Summary of Contents for Primus HCWP1- 26

  • Page 1: Log Splitter

    Log Splitter Owner/Operator Manual Models HCWP1- 26...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY......2 SAFETY WARNING SYMBOL ..3 SAFETY RULES.

  • Page 3: Safety

    SAFETY NOTATIONS NOTE: General reference information for WARNING: This splitting machine proper operation and maintenance practices. is capable of crushing or amputating body parts. Failure to IMPORTANT: Specific procedures or information required to prevent damage to observe the safety instructions in unit or attachment.

  • Page 4: Safety Warning Symbol

    4. DANGER! Keep hands away from moving parts. Moving parts can crush or cut. Keep hands away from moving parts. Moving parts can crush or cut. Operate the log splitter on level surfaces. Stay off slopes and slippery surfaces. OL0710 Always wear eye and hearing protection.

  • Page 5: Safety Rules

    SAFETY RULES parts. If unit is to be used by someone other than original purchaser; loaned, rented or sold, Protect eyes, face and head from objects that ALWAYS provide this manual and any may be thrown from unit. Wear appropriate needed safety training before operation.
  • Page 6 • Be sure to stop the engine and relieve ALWAYS keep protective structures, guards, hydraulic pressure before doing any and panels in good repair, in place and work on hydraulic parts. securely fastened. NEVER modify or remove • Keep body and hands away from pin safety devices.

  • Page 7: Specifications

    Operator Operator Manual Manual Manual of of of of Splitter Splitter Splitter Operator Operator Manual Splitter Technical Technical Parameters Parameters Parameters of of of of HCWP1-26T HCWP1-26T HCWP1-26T The Technical TechnicalParameters HCWP1-26T 1.1 The Max Splitting Force: 26T+/-10% 1.2. Max Pressure : 24MPa 1.3.

  • Page 8: Controls And Features

    3. 3. 3. 3. Controls Controls Controls Features Features (Figure (Figure 2& 2& Figure Figure Figure 3) 3) 3) 3) Controls and and Features Features (Figure (Figure 2& 2& Figure Wood pushing base Splitting control lever Picking up handle Drag wood plate Wheel Front jack stand Wood picking up shovel...
  • Page 9 position. 4.2. The log will be transported to the the proper location of the splitter when wood picking up shovel back to the limited position. The working of wood picking up shovel is controlled by packing up handle，wood picking up shovel will be in the quiescent state when the handle in the natural position. Pushing the handle inside （...
  • Page 10 Figure 5 6. Safety Tips Please keep away from the wood picking up shovel while operating, prohibition of keeping the foot under the shovel to avoid the injury.
