Pixelink PL-A780 System Manual

Firewire 6.6 megapixel camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Document No: 04646-01
Revision Date: June 2004
Copyright © 2004 PixeLINK. All Rights Reserved
PL-A780
FireWire
6.6 Megapixel Camera
SYSTEM GUIDE
3030 Conroy Road, Ottawa, ON K1G 6C2
Phone:
613.247.1211 or 1.888.484.8262
Fax:
613.247.2001
http://www.pixelink.com
e-mail:
info@pixelink.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL-A780 and is the answer not in the manual?

Questions and answers

Related Manuals for Pixelink PL-A780

Summary of Contents for Pixelink PL-A780

  • Page 1 PL-A780 Document No: 04646-01 Revision Date: June 2004 FireWire 6.6 Megapixel Camera SYSTEM GUIDE 3030 Conroy Road, Ottawa, ON K1G 6C2 Phone: 613.247.1211 or 1.888.484.8262 Fax: 613.247.2001 http://www.pixelink.com Copyright © 2004 PixeLINK. All Rights Reserved e-mail: info@pixelink.com...

  • Page 2: Copyright Notice

    System Guide or the examples herein. PixeLINK assumes no responsibility for any damage or loss resulting from the use of this System Guide, loss or claims by third parties which may arise through the use of this product, any damage or loss caused by deletion of data as a result of malfunction or repair, or any other damage related to the use of this product or associated documentation.
  • Page 3 FCC testing will be completed in 2004. All units shipped prior to the completion of FCC testing should be considered as prototypes and will be marked with the statement that the FCC rating is pending. Note that the PL-A780 Series is materially similar to the PL- A780 which has passed FCC and CE compliance testing.
  • Page 4 16 June 2004 Initial release. Related Documentation PixeLINK Application Programming Interface (API) Reference, Part Number 04326 PixeLINK Developer’s Application User’s Manual, Part Number 04328 IIDC 1394-based Digital Camera Specification, Ver. 1.31, dated September 17, 2003. IEEE Trade Association Document 2003017 Document No.: 04646-01...

  • Page 5: Table Of Contents

    Table of Contents Quick Start Instructions Introduction 2.1 The PL-A780 Series 6.6 Megapixel Camera 2.2 Topics Covered in this Guide 2.3 Firmware and Hardware Versions & Variants 2.4 Compatibility with PixeLINK Software & Drivers 2.5 Compatibility with 3 Party Software & Drivers PL-A780 Camera Specifications 3.1 Features...
  • Page 6 5.1.4.1 Camera Information 5.1.4.2 Camera Name 5.1.4.3 Descriptors 5.1.4.4 General Purpose Outputs 5.1.4.5 Look Up Table 5.1.4.6 Pixel Addressing 5.2 Non IIDC Features Accessible with the PixeLINK API 5.2.1 Flat Field Correction Developing Software for the PL-A780 6.1 Introduction 6.2 Useful Definitions 6.3 How Do 1394 Devices Communicate?
  • Page 7 Table 6 Operating Environment Conditions ..............15 Table 7 Storage Environment Conditions ..............16 Table 8 Pinout of the 6-Pin Hirose Connector..............23 Table 9 Default settings for PL-A780 features ...............27 Table 10 Feature Control Register Min/Max Values............30 PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright ©...
  • Page 8 Table 12 - Feature Element Inquiry CSRs (Section 4.5 in the IIDC 1.31 Spec.)..... 52 Table 13 - Color Coding Inquiry CSR for Format_7 (Section 4.9 in the IIDC Spec.) ..53 Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 9: Quick Start Instructions

    7. Adjust gamma and saturation controls as required to achieve the best image quality. Note that the PL-A780 camera, like any CMOS device, is subject to the physics of the sensor design. Fixed Pattern Noise (FPN), Photo Response Non Uniformity (PRNU), stuck pixels, read noise and thermal noise are an inherent part of the sensor.
  • Page 10 If a single gain and exposure setting is not possible, there will be practical limits on the gain and exposure times that can be used before the noise artifacts cause unacceptable degradation to the image quality. Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 11: Introduction

    “daisy chain” on a single FireWire bus. Fully IEEE 1394 IIDC 1.3 (IIDC) compliant, the PL-A780 can also be used with third party drivers compatible with the IIDC specification, such as the National Instruments IEEE 1394 for IMAQ driver.

  • Page 12: Table 1 Pl-A780 Variants

    For information on programming with the PixeLINK Application Programming Interface, please refer to the PixeLINK API Reference Manual, Part Number 04326. For information on the use of the PL-A780 with the PixeLINK Developer’s Application, please consult the PixeLINK Developer’s Application User’s Manual, Part Number 04328.

  • Page 13: Table 3 Firmware Version History

    Version 66.00.23 Initial release with the pre-production cameras. 2.4 Compatibility with PixeLINK Software & Drivers PL-A780 cameras are compatible with the following PixeLINK drivers and API software: • PixeLINK Camera Driver, Version 4.1 and later. • PixeLINK API, Version 4.1 and later.

  • Page 14: Table 5 Frame Rate - Frames Per Second

    PL-A780 Camera Specifications 3 PL-A780 Camera Specifications 3.1 Features Sensor Compatibility • • 2/3" CMOS 2208 x 3000 resolution (7.73 IIDC 1.3 mm x 10.50 mm - 13.1 mm diagonal) Format 0, Modes 1, 3, 5 and 6 • Format 7 3.5 µm square pixels...

  • Page 15: Frame Rate

    PL-A780 Camera Specifications 3.2 Sensor The sensor used in the PL-A780 cameras is a Fill Factory IBIS4-6600. The IBIS4-6600 is a 6.6 megapixel solid-state CMOS image sensor with 2210 x 3002 active pixels. The image size is fully programmable to a user-defined ROI. Pixels are on a 3.5 µm pitch.

  • Page 16: Figure 1 Color Bayer Pattern - Pixel Addressing Mode 1 (No Decimation)

    PL-A780 Camera Specifications Figure 1 Color Bayer Pattern - Pixel Addressing Mode 1 (No Decimation) Figure 2 Color Bayer Pattern - Pixel Addressing Mode 2 (Decimation 2x) Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE...

  • Page 17: Figure 3 Color Bayer Pattern - Pixel Addressing Mode 3 (Decimation 3X)

    PL-A780 Camera Specifications Figure 3 Color Bayer Pattern - Pixel Addressing Mode 3 (Decimation 3x) Figure 4 Color Bayer Pattern - Pixel Addressing Mode 4 (Decimation 4x) PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE...

  • Page 18: Figure 5 Color Bayer Pattern - Pixel Addressing Mode 6 (Decimation 6X)

    PL-A780 Camera Specifications Figure 5 Color Bayer Pattern - Pixel Addressing Mode 6 (Decimation 6x) The sensor ROI can also be resampled to combine the signals from a 2 x 2 or larger block of pixels (GRBG) into one RGB triplet. To see how this has an effect, it is important to...

  • Page 19: Figure 6 Examples Of The Effects Of Decimation, Resampling And Averaging On Image Quality

    PL-A780 Camera Specifications image quality. Defocusing the lens slightly to blur the lines in the image can eliminate the colors. Decimation reduces the image resolution but will introduce more artifacts as seen in Figure 6 b. The image has been magnified to allow comparison with Figure 6 a. The benefit of using decimation is mainly the increased frame rate possible with the reduced resolution.

  • Page 20: Operating Modes - Rolling Shutter And Fast Reset Shutter

    3.2.3 Timing, Performance and Data Rates The PL-A780 sensor uses a 40 MHz pixel clock to read out pixel data at 25 nanoseconds per pixel. Each row also has a delay of 7.3 µseconds and is padded with 10 isolation pixels. The minimum row readout time, in microseconds, is given by ∗...

  • Page 21: Figure 7 Rolling Shutter Integration And Read-Out

    The distortion is due to the comparatively lengthy process of readout compared to exposure. For example, to readout the entire PL-A780 frame requires approximately 250 milliseconds. While a short exposure may stop a moving object, the same object can move appreciably in the quarter second that it takes to readout the frame resulting in distortion in the direction of motion.
  • Page 22 To simplify the control of lighting when using the Fast Reset Shutter, the PL-A780 GPOs can output a Flash Window that indicates the period of time following the completion of the array reset and the start of readout.

  • Page 23: Figure 8 Pl-A780 Spectral Response

    PL-A780 Camera Specifications 3.3 Performance Specifications The PL-A780 responds to visible light in the 400 – 1000 nm range. The chart of spectral response is shown in Figure 8 below. Performance figures for FPN, PRNU and dynamic range are currently being measured.

  • Page 24: Table 7 Storage Environment Conditions

    PL-A780 Camera Specifications 3.4.2 Storage Environment Objectives Table 7 Storage Environment Conditions Condition Limits Temperature -40°C to + 75°C (-40°F to 167°F) Temperature change < 10°C/minute (< 18°F/minute) Shock 50 G Vibration 10 G at 20-200 Hz 20% - 80% non condensing Humidity Document No.: 04646-01...

  • Page 25: Figure 9 Pl-A780 Standard Configuration

    Front and bottom mounting holes for a tripod or other mounting fixture (M3 screws) Accessories Accessories such as trigger kits, tripod mounts, lenses, laptop accessory kits and hands-free switches are available from PixeLINK. For a current list of accessories, visit the PixeLINK Web site at http://www.pixelink.com/ or contact your PixeLINK vendor.

  • Page 26: Figure 10 Pl-A780 Rear View

    Camera Operation & Features Status Light MV Connector Figure 10 PL-A780 Rear View Figure 11 PL-A780 Front View Figure 12 PL-A780 Bottom View Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 27: Pl-A780 Handling Instructions

    Camera Operation & Features 4.3 PL-A780 Handling Instructions Caution: Do not open the camera housing. ESD— Handle the PL-A780 using proper ESD procedures. Refer to ANSI/ESD S20.20 Class Type 3 (4000 V). Cleaning Housing: Clean the housing with a cloth dampened (not dripping) with reagent- grade isopropyl alcohol.

  • Page 28: Electrical Connections

    As shown in Figure 12 on page 18 there are four M3 threaded holes on the bottom of the PL-A780 Camera. These holes can be used to attach the camera to an optional ¼-20 thread mounting plate (available from your PixeLINK vendor) or to mount the camera to a custom fixture.

  • Page 29: Status Led

    PixeLINK vendor. Power Demand A single PL-A780 draws 5 watts from the FireWire cable or 417 mA @ 12 V. Power Limitations The power capacity of the bus depends on the FireWire adapter card installed in the host computer.

  • Page 30: Figure 13 Machine Vision Connector-Interface Schematic

    Figure 13 Machine Vision Connector—Interface Schematic 4.6.3.1 Trigger and GPO Timing The default trigger latency on the PL-A780 cameras is 8 microseconds from the change in the trigger signal until the start of the image reset, assuming the Trigger Delay feature is set to zero.

  • Page 31: Table 8 Pinout Of The 6-Pin Hirose Connector

    Debounce Delay Adjustment Tool included with the PixeLINK software. A copy of the application is also available from the PixeLINK Web Site at http://www.pixelink.com. Look for the tool on the PL-A780 product page.

  • Page 32: Figure 14 Trigger Input Example - Ttl And Gate

    100KHz to avoid multiple triggers. Figure 14 Trigger Input Example - TTL AND Gate Figure 15 Trigger Input Example - TTL Inverter Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 33: Figure 16 Trigger Input Example - An Optical Trigger And Multiple Cameras

    GPO outputs from the camera being used to output a TTL signal. Figure 18 on page 26 shows the GPO from one camera being used to trigger a second camera. Figure 17 GPO Example - Output a TTL signal PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 34: Figure 18 Gpo Example - Gpo To Trigger

    The raw value of the trigger input can be read from the IIDC Trigger Inquiry register. This can be used as a general purpose input if one is required. Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 35: Table 9 Default Settings For Pl-A780 Features

    IIDC 1.31 specification. Advanced Control and Status Registers (CSRs) are provided to support custom features. This section describes the features and controls of the PL-A780 camera. For each feature, the set of values that define the feature in the IIDC specification are provided. In addition, information not included in the IIDC specification is provided to improve usability.
  • Page 36 White Balance 3200.0° 5.1.2 Video Format/Mode/Frame rate The PL-A780 supports the following video formats, modes and frame rates. • Format 0 VGA non-compressed 640 x 480 • Mode 1, 320 x 240 YUV(4:2:2), Frame rate 2 to 4 (7.5 to 240 fps) •...
  • Page 37 The feature control registers are integer based and only allow positive integer values. The absolute value registers use floating point numbers and can represent engineering units. The PixeLINK PL-A780 camera will accept both methods of control. However, some third party software applications only use the feature control register values. As a result, the control sliders will have strange limits.

  • Page 38: Table 10 Feature Control Register Min/Max Values

    FireWire bus. The frame interval can be effectively controlled by the trigger or by adding delays to the internal trigger. The maximum internal delay is 2.5 seconds. Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 39 22.1 A setting of 0.0 represents the imager unity gain setting. Parameter Unit Type Default Step Size Comments Gain Relative 22.1 Non linear PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 40: Gamma

    Unit Type Default Step Size Comments Left Columns Absolute 2184 Rows Absolute 2976 Width Columns Absolute 2208 2208 Height Rows Absolute 3000 3000 Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 41: Saturation

    63 µs Varies The integration time step size Time is the time required to read out one row. See Section 3.2.3 on page 12. PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 42: Temperature

    Turning the trigger on enables the Fast Reset Shutter. Parameter Unit Type Default Step Size Comments Mode None Absolute The PL-A780 only supports Trigger Mode 0. See Section 8.1. Source None Absolute 0: External, 1: Internal Polarity None Absolute 0: Negative, 1:Positive...

  • Page 43: White Balance

    0.0156 5.1.4 Advanced Features The following features are not defined by the IIDC specification but are specific to PixeLINK cameras and to the PL-A780 camera series. To access, read and/or control these features, see Section 7.1 Extensions to the IIDC Version 1.31 Specification on page 52.

  • Page 44: Camera Information

    When multiple descriptors are in use, the camera will encode a synchronization number in the first 16 bytes of image Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 45: General Purpose Outputs

    5.1.4.5 Look Up Table In the PL-A780, the Look Up Table (LUT) has 1024 2-byte entries that range in value from 0 to 1023 (10-bit depth). The LUT is used to implement the IIDC Gamma feature but it can also be used to implement any LUT transfer function required.
  • Page 46 LUT is turned off, the LUT values will be retained in camera memory and will be applied again once the LUT is turned on. Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 47: Pixel Addressing

    Comments Mode None Absolute 0: Decimate, 1: Average, 2: Bin, 3: Resample Value None Absolute Pixel Addressing Value of 5 is not supported. PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 48: Non Iidc Features Accessible With The Pixelink Api

    Camera Operation & Features 5.2 Non IIDC Features Accessible with the PixeLINK API The following features are specific to the PL-A780 camera series. To access them, you will need the PixeLINK Software Development Kit (PL-SDK-VERSION-4.1). The PixeLINK API defines two functions that allow access to camera specific features. These are PxLCameraRead and PxLCameraWrite.

  • Page 49: Developing Software For The Pl-A780

    IEEE 1394a Supplement CSR Architecture Specification – ISO/IEC 13212 (ANSI/IEEE 1212) If you are using the PixeLINK SDK, you do not need to read this section. The PixeLINK SDK is a high level Application Programming Interface (API) compatible with C, C++ and Visual Basic. It provides low-level drivers and a high-level software interface to the camera that simplifies the task of controlling PixeLINK cameras.

  • Page 50: How Do 1394 Devices Communicate

    Developing Software for the PL-A780 6.3 How Do 1394 Devices Communicate? Essentially the IEEE - 1394 FireWire bus uses a memory mapped communication protocol. 1394 transactions can be considered to be a read or write of data to a specified memory address.

  • Page 51: Command Register Details

    Developing Software for the PL-A780 features a specific camera supports and the Control registers are used to modify settings of the supported features. The next section will go into more detail about some of these registers. 6.5 Command Register Details This section will give details on some of the different IIDC command registers, what they mean and how to use them.

  • Page 52: Camera Features

    Developing Software for the PL-A780 different types of pixel format supported, and provide controls to set all of these options. The also provide information and control of isochronous streaming parameters (discussed later in Section 6.6.2 on page 45). For example to determine the current image width and height of the video data read the register at offset 000Ch (or address FFFF F0D0 0A0Ch using the example format 7 mode 0 control register offset).

  • Page 53: Video Transmission Details

    6.6.3 Features That Affect Isochronous Packet Size or Format The following list includes standard IIDC registers as well as PixeLINK extended registers: Status and Control Registers CUR_V_FRM_RATE...

  • Page 54: Pixelink Advanced Csrs

    V1.31 specification as vendor specific. These CSRs are based at an offset found in the Advanced Feature Offset value (register 0x480). This table is common for all IIDC compliant PixeLINK cameras and is included to promote compatibility. Not all the features listed in this table are available with the PixeLINK PL- A780 cameras.
  • Page 55 OBSOLETE. This has been replaced [2..7] with the trigger_source parameter of 120h Advanced Trigger Inquiry Trig_Intern_Inq the trigger_mode feature in IIDC v1.31 Trig_Type_Inq [10..31] PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 56 Quadlet offset of the absolute value Extended Shutter Knee 13Ch Offset [0..31] CSR for Extended Shutter Knee Point Point 0 0 (See NOTE 4) Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 57 Length, in bytes, of the data stored at the buffer address. This includes the 15Ch Buffer Size Value [0..31] size of the stored frame plus any descriptor information. PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 58 1 = On, 0 = Off 224h Rotate [1..31] Reserved Frame Buffer On/Off 228h Frame Buffer On_Off 1 = On, 0 = Off Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 59 The Feature_Id field of the Advanced Feature Access Control Register is a 48bit value with the following format: 0 – 7 8 – 15 16 – 23 24 – 31 32 – 39 40 - 47 PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 60: Extensions To The Iidc Version 1.31 Specification

    ID register should be checked each time this feature is changed. 7.1 Extensions to the IIDC Version 1.31 Specification The following sections describe PixeLINK extensions to the IIDC specification to allow for extra functionality within the IIDC address space. 7.1.1 Determining which Features can change in a Descriptor All feature element inquiry registers (Offset 500h to 5FFh) use bit 2 to indicate if the feature can have different values in different descriptors as shown in Table 12 below.

  • Page 61: White Shading Absolute Value Registers

    : quadlet offset of green or blue CSRs = ABS_CSR_HI_INQ_14 + 3 * X (where X = 1 for green and X = 2 for blue). PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 62: Feature Modes And Values

    8 Feature Modes and Values 8.1 Trigger Modes Trigger Modes 0-5 are defined by the IIDC 1.31 specification. The PL-A780 only supports Trigger Mode 0. When the trigger is turned on, the camera is placed in fast reset shutter mode. See Section 3.2.4.2 on page 14 for more information regarding the reset and readout times.

  • Page 63: Gpo Modes

    Feature Modes and Values 8.2 GPO Modes The PL-A780 supported GPO modes are defined below. The PL-A780 supports modes 0 (Strobe), 1 (Normal), 3 (Busy) and 4 (Flash Window). 8.2.1 GPO MODE 0 (STROBE) The GPO is set after a trigger occurs. The GPO pulse is delayed X (GPO Parameter 1) seconds from the trigger and is Y (GPO Parameter 2) seconds in duration.
  • Page 64 0. The PC uses little endian notation, where the least significant byte comes first. Hence, on a PC system, when receiving 16-bit data from the camera, the bytes will be swapped. Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 65 See the IIDC Specification - offset 058h from the Video Mode CSR for Format 7. For the PL-A780 series cameras which do not support flip or rotate, the color data will always be output with Filter ID = 2 (GR/BG) format.
  • Page 66 U8 byTriggerPolarity; // Trigger Polarity U8 byTriggerType; // Trigger Type U8 byReserved; // Padding to quadlet align } DESCRIPTOR, *PDESCRIPTOR; #endif // FRAME_STRUCTURE Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...

  • Page 67: Technical Notes & Support

    Download the Latest Software and Firmware The PL-A780’s onboard programming (firmware) can be upgraded at your computer. Whether you have a tech support issue or not, we recommend that you check our Web site (http://www.pixelink.com/) regularly for the latest versions of your PixeLINK software and firmware.
  • Page 69 Video stream The video image data sent over the FireWire bus (cable) from the camera to the host computer. This is the source of data for the preview window and any captured images or video clips. PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 71 GPO, 3, 4, 16, 19, 25, 26, 31, 41, 53, Delay, 38 54, 56, 57, 61, 64, A-1 version history, 5 heat sinking, 22 video formats, 32, 47 PixeLINK PL-A780 Document No.: 04646-01 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
  • Page 72 White Balance, 32, 33, 39, 63 YUV422, 11, 12, 31, 47 White Shading, 32, 39, 59 Document No.: 04646-01 PixeLINK PL-A780 MACHINE VISION CAMERA Copyright © 2004 PixeLINK SYSTEM GUIDE All Rights Reserved...
