J60 Thin Client User Guide Version 1.7 ShenZhen JIEYUN Technology Co., Ltd. （www.jieyung.com） Updated at 2014-06-28... - Page 2 Copyright @ 2013 JIEYUN Technology Co., Ltd. All rights reserved. Please do not copy, extract or publish any content of this document without the owner’s permission. The copy rights of the third party logo mentioned in this document belong to their owners.
-
Page 3: Table Of Contents
Contents INTRODUCTION ................................. 4 INTERFACES AND MOUNTING OPTIONS ......................4 SPECIFICATIONS ............................... 5 CONNECTION DIAGRAM ............................6 SYSTEM GUIDE ................................6 ............................... 6 CREEN ............................7 ETWORK NITIALIZATION ..............................7 ONNECTING ..............................8 ONTROL ENTRE ............................9 ONNECTION ETTINGS ..........................11 ESKPOOL ONNECTION RDP C... -
Page 4: Introduction
Introduction J60 thin client is based-on ARM cortex A9 4-cores 1.6GHz CPU and 1GB DDR3 memory. In additional, it is powered by deeply-optimized linux OS. The main features include： Up to 1080p resolution and 32bpp color depth. Small and exquisite without fan. -
Page 5: Specifications
Specifications System Description ARM Cortex A9 1.6GHz, 4 Cores DDR3：1GB Memory Flash NAND Flash： 8GB Network 10/100M based-T RJ45 ethernet port WiFi (Optional) WIFI 802.11B/G/N (optional) Audio Input MIC input, 3.5mm mini jack Audio Output Audio output, 3.5mm mini jack 4x USB ports Debug Port Mini USB port for debug... -
Page 6: Connection Diagram
Connection Diagram FIG.4-1 Connecting J60 thin client to a remote desktop server Notice, please make sure to use the matched power adapter, any mismatching maybe destroy the device. And if the monitor provides a HDMI or DVI interface, the HDMI cable or HDMI to DVI converter could take the place of VGA cable. -
Page 7: Network Initialization
Note, If the monitor cannot support the device’s resolution output, it maybe display a black screen, please refer to the chapter 7 to restore the default resolution setting. 5.2 Network Initialization At the network initialization phase, show as FIG.5-2, the device will check the local network connection and the IP settings. -
Page 8: Control Centre
FIG.5-3b Starting Auto Connecting When the auto connecting is failed, the device will retry after 15-second countdown, unless you cancel it, show as FIG.5-3c. FIG.5-3c Auto Connecting Retry 5.4 Control Centre As FIG.5-4a shows, administrator password should be provided before enter the control centre. -
Page 9: Connection Settings
FIG.5-4b Control Centre As FIG.5-4b shows, control centre is divided into three function zones: Main Menu List Setting Window Status Bar Main menu include the following menus: Connection Settings: Management the remote desktop connections Display Properties：Resolution and language settings ... - Page 10 FIG.5-5a Connection Settings Window Connection Type J60 thin client supports three kinds of connection and two kinds of desktop protocol: Deskpool Connection: Deskpool login-in connection configuration, adopt Microsoft RDP client with RemoteFX graphic feature enabled. Microsoft RDP Connection：Microsoft remote desktop server accessing configuration，adopt Microsoft RDP client with RemoteFX graphic feature...
-
Page 11: Add Deskpool Connection
5.6 Add Deskpool Connection Click【Add Deskpool Connection】, popup the “Add Deskpool Connection” dialog as FIG.5-6 shows: FIG.5-6 Add Deskpool Connection Input the following information before click 【OK】 button: 【Connection Name】: Name of this connection 【Server Address】: Address of remote deskpool server If you check the 【Remember Account】... - Page 12 【Password】 : Password of the remote desktop user. 【Domain】：Domain name. If no domain server, keep empty. FIG.5-7a Add Microsoft RDP Connection FIG.5-7b show the options for Microsoft RDP connection, include the personalized options and the auto-run program. FIG.5-7b Microsoft RDP Options Page 12 of 25...
-
Page 13: Add Spice Connection
Note, the RemoteFX option can only be enabled for Hyper-V remote desktop platform and the windows guest OS must be Windows 7 SP1 or later, otherwise, the option will be invalid. In addition, when the RemoteFX successfully enabled, it will adopt the 32bpp color depth automatically. -
Page 14: Add Ovirt Connection
FIG.5-8 Add SPICE Connection Input the following information before click 【OK】 button: 【Connection Name】: Name of this connection. 【Server Address】: Address of remote SPICE server. 【Port】: Port of the SPICE connection, it will be discarded as the security connection enabled. 【Password】: Password to login into SPICE server. -
Page 15: Display Properties
Note, Generally, the time settings of the thin client device should be consistent with the oVirt server. FIG.5-9 Add oVirt Connection 5.10 Display Properties Click 【Display Properties】menu, enter the display properties window shown as FIG.5- 10a. FIG.5-10a Display Properties Resolution Setting Select a resolution at 【Resolution】list box, and click 【Save】... -
Page 16: Network Settings
FIG.5-10b Notification to Change Resolution Click the 【Confirm】 button at FIG.5-10b to apply the new resolution, the device will auto reboot to apply it. When it reboot up, a confirm dialog will be shown as FIG.5-10c, the new resolution must be accepted before the 15-second timeout, Otherwise, the system will give up the new resolution setting and reboot to restore the original setting. - Page 17 FIG.5-11a Wired Network Settings Wired network settings Two kinds of settings for wired network parameters 1）DHCP mode In DHCP mode, the network parameters will be dynamically acquired from DHCP server, you can click 【Refresh】 button to refresh them. 2）Static IP mode In static IP mode, you have to input the IP address, subnet mask, gateway IP, DNS 1 and DNS 2 IP.
-
Page 18: Network Diagnosis
FIG.5-11b PPPoE Settings 5.12 Network Diagnosis Click 【Network Diagnosis 】menu, enter the network diagnosis window shown as FIG.5-12. FIG.5-12 Network Diagnosis In the <Network Diagnosis> window, You can check whether the network connection or destination server is available with ping operation, in additional, the parameters of ping command could be adjusted. - Page 19 Click 【System】menu, enter the system window shown as FIG.5-13a. FIG.5-13a System Information System Information The system information includes the following entries:【System Name】,【Product Name】,【Product Key】,【Disk Capacity】,【Memory Capacity】,【CPU Info】, 【Wired NIC】,【Wireless NIC】,【Image Release Time】. Software Information The software information includes the following entries:【Operation System】,【RDP Protocol】,【SPICE】,【Deskpool VDI Agent】.
- Page 20 FIG.5-13b Voice Setting Click 【SPICE】 button, enter the SPICE certification management window shown as FIG.5-13c. SPICE certificate is used for SPICE security connection.You can download SPICE certificate to the local device. The downloaded certificate will be listed and could be deleted by the 【Delete】...
- Page 21 FIG.5-13d Operations Restart System Click【Restart】 button and confirm this operation, the device will reboot automatically. System Upgrade The procedure to upgrade the system firmware: Phase I, prepares to upgrade: 1) Download upgrade package from www.jieyung.com (update.jytc); 2) Prepare a USB storage with FAT format; 3) Copy the update.jytc file to root directory of the USB storage ;...
- Page 22 Export Log Click 【Export Log】 to export the system log with the following steps: 1) Insert a FAT formatted USB storage to a USB port. 2) In <System> window, click 【Export Log】 button and confirm to export the log; 3) Unplug the USB storage, there will be a latest log file at root directory named system.tar.gz.
-
Page 23: Restore Factory Default Settings
FIG.5-13f Time Settings Restore Factory Default Settings To restore the factory default settings will clear user configuration and system log, There are three steps to restore factory default setting: Step 1: Power on the device and cancel auto connecting; Step 2: Press【Ctrl+Alt+Shift+F2】; Step 3: Click 【Confirm】... -
Page 24: How To Fix Rdp Failure
Step 3: Waiting for reboot and check the new resolution. 7.2 How to fix RDP failure Check network: diagnose the connection between thin client and windows server. Check the server side settings: check the remote desktop settings and firewall settings, for the windows xp server, the local security strategy should be classic mode. - Page 25 4. In the Flash section there should be 2 or 3 different versions of flash listed. If the flash section only has one flash file listed, click here to go to the Adobe website and download and install Adobe Flash Plugin for non-Internet explorer browsers.
