Apel BR–5000N Operation Manual

Bilirubin meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

______________________________________________________________________________________
All rights are reserved. This material may not be reproduced or copied, in whole or part, without the written permission of APEL CO., LTD.
OPERATION MANUAL
BILIRUBIN METER
BR – 5000N
IMPORTANT!
READ THIS OPERATION MANUAL!
*Prior to operation, please read this manual
carefully and retain it for future reference.
Failure to read, understand and follow the
instructions in this manual may result in
damage to the unit, injury to operating
personnel and/or poor equipment
performance.
BR5N-1-OMA-103a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BR–5000N and is the answer not in the manual?

Questions and answers

Summary of Contents for Apel BR–5000N

  • Page 1 All rights are reserved. This material may not be reproduced or copied, in whole or part, without the written permission of APEL CO., LTD. BR5N-1-OMA-103a...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Section 1 - Introduction 1.1 Introduction --------------------------------------------------- 1.2 Features ------------------------------------------------------ 1.3 Important Safety Instruction ------------------------------ Section 2 – Contents of the unit 2.1 Description of the unit -------------------------------------- 2.2 Control panel Keys, Display and Indicator -------------- Section 3 – Operation procedure 3.1 Preparation ---------------------------------------------------- 3.2 Taking blood sample ----------------------------------------- 3.3 Measurement of the specimen ------------------------------...

  • Page 3: Section 1 - Introduction

    Section 1 - Introduction 1.1 Introduction Congratulations on purchasing an APEL product. It’s an important and very smart decision that’s sure to reward you for many years to come. To ensure that you take full advantage of our Bilirubin meter, BR-5000N’s offered features and warranty benefits, be sure to carefully read and fully comprehend this Operation Manual.
  • Page 4 5. The print out by the printer The measurement data can be printed out by the option printer. (The measurement data are memorized up to 100 samples in maximum while the power switch in being turned on.) The printer connector is based on Centronics standard. 6.

  • Page 5: Important Safety Instruction

    Important Safety Instruction When utilizing your BR-5000N, always take basic safety precautions and warnings, in order to avoid damage to your unit, property and/or personal injury, which may result from misusage, exposure to fire or electric shock. Important warnings and safety precautions are as follows: 1.
  • Page 6 13. Do not allow anything to rest on the power cord. Do not locate this product where the power cord may trip any person or object. 14. To keep the accuracy of this instrument, calibration should be done periodically and after a period of long storage prior to operation. 15.

  • Page 7: Section 2 - Contents Of The Unit

    Section 2 - Contents of the unit Description of the unit Unpacking BR-5000N: Open the carton from the top and carefully unpack the BR-5000N. Do not discard the packing materials. Save all the packing material in the carton, in case the unit may need to be repacked and returned to your supplier for maintenance, repair, or service work.

  • Page 8: Control Panel Keys, Display And Indicator

    Control panel Keys, Display and Indicator μmol/dl mg/dl A～Ｚ PRINT ７ ８ EXIT ZERO ４ ５ ６ START ３ ０ ２ Control Panel FUSE FUSE Fig.１ １ １ １ 1. LCD Display 7. Power switch 2. Pilot lamp 8. Fuse holder 3.

  • Page 9: Section 3 - Operation Procedure

    Section 3 – Operation Procedure Preparation 1. Make sure that the power cord is plugged to the electric wall outlet and turn on the Power switch. Then, you can see the pilot lamp is lit and Warming Up 900 Warming Up 900 Warming Up 900 Warming Up 900 the number of seconds are counted down on the LCD display.
  • Page 10 centrifugally separated into serum and blood cells, as shown in Figure 4. (Make sure that there is at least 15mm of serum part. A serum gauge is provided on the surface of BR-5000N) Capillary tube Capillary tube Capillary tube Blood Putty Blood Top of the big toe, or heel of foot...

  • Page 11: Measurement Of The Specimen

    Measurement of the specimen 3.3.1 Normal measurement [ No. 0 ] Normal measurement is used only for temporary measurement. The data is not stored. 1. Take the capillary tube containing distilled water out of the capillary tube holder, insert the specimen tube that has been through centrifugal treatment. The serum part must fall within the same height as the part of the slit of cell holder.（Fig.4-2）...
  • Page 12 5. The sample No.( SN.XXX SN.XXX) shown on the LCD display is automatically SN.XXX SN.XXX incremented(+1) for the next measurement. 6. When the total measurement numbers reach 100, and one more measurement is tried to be executed, the alarm buzzer sounds and * Memory Full * Memory Full * Memory Full...

  • Page 13: Setting The Name Or Id Number Of The Test

    Setting the ID number 1. Press “No” key, and set the ID number (1 ～ 25) No. 5 No. 5 No. 5 No. 5 ID- - - - E005 E005 E005 E005 SN.001 SN.001 SN.001 SN.001 Ready Ready Ready Ready 2.
  • Page 14 3.5.2 The setting of Printer Choose whether Printer Interface is active or not. . 1. Press “SET”, and then “4” key. Set- - - - 4 4 4 4 2. Choose the condition with [1]/[2] keys. Printer Use Printer Use Printer Use Printer Use On : Printer effective...
  • Page 15 3.5.5 The setting of the Baud rate for the RS-232C Baud rate of RS-232C output can be set. 1. Press “SET”. and then “7” key. Set- - - - 7 7 7 7 2. Choose the condition with [1]/[2]/[3] keys. Baud rate Baud rate Baud rate...

  • Page 16: How To Use Serum Gauge

    How to use the Serum gauge. Capillary tube containing the sample can be inserted correctly without pulling out the capillary tube holder, if the serum gauge is used as follows. 1. Put the capillary tube treated centrifugally on the serum gauge. The border line between blood corpuscles and serum must be left of the line “A”...

  • Page 17: Section 4 - Maintenance And Inspection

    Section 4 – Maintenance and inspection 4.1 Adjustment with standard solution The standard value that is set in the equipment will fluctuate corresponding to deterioration of the light bulb, so to keep the accuracy of the instrument, confirm the value every 1 month (assuming 2 hours of usage/day) or after the light bulb is replaced or the instrument is not used for a long interval.

  • Page 18: Indication Of Alarms

    4.2 Indication of alarms When an alarm is given as the buzzer sounds 3 times and display value turned on and off, it is because of one or more of following reasons. 1. The high concentration of the specimen. (Bilirubin that exceeds a measurement value of 30mg/㎗.) 2.

  • Page 19: Light Bulb Replacement

    4.4 Light bulb replacement Caution : Prior to replacing the light bulb, be sure to turn off the power switch, unplug the power cord from the wall outlet, and make sure that the bulb is not hot. Remove a decorative screw and the cover from the bottom of the main unit. （fig5）...

  • Page 20: Section 5 - Specifications

    Section 5 – Specifications 5.1 Specifications : 0 ～30mg/㎗（Total bilirubin） Range of Measurement : 0 ～ 513.09 μmol/ℓ : ±５％ Measurement accuracy : 0 ～250mg/㎗ Hbcv Correcting Hemolysis Measuring method : Dual wavelength differential system (461nm,551nm） : 50 ～ 60 ㎕ Sample volume Sample container : Hematocrit capillary tube (Heparinized)
