Installation and Operation Manual

FDDOCAPSULE

Media Streamer

Document Number:

MAN – FDDOCAPSULE

do CAPSULE

Revision Date:

Rev:

12/09/2016

Page 1 of 37

TECHNICAL SUPPORT

470-239-7421 or FDSAvionics.com

Table of Contents

Need help?

Do you have a question about the FDDOCAPSULE and is the answer not in the manual?

Questions and answers

Summary of Contents for FDS FDDOCAPSULE

Page 1 Revision Date: Rev: Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 1 of 37 Installation and Operation Manual FDDOCAPSULE Media Streamer do CAPSULE © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 2: Specifications
RTCA DO-160 Section 7, Category B – Operating Shock Section 7, Category B - Crash Safety Shock Section 26, Category C - Flammability (Vertical 12 Second Burn) TECHNICAL SUPPORT © 2016 FDS Avionics Corp. All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 3 Revision Date: Rev: Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 3 of 37 Connectivity PRODUCT INPUTS OUTPUTS COMMUNICATION     © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 4: Table Of Contents
External Media ..........................15 Moving Map ......................... 16-24 do Media Home Screen ....................... 25-26 do Movies ............................27 do Music............................28 do Photos .............................29 do Playlists ..........................30 do Search ............................31 Widgets ............................32 © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 5 Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 5 of 37 Technical Drawing....................... 33-34 Technical Support ........................35 Instructions for Continued Airworthiness ................35 Warranty ............................36 Log of Revisions .........................37 © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 6: General Information
HDMI or VGA video output. The do Capsule has the ability to interface with FDS Smart Cabin CMS to control many cabin functions. This includes cabin lights, video, audio, and more.
Page 7: Installation Instructions
There are (8) #10 mounting locations on the unit: (4) on the side flange and (4) on the bottom flange (Refer to the Technical Drawing on page 22). FDS Avionics recommends using at least (4) #10 screws on the bottom flange or the side flange.
Page 8: Vga Wiring
Also, use short heavy gauge wire and a clean tight connection for ground. It is the installer's responsibility to understand the product's requirements in order to install the product in compliance with industry standards and safety. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 9: Operation Instructions
FDS Avionics supplies a test Wi-Fi router that can be used to test the system. This router is included in the installation kit which is sold separately (P/N: FDDOCAP-ACCESSORY).
Page 10: Connecting To The Default Wireless Network
2. Turn on Wi-Fi if it is not already on. 3. Click on Wi-Fi or network menu. A list of available wireless networks should now populate. 4. Select the Wi-Fi network called “DO-WIFI”. Type in the Password “12345678”. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 11: Control Buttons
28V of power from the aircraft. When the unit is powered down, turn on the unit by pressing the power indicator button. The Reset function is for testing purposes only and is reserved for the use of FDS Avionics Corp. 2. SSD Access Panel Access to insert or remove the Solid State Drives is accomplished by turning the thumb screw located in the lower left hand corner of the access panel.
Page 12: Rear Panel View
Page 12 of 37 Rear Panel View J1 – Power Connectivity DB25 Male 28V DC Power, ARINC 429 and RS-232 for FMS/GPS Data, audio, and FDS CMS interface via CAN. USB 2.0 x (2) Black Connector These ports can be used for a USB mouse/keyboard, thumb drives, point and shoot cameras, and USB hard drives when adding additional content or configuring the moving map system.
Page 13: Navigating The Do Capsule
The do CAPSULE can be accessed a few different ways. The primary method of accessing the do CAPSULE is by downloading and using the FDS do EXPERIENCE application available on both the iOS App Store (iOS users) and the Google Play Store (Android users). For Windows laptops and Microsoft Surface users, the Windows Application can be downloaded directly from FDS (www.FDSAvionics.com) Alternatively, if the app is not available, users can type in the do...
Page 14: The Dashboard
MAN – FDDOCAPSULE Page 14 of 37 The Dashboard The Dashboard is considered the homepage of the FDS do EXPEREINCE which allows people to access Media Content, the Moving Map, bulkhead monitor control, and the Smart Cabin CMS interface (where applicable).
Page 15: Cabin Management
The Smart Cabin CMS has the ability to control many cabin functions. These include cabin lights, audio, video and more. This button and functionality is only available for customers that choose to experience the full FDS do EXPERIENCE by purchasing an FDS Smart Cabin Management System to fully integrate with the aircraft.
Page 16: Moving Map
Page 16 of 37 Moving Map (Bulkhead Operation) When the FDS do2D Moving Map starts, the application will start in an initialization mode until a valid present position is obtained from aircraft’s avionics systems. During the initialization mode, three screens will continuously cycle: do, do360, and do3D.
Page 18: Moving Map
30 knots. In this mode, there are three screens visible by default: a single map view (low zoom level), the Relative Location Indicator, and the post-flight splash page. The post-flight splash page can be customized for a fee. Contact the FDS Avionics Corp. sales department for more information.
Page 19 Page 19 of 37 Moving Map (Client Operation) The FDS Avionics do CAPSULE client application gives the user the ability to interact and explore the FDS Moving Map. Pressing the menu button in the top left hand corner brings up the navigation menu.
Page 20 In this mode, use the “bull’s-eye” button in the top right hand corner to center the view on the aircraft. When exploring the map, orange POIs with a camera icon are clickable and can be expanded for more detail. Adding custom POIs can be added for a fee. Contact the FDS Avionics Corp. sales team for more information.
Page 21 World Clock – This button takes the user to the World Clock page. This page shows 6 configurable world time zones and the local time. The user can rotate the globe to view time zones around the world. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 22 In cases where more than one do CAPSULE is installed on an aircraft the “Select Source” button can be used to switch between units. Clicking the “Select Source” button will bring up a list that displays all do CAPSULES on the network. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 23 Instruments – This page is a simulated HUD that dynamically displays the altitude, speed, destination ID, and distance to destination. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 24 Flight Data – This page shows the current flight data of the flight such as altitude, time to go, distance to go, ETA, destination name, outside air temperature, time in flight, ground speed, and heading. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved.
Page 25: Do Media Home Screen
Click on the media tile of choice see the media data. Movie Data, trailer, and reviews screen. Click Watch or the play button to play a movie Play window © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 26 Tap once on screen to pull up features in full screen mode such as slider, volume, and Full Screen Mode minimize screen © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 27: Do Movies
Movies can be sorted by using the drop- Actor/Actress, Length, Rating, and movie down sort menu in top right of interface rating in the left column of interface © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 28: Do Music
List view of music – Swap between tile view Now playing a Queen Song - Player appears and list view with purple button near top left once song has started. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 29: Do Photos
Tap on a picture to bring up a playlist button inside the tile. Double tap to pull up an enlarged Enlarged selected picture. Tap the right or left picture. arrows to move to the next photo. © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 30: Do Playlists
Type in a playlist name to create the list that media selection Type in playlist name then push green arrow Click add to playlist button © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 31: Do Search
Avengers. Hit content. return to submit your request for a search. Search results page © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 32: Widgets
MAN – FDDOCAPSULE Page 32 of 37 do WIDGETS Tap the FDS logo to see the drop-down menu for About info, Widget options, Privacy Statement, and Terms and Conditions Tap Widgets to enable and disable © 2016 FDS Avionics Corp.
Page 33: Man - Fddocapsuleb
Revision Date: Rev: Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 33 of 37 Interface Control Drawing © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 34: 2016 Fds Avionics Corp. Technical Support
Revision Date: Rev: Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 34 of 37 Interface Control Drawing © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
Page 35: Technical Support
12/09/2016 MAN – FDDOCAPSULE Page 35 of 37 Technical Support Should you have any questions concerning this product or other FDS Avionics Corp. products, please contact our Product Support representatives at (470) 239-7421. FDS Avionics Corp. 6435 Shiloh Road Alpharetta, GA 30005...
Page 36: Warranty
Limited Warranty All FDS Avionics Corp. products are warranted to be free from material or manufacturing defects for a period of 24 months from the date of shipment for General Aviation customers or 12 months from the date of shipment for Government/Special Mission customers.
Page 37: Log Of Revisions
Revision Date: Rev: Document Number: 12/09/2016 MAN – FDDOCAPSULE Page 37 of 37 Log of Revisions Date Page Description 11/03/2015 Initial Release 12/09/2016 Add moving Map, Name Changes © 2016 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
