Summary of Contents for TORAIZ AS-1

  • Page 1 TORAIZ AS-1 SoundEditor LE User Guide...

  • Page 2: Table Of Contents

    2. Starting Up 2.1 AS-1 Setup ………………………………………………………………………………………………… 2.2 Getting Connected ………………………………………………………………………… 2.3 The MIDI Setup …………………………………………………………………………………… 2.4 Getting Banks from the AS-1 ………………………………………………………………………… 3. Editing Program 3.1 Adjusting Parameters …………………………………………………………………………………… 3.2 Editing　Sequencer …………………………………………………………………………………… 3.3 Writing Program to the AS-1 …………………………………………………………………………...

  • Page 3: Introduction

    - Send banks to AS-1 and save/load banks to computer - Change AS-1 GLOBAL SETTING We hope you enjoy using SoundEditor for your AS-1 ANALOG SYNTHESIZER! 1.1 About This Manual This manual is a simple manual for the SoundEditor LE version.

  • Page 4: Starting Up

    13 MIDI Out/Thru : Out 2.2 Getting Connected Connect the AS-1 to your computer by the USB cable or the MIDI interface. If you are using the MIDI interface, it must connect with both MIDI In and MIDI Out connectors.

  • Page 5: Getting Banks From The

    TORAIZ AS-1 SoundEditor In the MIDI Setup window, select the MIDI IN and OUT ports o which the AS-1 is connected. Set the MIDI Channel to match the MIDI channel on the AS-1. Once the proper ports and MIDI channel are selected, the screen below should appear.

  • Page 6: Editing Program

    3. Editing Program You can edit the program that is shown in the Program Name Display. A different program can be selected by using the PROGRAM knob on the AS-1 or in the Banks window in SoundEditor. 3.1 Adjusting Parameters Select [VOICE] to display the Parameters window.

  • Page 7: Editing　Sequencer

    TORAIZ AS-1 SoundEditor In [Preferences] in the File menu, you can change how the knob controls and mouse wheel behave by adjusting the values. After a parameter is changed, you can select [Undo] or [Redo] in the Edit menu. 3.2 Editing　Sequencer...
  • Page 8 TORAIZ AS-1 SoundEditor a) Note : Right-click to insert a note. Double-click to delete a note (insert a rest). b) Velocity : Click and drag to adjust the velocity. When set to 0, a rest is added. c) Tie : Tie is set when the right edge of a note is dragged, or when the checkbox is set to ON.

  • Page 9: Writing Program To The

    3.3 Writing Program to the AS-1 After changing the parameters or sequence pattern, make sure to select [Write Program] in the Edit menu to save the changes to the AS-1. This is the equivalent to the WRITE function (SHIFT+GLOBAL) on the AS-1.

  • Page 10: Editing Banks

    TORAIZ AS-1 SoundEditor 4. Editing Banks Select [BANKS] to display the Banks window. 4.1 Copying Program between Banks You can use any of the methods below to replace a program with another program from a different bank. a) Select [Copy Program] in the Edit menu to copy a program, then select [Paste Program]　to paste it over another program.

  • Page 11: Transmitting Banks To The

    4.2 Transmitting Banks to the AS-1 Click the MIDI menu and select [Transmit Bank] to send all programs in the specified SoundEditor bank to the AS-1. Please note that when [Transmit Bank] is performed, all programs in the specified AS-1 bank　are overwritten.

  • Page 12: Saving Banks To The Computer

    TORAIZ AS-1 SoundEditor 4.4 Saving Banks to the Computer - To save the data of a specific user bank to the computer, perform the following operation: a) Select [Save Program Bank] in the File menu and specify which bank to save.

  • Page 13: Loading Banks From The Computer

    TORAIZ AS-1 SoundEditor 4.5 Loading Banks from the Computer - To load bank data from the computer to a specific user bank, perform either one of the two operations below. a) Select [Load Program Bank to] in the File menu, and specify the bank in which to load the bank data.

  • Page 14: Additional Information

    5. Additional information 5.1 Troubleshooting - If the AS-1 and SoundEditor are connected but do not operate properly, then check that the AS-1 GLOBAL SETTING is configured as described in "2.1 AS-1 Setup". - If the connection between the AS-1 and SoundEditor is interrupted due to reasons such as a cable being plugged or unplugged, then: Select [MIDI Setup] in the MIDI menu, and specify the AS-1 again.

  • Page 15: Midi Setup For Use With Other Midi Sequencer (Windows Pc)

    Driver Below is an excample of a connection procedure. 1 Launch the virtual MIDI driver on the computer. 2 Turn ON the AS-1. 3 Launch SoundEditor and check that the connection status is ON-LINE. 4 Launch the MIDI sequencer. 5 In SoundEditor, click the MIDI menu, select [MIDI Setup], and configure the MIDI PORTS settings below.
  • Page 16 TORAIZ AS-1 SoundEditor Although the SoundEditor connection status is displayed as OFF-LINE, you can continue configuring the settings. 5 Configure the MIDI IN/OUT settings below for the MIDI sequencer. MIDI IN PORT : Virtual MIDI port MIDI OUT PORT : AS-1 As an example, when using with Ableton Live: - Configure the MIDI settings in Preferences.
