Monoprice 21596 User Manual

Vacuum food sealer
Hide thumbs
Table of Contents

Advertisement

Quick Links

MONOPRICE
Vacuum Food Sealer
P/N 21596
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21596 and is the answer not in the manual?

Questions and answers

Related Manuals for Monoprice 21596

Summary of Contents for Monoprice 21596

  • Page 1 MONOPRICE Vacuum Food Sealer P/N 21596 User's Manual...

  • Page 2: Table Of Contents

    CONTENTS SAFETY WARNINGS AND GUIDELINES ........................3 INTRODUCTION .................................... 5 CUSTOMER SERVICE ................................6 PACKAGE CONTENTS ................................6 PRODUCT OVERVIEW ................................7 Top Panel ....................................7 Main Body ....................................8 OPERATION ..................................... 9 Creating Custom-Sized Vacuum Bags......................9 Vacuuming and Sealing a Bag ..........................10 Vacuuming an External Canister .........................

  • Page 3: Safety Warnings And Guidelines

    SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ...
  • Page 4 Do not expose this device to corrosive materials. Do not clean  using abrasive materials. Clean using a damp cloth or sponge with mild soap, if necessary. Allow it to fully dry before using it again. Allow the device to rest for at least 40 seconds between each ...

  • Page 5: Introduction

    INTRODUCTION Thank you for purchasing this Vacuum Food Sealer! Exposure to air can cause food to lose flavor and nutritional value and can lead to the growth of bacteria, mold, and yeast, which can cause the food to spoil. Vacuum sealing food removes air and seals in the flavor and freshness, allowing food to remain fresh and unspoiled for up to 7 times longer than normal.

  • Page 6: Customer Service

    CUSTOMER SERVICE The Monoprice Customer Service department is dedicated to ensuring that your ordering, purchasing, and delivery experience is second to none. If you have any problem with your order, please give us an opportunity to make it right.

  • Page 7: Product Overview

    PRODUCT OVERVIEW Top Panel Vacuum Seal Button: Vacuums and seals a bag. The sealer should be allowed to rest for at least 40 seconds between vacuuming and sealing actions. Food Button: Toggles between Dry and Moist operating modes. Mode Button: Toggles between Normal and Gentle operating modes.

  • Page 8: Main Body

    Main Body A. Cutter Knob: Cuts the internal vacuum roll to the desired length. Roll Lid: Covers the vacuum roll chamber. C. Locking Latch: Once the bag is inserted into the sealing chamber, press down on the latches on each side until each locks in place before attempting to seal and/or vacuum the bag.

  • Page 9: Operation

    G. Rubber Seal: The rubber seal and gasket combine to allow the suction necessary to vacuum air out of a bag. H. Removable Drip Tray: When vacuuming liquid or moist food, some liquid can be sucked out and into the drip tray. Remove and clean the drip tray after each use.

  • Page 10: Vacuuming And Sealing A Bag

    Press the Seal Button to seal the end of the plastic. Press the Release Buttons on the sides to release the Locking Levers. 10. Remove the sealed plastic from the sealing slot. Inspect it to make sure that the end is properly sealed. 11.

  • Page 11: Vacuuming An External Canister

    Press the Release Buttons on each side to release the Locking Latches. 10. Inspect the bag end to make sure that it is properly sealed. 11. Allow the sealer to cool for 5 minutes before attempting to seal another bag. Vacuuming an External Canister In addition to vacuum sealing a plastic storage bag, you can store food in an external container/canister and vacuum seal it.

  • Page 12: Auto Marinate Function

    Auto Marinate Function The sealer features an automatic marinate function, which works with an external marinate container to marinate food in a matter of minutes. By vacuuming the air out of the container, it opens the pores in the food and draws the marinade in.

  • Page 13: Care And Cleaning

    CARE AND CLEANING Perform the following steps to clean the vacuum sealer after use. Unplug the sealer from the AC power outlet. Press the Release Buttons on each side of the sealer to release the Locking Latches. Carefully remove the Sealing Tray from the Main Body. Carefully remove the Removable Drip Tray from the Sealing Tray.
  • Page 14 Vacuum sealing cannot replace the need to refrigerate or freeze  perishable foods. Ensure that the opening of the bag is clean and flat, with no foreign  objects or folds, which can prevent the end from sealing properly. To prevent wrinkles in the seal when sealing bulky item, stretch the ...

  • Page 15: Troubleshooting

    TROUBLESHOOTING Nothing Happens When Trying to Vacuum Seal Check that the power cord is plugged into an AC power outlet.  Ensure that the power cord is not damaged.  Test the AC outlet to ensure it is live by plugging in another device, ...

  • Page 16: Storage Guide

    STORAGE GUIDE Vacuum sealing allows you to keep food fresh for longer periods of time. The following tables are a comparative guide to the amount of time specific foods can be stored in different environments, with and without vacuum sealing. Refrigerated (+41°...

  • Page 17: Frozen (+0° ±3.5°F)

    8-10 months 8-24 months TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates.

  • Page 18: Specifications

    (2) this device must accept any interference received, including interference that may cause undesired operation. Modifying the equipment without Monoprice’s authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense.

  • Page 19: Notice For Industry Canada

    radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
