Dynamode 2 PORT GIGA SWITCH User Manual

Vlan ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VLAN Ethernet Switch
User's Manual
Ver. 9.0
Dynamode Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2 PORT GIGA SWITCH and is the answer not in the manual?

Questions and answers

Summary of Contents for Dynamode 2 PORT GIGA SWITCH

  • Page 1 VLAN Ethernet Switch User’s Manual Ver. 9.0 Dynamode Ltd...

  • Page 2: Table Of Contents

    7-2-3 Overrall setting -------------------------- 7-2-4 QoS setting ------------------------------ 7-2-5 Priority Tag remove/insert ------------ 7-2-6 VLAN overall setting ----------------- 7-2-7 VLAN setting 7-2-8 IGMP snooping------------ 7-3 Security setting ------------ 7-4 Diagnostic function -------- 7-5 Reset to default configuration --------- Dynamode Ltd...

  • Page 3: Brief Introduction Of The Product

    100 meters (328ft) If the switch has a Tx fibre port, you can use long range fibre to connect the switch. The switch supports MD/MDI-X auto sense, so you can use straight cable to connect the workstation or another switch/hub. Dynamode Ltd...

  • Page 4: Connect With Other Switch/Hub

    It can analyse the target address of the dada packet to decide the forwarding destination of each packet. So the switch can significately reduce the data flow in the networking. Dynamode Ltd...

  • Page 5: Led Introduction

    No power Power on There is a device linked to Link/Act the corresponding port but no activity There is an active device Flash linked to the corresponding port 100M bps The device in 100Mbps The device in 10Mbps Dynamode Ltd...

  • Page 6: Product Specification

    7. Management and software introduction This switch support VLAN, Trunk, QoS, Ports configuration (enable/disable, auto negotiation, half/full duplex, flow control) ect. networking management functions. It can be managed by management software through serial port(RS-232) or browser. Management through console port Dynamode Ltd...
  • Page 7 ---> Hyper terminal” (Windows 98). For Windows 2000 the hyper terminal is intalled by default. 3. Input the name for the connection in the new link dialogue. 4. Set the COM port according to the PC main board ( usually COM1). Dynamode Ltd...
  • Page 8 5. Serial port settings: Bit rate: 19200bps Data location: 8 Parity check: None Stop bit: 1 Flow control: None Dynamode Ltd...
  • Page 9 If the hyper terminal interface has disorder words or no reaction, pls check the serial port property settings, and if the serial port is correctly connected or if the power of the switch is on. Input any key to enter into the main menu. See below figure: Dynamode Ltd...

  • Page 10: Status Menu

    Key explanation: Digital keys: choose the relative option; F : Refresh the current page; There are 6 options on the main menu, for details pls see below: 7-1 Status Menu See figure below: Dynamode Ltd...

  • Page 11: Overview

    Explanation: Overview: Overview the status of the switch Port Status: Show status of the ports Key “0”: return to the previous page 7-1-1 Overview See figure below: Dynamode Ltd...

  • Page 12: Port Status

    Explanation: 1. Input “E”, enter into switch name change 2. after change, press “enter” key to confirm 7-1-2 Port Status 100M ports: 1000M ports: Dynamode Ltd...

  • Page 13: Configuration Menu

    “Flow Control”: Port flow control status. Enable means open, Disable means close. “Auto Negotiation”: Port auto negotiation status. “Enable” means open, Disable means close “Trunk”: Shows if the port is in any Trunk group 7-2 Configuration Menu See figure below: Dynamode Ltd...

  • Page 14: Port Setting

    7-2-1 Port setting See figure below: Dynamode Ltd...
  • Page 15 “10M Full” means 10Mbps/Full duplex “10M Half” means 10Mbps/Half duplex “1000M Full” means 1000Mbps/Full duplex “Flow Control”: Port flow control settings “Enable” means flow control is enabled “Disable” means flow control is disabled “Tx Only” means only enable flow control for Dynamode Ltd...

  • Page 16: Port Trunking Setting

    “4Mbps”: the port can only transmission data at 4M bps bandwith “8Mbps”: the port can only transmission data at 8M bps bandwith “Tx Bandwidth”: Transmisstion bandwidth control (settings same as above) 7-2-2 Port trunking setting Port trunking is mainly used for improve the uplink Dynamode Ltd...

  • Page 17: Overrall Setting

    The assighment principal is according to the sequence of the port number averagely. Note: This switch is already preset 8 trunk group. The user can choose to enable the relative Trunk group according to actual requirement. 7-2-3 Overrall setting See below figure: Dynamode Ltd...

  • Page 18: Qos Setting

    High priority and Low priority. The dada flow with High priority has more short delay with the internal process of the switch, reduce the time waiting maximumly for some delay sensitive communication. See figure below: Dynamode Ltd...
  • Page 19 “Priority Weighted Ration (High: Low)”: The firmware preseted 4 kinds of priority, 1:0, 4:1, 8:1, 16:1 seperately. The user can set it according to their requirement. Note: The priority of static port is higher than 802.1p and OS/Diff Serv. Dynamode Ltd...

  • Page 20: Priority Tag Remove/Insert

    Ethernet), 12 bit VLAN ID(VID). 3 bit priority information is for 802.1p, VID is identifier of VLAN for 802.1Q. Since there are 12 bits for VID, so it can set 4094 VLAN. Dynamode Ltd...

  • Page 21: Vlan Overall Setting

    It will insert a tag to the ports with High priority of the 802.1Q VLAN member. “Insert Tag (all frame)”: After enable this, it will insert a tag to all ports of the 802.1Q VLAN member. 7-2-6 VLAN overall setting See figure below: Dynamode Ltd...
  • Page 22 Enable/Disable “IP Multicast Packet Inter-VLAN Leak”: Enable/Disable “802.1Q VLAN tag aware”: Enable/Disable “Ingress Rule for Acceptable frame types”: Clasify rules for received frame within one VLAN “Admit all Frames” “Admit only VLAN-Tagged Frames” “Ingress Rule Ingress Filtering”: Enable/Disable Dynamode Ltd...

  • Page 23: Vlan Setting

    Engineering department, one for Accounting department and one for Sales department. According to position levels, like one for directors, one for managers and one for other staff. According to users, like one for email users and one for multimedia users. Dynamode Ltd...
  • Page 24 1. “E” to enter into the revise mode 2. “A” to set up a VLAN group 3. After creating a Port Base VLAN, appoint the members belong to the VLAN group 4. Press “Enter” to confirm the set up. Dynamode Ltd...
  • Page 25 4. Set VLAN ID and VLAN members for the group 5. Press “Enter” to confirm the settings 6. “O” to finish and escape the set up 7. Press “Save” to save the settings （三）Delete a VLAN group See figure below: Dynamode Ltd...

  • Page 26: Igmp Snooping

    VLAN overall setting 2.If there is no VLAN setup, all the ports are in the same VLAN group. Advice: Not use Port Base VLAN and 802.1Q VLAN at the same time. 7-2-8 IGMP snooping See figure below: Dynamode Ltd...

  • Page 27: Security Setting

    “IGMP snooping”: Enable this function, it can snoop the broadcasting informtin through this 7-3 Security setting See figure below: Dynamode Ltd...

  • Page 28: Diagnostic Function

    “Authentication Key”: In the “Value” volume input 4 keys. Advice: If not necessary pls don’t change this value 7-4 Diagnostic function See figure below: “Diagnostics”: 1. To detect if any member within a Trunk Dynamode Ltd...

  • Page 29: Reset To Default Configuration

    “Load Factory Defaults”: If you choose this, the switch will ask if your confirm the choice. Choose “Y”, the switch will reset all the setting to the factory defaults. Note: This will delete all the user settings 7-6 Save configuration See figure below: Dynamode Ltd...
  • Page 30 “Save”: After the switch settings, pls choose this option to save the settings, the switch will ask if confirm the choice, “Y” to confirm, “N” to cancel. Dynamode Ltd...
