Menu Item
Auto Backlight on Auto Backlight turns on the backlight soon after AC power is restored.
Turn Backlight off with Saves lamp life and energy by turning off backlights
no Source (DPMS)
DPMS Delay The amount of time the unit will wait after a source is removed, before it turns off
the backlights.
Backlight Control The method by which the backlight intensity is adjusted. Auto mode adjusts the
Mode light levels using a threshold and a light intensity sensor. Manual mode allows
the user to set the backlight intensity manually.
When Backlight Control Mode is set to Manual:
Backlight Intensity Backlight Intensity can be controlled when Backlight Control Mode is Manual. In
Auto mode, Backlight Intensity is read only.
When Backlight Control Mode is set to Auto
Ambient Light Ambient Light is the light currently in the immediate area of the Bay Cat X
Ambient Threshold Ambient Threshold is the light intensity below which the backlights go to the Low
Intensity setting.
Low Intensity Low Intensity is the backlight level (as a percent of maximum) the light will go to
when the ambient light falls below the Ambient Threshold. There is a built-in 3
minute delay before the low intensity takes effect. This keeps the backlight from
flashing between low and high intensity if the ambient light is hovering near the
threshold value.
Backlight Control Menu Options
Description Setting(s)
0 mins - 1 hr
Auto, Manual
30-100%
30-100%
97
