal Operational Range: 176 to 320Vac Extended Operation: Low: 176 to 90Vac (derated power) Frequency: 45 to 66Hz Current: 16.8A @ 240Vac 19.4A @ 208Vac 22.8A @ 176Vac (maximum) Recommended Feeder Breaker...
  • Page 53 Specifications for Alpha Switched Mode Rectifier Cordex 48-3.6kW Continued Weight: Module: 4.6 kg (10.1 lb.) 23” Shelf: 14.5 kg (32 lb.) 19” Shelf: 12.7 kg (28 lb.) Safety EN 60950-1: 2006 Rectifier output shall be rated SELV suitable for connection to TNV-1 circuits 60950-1: 2 C22.2 No.
  • Page 54 REVISIONS LIST 89 - KYDEX REAR COVER REV BY DESCRIPTION DATE APPD CORRECTED NO. OF MODULES E O F 2004/06 INCORPORATED E.O.'S A1-9 J.U. 2005/02 LIST 81 UPDATED MP/JU 2005/10 16.10 408.8 CORRECTED VIEWS DESCRIPTION 2005/10 15.28 388.2 17.16 436 6.00 152.4 LIST 23 23"...
  • Page 55 20.13 511.4 15.28 388.2 6.00 152.4 LIST 23 23" MID-MOUNT REAR ISOMETRIC VIEW (LIST 81 - OUTPUT BARS) LIST 25 TOP VIEW 23" FLUSH MOUNT (LIST 81 - OUTPUT BARS) 7.57 192.4 6.90 175.1 REAR ISOMETRIC VIEW (LIST 82 - OUTPUT BARS) REAR VIEW THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED...
  • Page 56 REVISIONS REV BY DESCRIPTION DATE APPD LIST 81 UPDATED MP/JU 2005/10 CORRECTED VIEWS DESCRIPTION CORRECTED VIEWS DESCRIPTION 2005/10 UPDATED LIST 85 LABELS AC WIREWAY BLANK PLATE AC WIREWAY, BOTH SIDES, SWITCH SETTING FOR CAN TERMINATION SEE DETAIL 'A' 1.3 [34] HOLE FOR CUSTOMER SUPPLIED 1"...
  • Page 57 3/8" FLAT WASHER 3/8" LOCK WASHER 3/8" FLAT WASHER 3/8 - 20 NUT POSITIVE (+) 3/8" LOCK WASHER POSITIVE (+) OUTPUT TERMINAL 3/8 - 20 NUT OUTPUT TERMINAL DC WIRING (CUSTOMER SUPPLIED) POSITIVE (+) BUS BAR (CUSTOMER SUPPLIED) NEGATIVE (-) NEGATIVE (-) OUTPUT TERMINAL OUTPUT TERMINAL...
  • Page 58 REVISIONS DESCRIPTION REV BY DATE APPD 2004/06 CORRECTED NO. OF MODULES REAR COVER, BLANKING PLATE ADDED J.U. 2005/02 GS INCORPORATED EO -C1. 2006/09 LIST 19 & 23 ADDED. 2006/09 CORRECTED SPELLING ERROR 16.10 408.9 15.28 388.2 6.74 171.1 6.55 166.4 6.05 153.7 4.99 126.6...
  • Page 59 REVISIONS REV BY DESCRIPTION DATE APPD UPDATED LABEL L2 TO L2/N AC WIREWAY BLANK PLATE SWITCH SETTING FOR CAN TERMINATION AC WIREWAY (2 PLACES) SEE DETAIL 'A' 1.3 [34] HOLE FOR CUSTOMER SUPPLIED UNTERMINATED 1" CONDUIT FITTING TERMINATED REAR VIEW - AC REAR COVER REMOVED PROTECTIVE EARTH TERMINAL 2 PLACES DETAIL 'A' - AC INPUT...
  • Page 60 3/8" FLAT WASHER POSITIVE (+) 3/8" LOCK WASHER POSITIVE (+) OUTPUT TERMINAL 3/8-20 NUT OUTPUT TERMINAL 3/8" FLAT WASHER 3/8" LOCK WASHER 3/8-20 NUT DC WIRING (CUSTOMER SUPPLIED) POSITIVE (+) BUS BAR (CUSTOMER SUPPLIED) 3/8" FLAT WASHER 3/8-20 x 1" HEX BOLT NEGATIVE ( - ) OUTPUT TERMINAL NEGATIVE ( - )
  • Page 61 REVISIONS REV BY DESCRIPTION DATE APPD 64 PIN CONNECTOR PIN OUT RESET SWITCH A32 B32 K1 - COM K1 - NO K2 - NO K1 - NC K2 - NC K2 - COM K3 - COM K3 - NO 32 PIN CONNECTOR K4 - NO K3 - NC K4 - NC...
  • Page 62 REVISIONS REV BY DESCRIPTION DATE APPD CAN TERMINATION SWITCH ENABLE TERMINATION IN THE FINAL SHELF ON THE CAN BUS ONLY #6-32x0.375 PH SCREW, LOCK AND FLAT WASHERS 747-271-20 ADAPTER SECURE ADAPTER INTO SHELF MODULE #1 SLOT BATTERY CONNECTION (-48V) ONLY REQUIRED WHEN USING 3.6kW CORDEX SHELF BATTERY DISCONNECT DEVICE CXCM4 POWER AND RECTIFIER CAN...
  • Page 64 Alpha Technologies Ltd. Alpha Energy, Alpha Industrial Power Inc. 7700 Riverfront Gate Alpha Technologies Inc. 1075 Satellite Blvd NW, Burnaby, BC V5J 5M4 3767 Alpha Way Suite 400 Canada Bellingham, WA 98226 Suwanee, GA 30024 Tel: +1 604 436 5900 United States United States Fax: +1 604 436 1233...
