Summary of Contents for Satel GPRS-T2
- Page 1 GPRS/SMS Reporting Module GPRS-T2 Program version 2.01 gprs-t2_en 11/11 SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND tel. + 48 58 320 94 00 info@satel.pl www.satel.eu...
- Page 2 The latest EC declaration of conformity and product certificates can be downloaded from our website www.satel.eu SATEL's goal is to continually improve the quality of its products, which may result in alterations of their technical specifications and firmware. Current information on the introduced modifications is available on our website.
-
Page 3: Module Features
SATEL GPRS-T2 The GPRS-T2 module is a device dedicated for use in intruder alarm systems for the purpose of reporting and messaging via the GSM networks. The main task of the module is monitoring the status of inputs. A change of the input status results in sending event codes to the monitoring stations or notifying selected telephone numbers by means of SMS message or CLIP service. - Page 4 GPRS-T2 SATEL • Capability to automatically replace the GPRS transmission with SMS message, if there are problems with GPRS transmission. • Encrypted transmission of events sent with the use of GPRS technology. • Notifying of a change in zone status by means of: –...
- Page 5 (see: Fig. 3). 3 - RS-232 port (TTL standard) enabling the module to be connected to the PC computer (connection can be made with cables included in the set manufactured by SATEL and designated DB9FC/RJ-KPL).
-
Page 6: Installation
All electrical connections may only be made with disconnected power supply. It is not recommended to power up the device with disconnected antenna. The GPRS-T2 module should be installed indoors, in spaces with normal air humidity. When selecting the installation place, take into consideration that thick walls, metal partitions, etc. - Page 7 SATEL GPRS-T2 3. Connect the wire of transformer secondary winding, from which AC voltage is supplied, to the module power supply unit to the AC terminal (see Fig. 4). 4. Connect the device to be controlled by the module to the relay output terminals.
- Page 8 GPRS-T2 SATEL Fig. 6. GPRS-T2 module in housing, secured with a plastic strap. 4. P ROGRAMMING AND CONFIGURING THE MODULE The GPRS-S program is used for programming and configuring the module. The program is delivered free of charge with the device. Communication between the program and the module can be effected locally or remotely.
- Page 9 "p" stands for the number of network port through which communication with the GPRS-S program is to be effected). The module will connect to the computer whose address was given in the SMS message. 4.3 D ESCRIPTION OF THE PROGRAM 4.3.1 M AIN MENU Fig. 7. Main menu of GPRS-T2 program.
- Page 10 GPRS-T2 SATEL Explanations for Figure 7: - Read from file – button enables loading configuration data from file. - Write to file – button enables saving configuration data to file. - Read – button enables reading data from the module.
- Page 11 Fig. 8. "GSM telephone, Monitoring stations" tab. Programming GPRS-T2 identifier – a sequence of 1 to 8 alphanumeric characters to identify the module. Communication between the program and the module is only possible when the identifier entered in this field is consistent with that stored in the module. No identifier is preprogrammed in the module with factory default settings.
- Page 12 GPRS-T2 SATEL SMS center number – telephone number of the Short Message Service Center, which delivers SMS messages. Entering the number is necessary if the module is to send SMS messages. The number stored in the module must be suitable for the network in which the GSM telephone is working (depending on the SIM card installed in the module).
- Page 13 SATEL GPRS-T2 Tel. number (SMS) – GSM telephone number used by the monitoring station for receiving SMS messages. Must be preceded by the country code. Address (GPRS) – address of the monitoring station. It can be entered in the IP address form (4 decimal numbers separated by dots) or as a name.
- Page 14 GPRS-T2 SATEL Fig. 9. "Test transmissions, Control" tab. SMS test transmission – enter in this field the SMS message body which will be sent as the module test transmission to the selected telephone numbers. Note: If you have defined the time period after which the test transmission is to be sent, and the "SMS test transmission"...
- Page 15 SATEL GPRS-T2 Note: The test transmission will be sent as an event, if the following parameters and options are programmed for the monitoring station: – GPRS reporting (see section "Starting GPRS reporting") or SMS reporting (see section "Starting SMS reporting") is activated, –...
- Page 16 GPRS-T2 SATEL Send SMS with module status to CLIP – if this option is enabled, it is possible to obtain information about the module status with the use of CLIP service. Call the module telephone number and after hearing the dialing tone, hang up – the module will identify...
- Page 17 SATEL GPRS-T2 containing information on the module status to the telephone number from which the control message was sent (see: "Send SMS with module status to CLIP" option). Output Turn on – enter in this field the SMS message content that will be sent to the module telephone number in order to activate the relay output.
- Page 18 GPRS-T2 SATEL The defined time makes it possible to reduce the number of sent transmissions. Values from the 0 to 255 seconds range can be programmed. Fig. 10. Table "Inputs" and "CLIP/SMS messaging" in "Inputs" tab. Blocking – select this field if the input is to serve as a blocking input, i.e. its violation will result in blocking other inputs of the module.
- Page 19 SATEL GPRS-T2 means that the voltage threshold is not controlled. The maximum value that can be programmed is 16.56 V. Fig. 11. Operation manner of analog input. 0 – no violation. 1 – violation. L-T – voltage level L minus tolerance. L – lower voltage level. L+T – voltage level L plus tolerance. H-T – voltage level H minus tolerance.
- Page 20 GPRS-T2 SATEL CLIP T1 – T4 – select the fields of telephones (see: numbers in the list "Telephone numbers for messaging and test transmissions", programmed in the "GSM telephone, Monitoring stations" tab), which will be informed about a change of input status by using the CLIP service.
- Page 21 SATEL GPRS-T2 You can also make use of the code editor. To open the code editor, click on the button designated with three dots, available in the "EVENT" filed. Violation/pass Partition / Restore Partition – partition number which will be sent in the event code.
- Page 22 GPRS-T2 SATEL 4.5 S TARTING REPORTING 1. Enter the telephone number of Short Message Service Center ("SMS center number" field in the "GSM telephone, Monitoring stations" tab). 2. Configure parameters of the monitoring station(s) ("GSM telephone, Monitoring stations" tab): – select the "SMS" field;...
-
Page 23: Restoring Factory Default Settings
SATEL GPRS-T2 – enter the content of SMS message that will be sent when the input is restored to its normal status ("Restore" field). 6. In case of the analog inputs, the "Add input voltage value to message" option can be additionally enabled ("Inputs"... -
Page 24: Specifications
GPRS-T2 SATEL 6. S PECIFICATIONS Supply voltage ....................12 V DC ±15% Current consumption, standby ..................75 mA Current consumption, max..................... 400 mA Power supply required output current, min................2 A Permissible voltage at AC input ................up to 25 V AC Current-carrying capacity, FT output ................50 mA...
