- Page 1 RKD-DS-17-HDXD 1U Dual Slide LCD Console Drawer Options : - SDI - AV / HDMI / Audio - DC power User Manual 17” Ultra High Resolution LCD 1920 x 1200 RKD-DS-17-HDXD www.kvmswitchtech.com...
- Page 2 Re-position or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. RKD-DS-17-HDXD www.kvmswitchtech.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > RKD-DS-17-HDXD Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 5 Connection P.6 - 7 < Part. 2 > Specifications / OSD Product Specifications P.8 - 9 Keyboard / Mouse Specifications P.10 - 12 On-screen Display Operation ( OSD ) P.13 - 14... - Page 4 DB-15 KVM -MIP813 -MIP1613 -MIP824 -MIP1624 -M802 -M1602 -M803 -M1603 -M804 -M1604 Combo Local Remote 8-port 16-port 32-port DB-15 KVM -IP802 -IP1602 -802 -1602 -S801 -S1601 DVI-D Local Remote 12-port -1201D PS/2 Local Remote 8-port DB-15 KVM -801 RKD-DS-17-HDXD www.kvmswitchtech.com...
- Page 5 Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your microfiber cloth first, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. RKD-DS-17-HDXD www.kvmswitchtech.com...
-
Page 6: Package Content
< Part 1 > < 1.1 > Package Content RKD-DS-17-HDXD unit X 1 - KVM-KVM-CX-6 6ft DVI-D console cable X 1 ( Alternative : KVM-CB-6 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 7 < 1.2 > Dimension RKD-DS-17-HDXD Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 650 x 44 mm 595 x 860 x 140 mm 12 kg 18 kg RKD-DS-17-HDXD 23.4 x 33.9 x 5.5”...
-
Page 8: Installation
< 1.3 > Installation - How to install Installation Slides RKD-DS-17-HDXD www.kvmswitchtech.com... - Page 9 < 1.3 > Installation - How to Use the Dual Slides RKD-DS-17-HDXD Press the handle button and gently slide out the drawer. Flip up the LCD to a suitable angle. Operate the LCD console drawer. RKD-DS-17-HDXD www.kvmswitchtech.com...
- Page 10 < 1.3 > Installation - How to Use the Dual Slides Flip down the front panel. Press the handle button and gently push back the drawer into the rack. Return the LCD console drawer to park position. RKD-DS-17-HDXD www.kvmswitchtech.com...
-
Page 11: Connection
< 1.4 > Connection to via KVM-CX-6 USB Server RKD-DS-17-HDXD cable LCD Console Drawer Power DVI-D KVM-CX-6 DVI-D console cable U S B DVI-D USB server < 1.4 > Connection to via KVM-CX-6 external KVM cable LCD Console Drawer Power... - Page 12 Before attempting to connect anything to the LCD console drawer, we suggest turning off the power to all devices. Apply power to connected devices again only after the LCD console drawer is receiving power. The company is not responsible for damage caused in this way. RKD-DS-17-HDXD www.kvmswitchtech.com...
-
Page 13: Product Specifications
< Part 2 > < 2.1 > Product Specifications RKD-DS-17-HDXD Panel Size ( diagonal ) 17.1-inch Widescreen TFT color LCD Display pixel ( dots x lines ) Panel 1920 x 1200 Brightness ( typ. ) Contrast Ratio ( typ. ) - Page 14 70 / 75Hz 848 x 480 x 60Hz 800 x 600 x 60 / 72 / 75Hz 720 x 400 x 70Hz 640 x 480 x 60 / 72 / 75Hz 640 x 400 x 70Hz 640 x 350 x 70Hz RKD-DS-17-HDXD www.kvmswitchtech.com...
-
Page 15: Keyboard / Mouse Specifications
< 2.2 > Keyboard / Mouse Specifications RKD-DS-17-HDXD G keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time Software support MS Windows 7 / 2008 / 2003... - Page 16 How to Use "MAC" Keyboard Keyboard Features Fast-forward Decrease display brightness Mute sound Increase display brightness Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts. Dashboard Increase volume Rewind Eject disc Command Play / Pause RKD-DS-17-HDXD P.11 www.kvmswitchtech.com...
- Page 17 < 2.2 > SUN Keyboard / Mouse Options RKD-DS-17-HDXD S keyboard integrated with touchpad S keyboard integrated with touchpad / trackball Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help 104 key notepad keyboard with full numerical pad and SUN function ...
-
Page 18: On-Screen Display Operation ( Osd )
Picture size : Adjust the image size Color temp : Standard / Cool / Warm / User to choose Noise reduce : Reduce the noise of the image Sharpness : Adjust the image from weak to sharp RKD-DS-17-HDXD P.13 www.kvmswitchtech.com... - Page 19 Adjust picture in picture setting PIP position : Enter into PIP position PIP source : Enter into the Sub source and sound source System reset : Return the adjustment back to factory setting Information : Select for Help RKD-DS-17-HDXD P.14 www.kvmswitchtech.com...
- Page 20 48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized Video HD-SDI 48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized SD-SDI / Asynchronized Video Max. Transmission Distance 3G-SDI 150m at 2.97Gb/s 75 ohm coaxial cable HD-SDI 250m at 1.485Gb/s SD-SDI 480m at 270Mb/s RKD-DS-17-HDXD P.15 www.kvmswitchtech.com...
- Page 21 < 3.2 > Options : RKD-DS-17-HDXD - HDMI ( HDMI 1.1, CEA-861-D ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) For dual slide 1U / 2U LCD console drawer, the user can only select one of the above four options.
- Page 22 50 mA - Full load 4950 mA 2450 mA 1220 mA Output rating Output voltage: 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A Efficiency DC power Option excludes 1 x power cord and 1 x AC power adapter RKD-DS-17-HDXD P.17 www.kvmswitchtech.com...
- Page 24 The company reserves the right to modify product Specifications without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. RKD-DS-17-HDXD www.kvmswitchtech.com...
