Gigabit Management Switch
Quick Installation Guide
Features:
Comply with IEEE 802.3 Ethernet、 IEEE 802.3z、 802.3x、 802.1q、 802.1p、
802.1d and 802.3ab standards
Backbone width 48G
Store-forward structure
Support 80 IEEE 802.1 Q Tag VLAN、 24 Port VLAN
8K MAC address
Each port supports MAC address learning
Port Trunk
Port Mirror
Support 802.1x pass through
Broadcasting storm control
Port security including static MAC bonding and IP address filter
Port bandwidth control
Supoort WEB and RS232(out of band) management
Support DHCP protocol
Firmware upgrade through TFTP、HTTP、XMODEM， and setting file
upload and download through TFTP、HTTP
High quality internal power supply
1U steel 19" rack mountable case design
Dynamode Ltd
Advertisement
Table of Contents
Summary of Contents for Dynamode 24 ports Giga managed switch
- Page 1 Port security including static MAC bonding and IP address filter Port bandwidth control Supoort WEB and RS232(out of band) management Support DHCP protocol Firmware upgrade through TFTP、HTTP、XMODEM， and setting file upload and download through TFTP、HTTP High quality internal power supply 1U steel 19” rack mountable case design Dynamode Ltd...
-
Page 2: Specifications
Specifications: Model 24 ports Giga managed switch Standards IEEE 802.3 Ethernet、 802.3x、 802.1Q、 802.1p、 IEEE802.1Dand 802.3ab Ports 24 1000Base-T ports 10BASE-T：Cat 3 or above UTP and STP Cable 100BASE-TX：Cat 5 UTP and STP 1000BASE-T：Cat 5 UTP and STP MAC address... - Page 3 If the attached device does not support auto negotiation or has auto- negotiation disabled, an auto sensing process is initiated to select the speed and set the duplex mode to half-duplex. Step 3 Manegement This chapter describes three manamgement methods of the Switch. ·Web-based mangagement ·Console management ·Telnet management Dynamode Ltd...
- Page 4 When the following dialog page appears, enter the default user name and passport and press Login to enter the main configuration window. NOTE: The factory-default User name is empty. Pass word is “admin ” Dynamode Ltd...
- Page 5 3. Setup the COM port properties by using the information below and click“OK”. NOTE: The console port is set at the factory for the following configuration: Baud rate: 115200 bps Data width: 8 bits Parity: none Stop bits:1 Flow Control: None Dynamode Ltd...
- Page 6 4. You should see some boot-up messages displayed within your “HyperTerminal” session. 5. At the “password” field type in “admin” and hit “ Enter” .You are now logged into the Switch’s configuration program. Dynamode Ltd...
- Page 7 NOTE: The factory-default User name is empty. Pass word is “admin” Dynamode Ltd...
