  • Page 1 P OW ER 38-2553 PORTABLE 7" LCD MONITOR AND DVD PLAYER PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
  • Page 2 Notice: 1.This Product incorporates copyright protection technology that is pro- tected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights own- ers. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 3: Table Of Contents

    Content A. Introduction ................ 1 B. Cautions and Warnings ............. 1 C. Contents ................3 D. Powering and Installation ..........3 E. Controls, Indicators, and Connectors ......... 5 F. Loading and Playing a Disc ..........6 G. Setup.................. 7 H. Basic Operation ..............13 I.

  • Page 4: Introduction

    A. Introduction Thank you for choosing theportable DVD player. The main features include a 7" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in hotels, offices or your home.
  • Page 5 operation, never cover or block the slots and openings with a cloth or other material. Keep the unit away from an open flame such as fire, candle etc. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type, in order to protect the environment, please dispose the battery properly.

  • Page 6: Powering And Installation

    7.Regional Coding Both the DVD player and disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 2 DVD with other regional codes cannot be played in this unit C.
  • Page 7 3. Installation In Vehicle 1) Take out carry bag and unit. Open them for installation. 2) Place unit into the bag across the waist flex and make sure four corners of unit are tightened by narrow flexes. 3) Place the bag with unit into back of car seat and fasten it into the headrest with length adjustable waist strap.

  • Page 8: Controls, Indicators, And Connectors

    E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 2) O PE N P OW ER Figure 2 11) Power LED 1) DC 9V Input Jack 12) Open Switch 2) Charge Indicated LED 13) LCD Panel Shut Off Switch 3) AV Jack 14) Previous Button 4) AV in/out SW...

  • Page 9: Loading And Playing A Disc

    2. Remote Control View (Refer to Figure 3) 1) Setup Button 2) Up Button 3) Previous Button 4) Enter Button 5) Reverse/Left Keypad 6) Down Button 7) Numeric Button 8) Display Button 9) Zoom Button 10) Subtitle Button 11) Next Button 12) A-B Repeat Button 13) Forward/Right Keypad 14) 1/All Repeat Button...

  • Page 10: Setup

    G. Setup 1. General Setup Page 1)With no disc inside the player, press ‘SETUP’ to display the Main screen of the Setup Menu on the screen and “General Setup Page” appears. At the same time, “ ” is highlighted. Press ‘SETUP’ again to exit the Setup Menu .
  • Page 11 c) OSD Language You can choose English,French,Italian,German,Dutch as the OSD language d). Screen Saver *On: Enables screen saver *NOTE: The DVD player will enter the Screen Saver mode after ap- proximately five minutes if the same image remains on the screen. *Off: Disables screen saver (off) e).
  • Page 12 3. Password button to select “Password Setup In Setup menu, Press the Page” and is highlighted. Press ENTER to enter the password page. Press ENTER twice to enter the Password Change Page. Input the Old Password or the Default Password, the New Password, and Confirmed the New Password.
  • Page 13 NOTE: The level of 8 ADULT is the factory default. e) Select ‘Default’ using the UP/DOWN button, then press RIGHT to enter the submenu. Press ENTER to make the setting return to the factoryset mode. NOTE: The parental setting is not affected by the default reset function.

  • Page 14: Basic Operation

    H. Basic Operation POWER Turn the unit on/off OPEN Remove/load the disc PLAY/PAUSE Start Play/Still Picture STOP (1 time) Stop at the present playing point / (2 times) Stop playing NEXT Go to the next chapter, track or scene during play back PREVIOUS Go back to the previous chapter, track or scene during play back...

  • Page 15: Menu

    I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 16 2. ANGLE During playback of a disc, press ‘ANGLE’ to display the available angles for discs containing multi-angles*, with the current angle num- ber (1) and the total number of angles (2) displaying. Press ‘ANGLE’ to select another angle, then press again to exit and return to the normal viewing angle.
  • Page 17 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total num- ber of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automati- cally if the ‘AUDIO’...
  • Page 18 6. A-B REPEAT a. During playback press a first time ‘A-B’ to set the Starting Point A. A-B Repeat Starting Point Screen Display b. Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B. A-B Repeat Ending Point Screen Display c.

  • Page 19: Playing Audio Cds

    7. REPEAT a. During playback press ‘1/ALL REPEAT’ constantly to see the re- peat mode as right. Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Off: Resume normal playback The ‘Chapter’ repeat display shows below for example: Chapter Repeat Screen Display K.
  • Page 20 Total Elapsed: The current track playing and the total time that the CD has been playing. Total Remain: The current track playing and the amount of time remaining on the CD. Display Off: The CD time Information will not be displayed. Take ‘Single Elapsed’...

  • Page 21: Playing Mp3 Discs

    L. Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. CD-R /RW discs that have been encoded in MP3 format are compatible with this system.
  • Page 22 4. Use the ( NEXT ) button to move to the next song. Press the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF(Folder). Pressing 1/ALL REPEAT consecutively changes the repeat options: •...

  • Page 23: Connecting To Other Equipments

    M. Connecting to other equipments. ( Refer to Figure 4) 1. You can also connect the DVD player to a TV to enjoy high quality stereo sound and picture on another monitor. a. Position the AV In/Out Switch to “Out” Position. b.
  • Page 24 3.Using E Port for connecting to a Game Pad (sold separately). Playing Games with Game Pad Please refer to the specific operations described in the Game Pad. Figure 6 4.Using E Port for connecting to a Tuner Box (not available in Scandinavia Receiving the TV Programs with Optional Tuner box.

  • Page 25: Specifications

    N. Specifications Compatible DISC: DVD/CD/MP3/MPEG4 Signal system: PAL Panel size: 7 inch Frequency response: 20 Hz to 20 kHz Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser Wave Length: 650 nm/795 nm Power source: DC 9-12 V Operating temperature: 5~35°C Weight : 0.68 kg...
  • Page 26 battery in optimum condition. Under no circumstances short the battery terminals, store the battery in a metal container, or leave the battery in a humid or damp environment. Ideally, store the battery in an airtight container with desiccant or other dehumidify- ing agent.
  • Page 27 Installing the Battery Pack: 1. First, make sure the player is in “Power Off” mode and that the AC power supply has been disconnected. 2. Flip down the monitor. 3. Push the battery towards the rear flank of the player until it locks into position.

  • Page 28: Troubleshooting

    P. Troubleshooting PROBLEM SOLUTION • Make sure your DVD is connected properly. No sound or Make sure all cables are securely inserted distorted sound into the appropriate jacks. • You can’t advance through the opening credits and warning information that appears Can’t advance at the beginning of movies because the disc through a...
  • Page 29 Troubleshooting (Cont) PROBLEM SOLUTION • Verify that the batteries in the remote are IR sensor fresh. inoperative • Verify that the remote sensor eye is not obstructed. • Verify that the infrared transmitter is pointed directly at the IR sensor, and is within 10 feet of the sensor.
