Summary of Contents for MIMO UM-760
-
Page 1: User Manual
Super Slim Foldable Design User Manual UM-760 / UM-760F UM-760R/ UM-760RF UM-760C/ UM-760CF www.multimedialink.co.kr PAGE 1 OF 22... -
Page 2: Table Of Contents
Package Contents ………………………………………... 6 Connections and Installation ………………………….. 7 Installing USB Monitor Driver ……………………..….. 8~12 MIMO Display Setting ……..……………………………. 13 Table PC Settings for Capacitive Touchscreen ……. 14 Installing Resistive Touchscreen Controller ……..15~17 System Requirements and Restrictions ……………. 18 Troubleshooting ………………………………………….. -
Page 3: Safety Instructions
USB Cable (DC 5V) only. * MIMO doesn’t require any additional power source ▪ Do not place MIMO in a location exposed to moisture, dust, smoke, water, or in a car. * Otherwise, this may result in electric shock or fire. - Page 4 - If foreign material enters the product, disconnect the USB cable and contact a Service Center. ▪ Do not install MIMO in an unstable location - Otherwise, it may fall and cause personal injury and/or damage the product. ▪ Ensure that users do not disassemble, repair or modify the product themselves - If the product needs to be repaired, contact a Service Center.
-
Page 5: Product Features
▶ USB powered monitor with Capacitive Touchscreen Panel (UM-760C, UM-760CF) ▶ Super Slim Foldable and Portable Design ▶ With only USB cable connection, a user may utilize MIMO as Multiple Input/ Output device for Video Conference, Instant Messaging, News and Stock casting. -
Page 6: Package Contents
▣ Package Contents Please make sure the following items are included with your monitor. Contact a local dealer to buy optional items. ▶ UM-760/ UM-760R / UM-760C UM-760/ UM-760R / UM-760C USB CABLE Install Disc + User Manual ▶ UM-760RF / UM-760 CF... -
Page 7: Connections And Installation
• O/S : Windows 2000 SP4/XP SP2 32bit/Vista 32bit ▶ Using the Software With only USB cable connection, a user may operate MIMO as an Extension monitor with Touchscreen Panel (UM-760R, UM-760RF, UM-760C, UM-760CF). For more detail functions and feature please refer to page 5 “Product Features”) -
Page 8: Installing Usb Monitor Driver
▣ Installing DisplayLink USB Monitor Driver This section shows you how to install the DisplayLink USB Graphics software and Touchscreen driver for MIMO device on different operating systems. [ Windows 7 to 10 operating systems ] DisplayLink software can be installed from Windows update. - Page 9 5. Connect your DisplayLink enabled device 6. Upon detection of a DisplayLink enabled device DisplayLink Graphics installs 7. You are then informed when installation of 8. Reboot your PC to complete the installation DisplayLink software has completed. [ Windows XP operating system ] DisplayLink software can be downloaded and installed from the DisplayLink website or the CD- ROM following the steps below.
- Page 10 [ Mac OS X ] from a CD- DisplayLink software can be downloaded and installed from the DisplayLink website following the steps below. Select the 'DisplayLink Software Installer' to begin installation of the DisplayLink driver on your Mac. This will run a standard Mac installer and will require a reboot once it has completed [ Ubuntu ] from a The latest software for Ubuntu 14.04.2 LTS can be downloaded from the...
- Page 11 Check the "Allow executing file as a program" box. sudo apt-get install “ 4. Install the DKMS framework from a Terminal using the command dkms” .run” “ 5. Execute the DisplayLink file using the Terminal, by cding to the directory containing the .run”...
- Page 12 [ Android ] Please download an app from the Google Play Store and install it into your Android Phone or Tablet, which will enable an external screen to be connected to your Android device, using USB. 1. Requirements Android device with an ARM based processor ...
-
Page 13: Mimo Display Setting
[ Windows 7 to 10 – Controlling the MIMO 3G Display ] 1. MIMO Display Properties Setting You can configure MIMO 3G device through the use of Windows Display Properties (WDP), which provides a simple method to attach, rotate, duplicate or extend screens as well as modify screen resolution. - Page 14 ▣ Tablet PC Settings for the use of Capacitive Touchscreen (For UM-760C, UM-760CF) This section shows you how to set the “Tablet PC Settings” to use the capacitive touchscreen for Multi-touch use on Windows 8.1/ 8/ 7. 1. Tablet PC Settings ①...
-
Page 15: Installing Resistive Touchscreen Controller
As a matter of course, it is highly recommended that any other non UPDD touch drivers be uninstalled prior to installing UPDD. It is recommended that where possible the MIMO device is connected to the system. 1. Selecting Touchscreen Driver Select the Touchscreen Driver to install and click it or select the setup.exe file and click on Setuop.exe in... - Page 16 3. Rebooting your system After complete the install, you need to reboot before you can use the MIMO enabled device. 4. Settings and Calibrations Check the monitor number of the installed MIMO at “Display Properties” Right-click and click the “Adjust settings” to run the UPDD Console on the system tray.
- Page 17 ▶ Calibration The product is with factory default calibration value. If required user may execute Touch Screen Controller Calibration as follow. Calibration is very important procedure to align coordinates of the exact touch point on screen with Windows cursor. With the calibration user may utilize Touch Screen Control without distortion. The last calibration data will be saved in the Windows system so as not to be required after reboot the system except the user rotate the screen.
-
Page 18: System Requirements And Restrictions
User may check the Operating System version by Right-click 'My Computer’ → ‘Properties’ → ‘System Properties’ 2. MIMO is a USB monitor to be recognized as a Generic USB device. Therefore system boot-up screen or DOS screen cannot be displayed properly. -
Page 19: Troubleshooting
4. Click ‘Action(A)’ -> “Add Hardware(A)”. 5. Reboot the PC. * Normal PC recognizes MIMO as a generic USB device. Frequent power on and off of the device may cause USB device error. Please refer to Microsoft customer support for USB devices’... - Page 20 Q: I cannot see DOS opening screen with MIMO when my PC is booting up. A: MIMO is a generic USB device. Since DOS doesn’t recognize USB Device while booting-up, MIMO cannot get video signal from the system.. Q: I cannot run 3D graphic game with MIMO screen.
- Page 21 Q: How can I clean the outer case/LCD Panel? A: Disconnect the USB cable and then clean the MIMO with a soft cloth, using either a cleaning solution or plain water. Do not leave any detergent or scratches on the case. Do not let any water enter the monitor.
-
Page 22: Specifications
▣ Specifications • Model Name: UM-760, UM-760R, UM-760RF, UM-760C and UM-760CF • Display Size: Diagonal 7.0 inch Active Area 153.6 mm(W) x 90.00 mm(H), • Display Resolution: WSVGA(1,024 x3(RGB)x 600) • Pixel Pitch: 0.05mm(W) x 0.15mm(H) • Response Time: 10msec •...
