Summary of Contents for Klimaire KFTC018
-
Page 1: Installation Manual
® KFTC Series 18,000 to 48,000 Btu/h Cooling Only & Heat Pump INSTALLATION MANUAL... -
Page 2: Installation
I N S T R U C T I O N S C E I L I N G CASSETTE TYPE INDOOR UNIT Read this installation instructions carefully before installing the unit KFTC018 / 024 MODEL SERIES KFTC036 / 048... - Page 3 INSTALLATION DIAGRAM AND ACCESSORIES INDOOR UNIT High Pressure Copper Tube Low Pressure Copper Tube Drain Pipe Wire Low Pressure Piping Tape High Pressure Piping Tape OUTDOOR UNIT...
-
Page 4: Indoor Unit Installation
There should not be any obstacles to prevent the Do not install the unit near the door way. air circulation. A place where air circulation in the room will be good. 1.1 INDOOR UNIT DIMENSION. MODEL KFTC018 KFTC024 KFTC036 KFTC048 Height above ceiling (A) 235 mm. 235 mm. - Page 5 INDOOR UNIT INSTALLATION 860~890 THE CEILING HOLE FIG.2 1.2 INDOOR UNIT INSTALLATION. Select the location where a space is more more than than 100 cm. as shown in fig.3 also ensure 100 cm that the position does not interfere with light fitting, sprinkle head, etc.
- Page 6 INDOOR UNIT INSTALLATION Hang the four mounting rods to the positions marked as picture shown (using twelve nuts and eight washers to support the suspension Lock Nut brackets). Suspend the unit to the mounting rods. Lock the nuts, ensure for good drainsage, and Washers check whether the unit is on horizontal level by using leveling guage.
-
Page 7: Outdoor Unit Installation
OUTDOOR UNIT INSTALLATION WHERE TO INSTALL OUTDOOR UNIT : The foundation must be solid enough to bear the The location is sufficiently isolated so that the running weight and vibration of the unit. noise and the hot exhaust air do not disturb the The space around the unit is adequate for ventilation. -
Page 8: Pipe Preparation
PIPE PREPARATION Right Wrong PIPE & ELECTRICAL WIRE CUTTING Cutting Tool Use cutting tools easily found in the market. Sloped Cut Rough Cut Measure precisely both outer & inner pipe. Provide a little bit longer pipe than the measurement. Wire must be 1.5 m. longer than the refrigerant tube. REAMING Refrigerant Tube Clean inside of the inner refrigerant tube. -
Page 9: Refrigerant Piping Work
4.3 Avoid pipe bending as much as possible. If it is necessary, the bending radius must be more than 3 cm. or 4 cm. LIQUID PIPE TABLE MODEL PIPE SIZE THICKNESS (mm.) KFTC018 3/8" Gas pipe and liquid pipe insulation depends upon KFTC024 3/8" copper pipe size and the insulation thickness = 3/8" KFTC036 3/8"... - Page 10 REFRIGERANT PIPING WORK DRAIN PIPE OUTLET A drain pipe and refrigerant pipes must be covered by insulation to prevent condensation. Caution on drain collecting piping. Use a larger diameter pipe as it comes near the end. Horizontal The size of pipes marked with * must be at least 40 mm (1-5/8),...
-
Page 11: Air Purging
AIR PURGING AND CHECK OF PIPE LEAKAGE AIR PURGING The purpose of air purging is to get rid of moisture and air in the system, otherwise moisture and air may cause ineffectiveness of the compressor which directly affects the cooling capacity. PURGING BY USING VACUUM. -
Page 12: Wiring Diagram
How to tighten screw on terminal block. 1. Bare the ends of electric wire. 2. After retaining the wire, check that all the terminal screws are firmly tightened. COOLING ONLY INDOOR UNIT OUTDOOR UNIT KFTC018- KFTC02- KFTC036- KCHB018- KCHB024- KCHB036-... - Page 13 WIRING DIAGRAM COOLING ONLY INDOOR UNIT OUTDOOR UNIT KFTC036 / 048- KCVS036 / 048-C HEAT PUMP INDOOR UNIT OUTDOOR UNIT KFTC036 / 048- KCVS036 / 048-H...
- Page 14 LIQUID PIPE AND DRAIN PIPE IF THE OUTDOOR UNIT IS INSTALLED Sealed LOWER THAN THE INDOOR UNIT (picture 1) 1. A drain pipe should be above ground and the end Saddle of the pipe does not dip into water. All pipes must be restrained to the wall by saddles.
-
Page 15: Test Running
TEST RUNNING RUN TEST Check electrical main wire's voltage. Run the air conditioner for 15 minutes or more. Check the electrical current with ampmeter and compare with the specifications. Terminal Board Control Board Cover Electrical Wire Ampmeter EVALUATION OF THE PERFORMANCE Use a thermometer to measure cool air both in and out. - Page 16 ® Klimaire Products, Inc. 7909 N.W. 54th Street Miami, 33166 U.S.A. : (305)593- 8358 : (305)593-8212 e-mail : klimaire@worldnet.att.net NOTE: SPECIFICATIONS AND PERFORMANCE DATA LISTED HEREIN ARE SUBJECT TO CHANGE WITHOUT NOTICE I2TC2001...
