INSTRUCTIONS FOR
Self-Levelling
Laser Level Kit
Stock No.88640
Part No.LLK3
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.

GENERAL INFORMATION

These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LLK3 and is the answer not in the manual?

Questions and answers

Related Manuals for Draper LLK3

Summary of Contents for Draper LLK3

  • Page 1: General Information

    AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.

  • Page 2: Title Page

    Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact.

  • Page 3: Table Of Contents

    CONTENTS 2.1 CONTENTS PAGE CONTENT PAGE TITLE PAGE INTRODUCTION ....................2 REVISION HISTORY....................2 UNDERSTANDING THIS MANUAL ...............2 COPYRIGHT NOTICE....................2 CONTENTS CONTENTS ......................3 GUARANTEE GUARANTEE ......................4 INTRODUCTION SCOPE ........................5 SPECIFICATION ......................5 HEALTH & SAFETY INFORMATION GENERAL SAFETY INSTRUCTIONS FOR LASER USE..........6 TECHNICAL DESCRIPTION IDENTIFICATION ....................7 ASSEMBLY LASER LEVEL BATTERY INSTALL................8...

  • Page 4: Guarantee

    This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period.

  • Page 5: Introduction

    This manual is intended to give an overview of this machines features, functionality and safe operation. 4.2 SPECIFICATION Stock no..........................88640 Part no............................LLK3 Laser classification ........................ Class II Output power ........................<1mW Wavelength ......................... 650nM Laser accuracy ........................0.5mm/M Operating range ........................

  • Page 6: Health & Safety Information 5.1 General Safety Instructions For Laser Use

    GENERAL SAFETY INSTRUCTIONS Laser radiation. Do NOT stare into beam. Class II laser product. Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers and microscopes) with a distance of 100mm may pose an eye hazard. Viewing the laser output with certain optical instruments designed for use at a distance (for example, telescopes and binoculars) may pose an eye hazard.

  • Page 7: Technical Description

    TECHNICAL DESCRIPTION 6.1 IDENTIFICATION Laser beam aperture. Horizontal adjustment wheels (x3). ON/OFF switch (horizontal beam). Transportation lock. ON/OFF switch (vertical beam). Tripod mount/base. Power light (vertical beam). 1180mm tripod. Power light (horizontal beam). 3 x AA batteries. Angle rotation indicator. Laser enhancement goggles.

  • Page 8: Assembly

    Insert the 3 x AA batteries*, taking note of the polarity indicated inside the compartment. Replace the cover securely. * Draper Stock No.61834. NOTE: Ensure the laser beam aperture is covered to avoid FIG.1...

  • Page 9: Operation And Use

    OPERATION AND USE Remove the tripod from the case, extend all the legs and place the tripod into position. Ensure the locking screw on the side of the tripod is tight. Adjust the height of each leg individually to align the bubble on the top of the tripod as near as possible to the centre of the circle.

  • Page 10: Explanation Of Symbols

    EXPLANATION OF SYMBOLS 9.1 EXPLANATION OF SYMBOLS WEEE LASER RADIATION. Do not dispose of Waste Electrical DO NOT STARE INTO BEAM. & Electronic Equipment in with domestic rubbish 10. DISPOSAL 10.1 DISPOSAL - At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations.
  • Page 12 - Sales Desk: (023) 8049 4333 - General Enquiries: (023) 8026 6355 - Service/Warranty Repair Agent For aftersales servicing or warranty repairs, please contact the Draper Tools Helpline for details of an agent in your local area. YOUR DRAPER STOCKIST SRLJ1115...
