iModem
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iModem and is the answer not in the manual?

Questions and answers

Related Manuals for Etisalat iModem

Summary of Contents for Etisalat iModem

  • Page 1 Quick Start Guide...

  • Page 2: Getting To Know Your Device

    Getting to Know Your Device Appearance The following figure is for your reference only. *External antenna connectors (not all the devices support) Charging/micro-USB jack Indicator light Power key • Press and hold for about 3 seconds to power on/off your device. •...

  • Page 3: Indicator Lights

    Getting to Know Your Device WPS key Press and hold for 3 seconds to activate the WPS function. micro-SIM card slot and reset hole Indicator lights Indicator Status Description The battery is low. Red solid / Please blinking charge the battery. Green The battery is being Battery...
  • Page 4 Getting to Know Your Device Indicator Status Description Blue solid Wi-Fi is active. Wi-Fi Blue blinking WPS is active. Light off Wi-Fi is off. You have unread Blue solid messages. You have new Blue blinking messages. There is no unread Light off message or new message.
  • Page 5 Getting to Know Your Device Indicator Status Description Error status. Not registered to the mobile network, no micro-SIM card inserted or no network service available. Registered to the Green solid 2G/3G mobile network Network Connected to the Green 2G/3G mobile network Blinking and data is being transferred.
  • Page 6 Getting to Know Your Device Connection Scenarios The device allows multiple clients to surf on the Internet at the same time. The following figure is for your reference only. A micro-SIM card can be used to access the Internet.

  • Page 7: Installing Your Device

    Installing Your Device Open the micro-SIM card cover. NOTE: Do not remove the cover rudely, because it is connected with the device.
  • Page 8 Installing Your Device Install a micro-SIM card to the micro-SIM card slot. WARNING! Your device does not support SIM cards, nano- SIM cards or any other non-standard micro-SIM cards. To avoid damage to the device, do not use those cards or any card holders. Close the micro-SIM card cover.

  • Page 9: Connecting To Your Device

    Connecting to Your Device Using Wi-Fi Power on your device. Ensure that your computer or other client devices have enabled Wi-Fi, and search for available wireless networks NOTE: Refer to your Wi-Fi-enabled client device manual for further details on how to search for wireless networks.
  • Page 10 Connecting to Your Device NOTE: Refer to the chapter Getting to Know the Wi-Fi SSID and Password to get the default Wi-Fi SSID and password. Wait until the client device is connected to your device successfully. Using a USB Cable Connect a computer to your device with a USB cable.

  • Page 11: Configuration Page

    Launch the Internet browser and enter http://192.168.0.1 or http://imodem.Etisalat4G. com in the address bar. Enter the password to log in to the Etisalat 4G iModem configuration page. NOTE: The default password is etisalat.

  • Page 12: Accessing The Internet

    Changing the Wi-Fi SSID or Password Log in to the Etisalat 4G iModem configuration page. Select Wi-Fi Settings. Change the Network Name (SSID) or the Password in the Main SSID area. Click Apply. Accessing the Internet After a client device is successfully connected to your device, you can access the Internet in Automatic or Manual mode.
  • Page 13 Mode>Manual, and then click Apply Click to return to the home page, and then click NOTE: • To change current connection setting, please disconnect from network. • To modify the parameters of your device, log in to Etisalat 4G iModem configuration page.

  • Page 14: Configuring Your Pc

    Configuring Your PC The following procedure describes how to configure the Internet Protocol in Windows 7 for your Wi-Fi connection. Right-click Network and select Properties. Select Change adapter settings. Right-click Wireless Network Connection and select Properties. Select Internet Protocol Version 4 (TCP/ IPv4), and click Properties.

  • Page 15: Warning And Notice

    Warning and Notice To the Users • If inadequately shielded, some electronic devices, for example, the electronic system o f ve h i c l e s , m a y b e a f fe c te d b y t h e electromagnetic interference caused by the device.
  • Page 16 explosive gases or explosive products being processed. Power off the device if necessary. • Do not use electronic transmission devices in aircrafts, at petrol stations or in hospitals. Observe and obey all warning signs, and power off the device in these conditions. •...
  • Page 17 • When the device is operating, do not touch the metallic parts. Failing to do so may cause burns. • Use original accessories or accessories that are authorized. Using any unauthorized accessories may affect the performance of the device and violate the related national regulations about telecom terminals.

  • Page 18: Using Battery

    95% are recommended. Using Battery Do not change the built-in rechargeable battery in your device by yourself. The battery can only be changed by etisalat or etisalat authorized service provider. Limited Warranty This warranty does not apply to defects or errors in the product caused by: Reasonable abrasion.
  • Page 19 T h i s w a r ra n t y i s e n d u s e r s ’ s o l e re m e d y and etisalat’s sole liability for defective or nonconforming items, and is in lieu of all other...

  • Page 20: Limitation Of Liability

    Limitation of Liability etisalat shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using of this product, no matter whether or not etisalat had been advised, knew...

  • Page 21: Legal Information

    Legal information Copyright © 2016 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation.

  • Page 22: Troubleshooting

    Troubleshooting Problem Recommended Action • Install the software, The connection and run the installation between your program in the path of device and a My Computer. PC through • If the driver of your a USB cable device is abnormal, cannot be reinstall the software.
  • Page 23 Problem Recommended Action • Ensure that the Wi-Fi function is enabled. • Refresh the network list and select the The connection correct SSID. between your • Check the IP address, device and and ensure that your a client through client can automatically Wi-Fi cannot obtain an IP address.
  • Page 24 Problem Recommended Action • Ensure that your micro- SIM card is available. • Change the location The client and find a place with connected to good signal. the device • Check the settings of cannot access the WAN connection the Internet. mode.
  • Page 25 Problem Recommended Action • Enter the correct address. The default address is etisalat 4G http://192.168.0.1 iModem or http://iModem. configuration Etisalat4G.com page cannot • Use only one network be visited. adapter in your PC. • Do not use any proxy server.

  • Page 26: Getting More Help

    Getting More Help You can get help by: Sending an email to mobile@zte.com.cn • Visiting www.ztedevice.com • • Calling the service hotline: +86-755-26779999...
