JOHN DEERE
X465, X475, X485, X495, X575, X585 and X595
X700 SERIES
(X700, X720, X720se, X724, X728, X728se, X729, X740, X744, X748, X748se, X749)
CAB MOUNTING INSTRUCTIONS
A-11271
Manufactured by:
BOX 70 • LITCHFIELD, MINNESOTA 55355-0070
Phone: (320) 693-3221
Fax: (320) 693-7252
1-800-222-5463
Website: www.800cabline.com
05-10408
November 21, 2006
Advertisement
Summary of Contents for CozyCab A-11271
- Page 1 X465, X475, X485, X495, X575, X585 and X595 X700 SERIES (X700, X720, X720se, X724, X728, X728se, X729, X740, X744, X748, X748se, X749) CAB MOUNTING INSTRUCTIONS A-11271 Manufactured by: BOX 70 • LITCHFIELD, MINNESOTA 55355-0070 Phone: (320) 693-3221 Fax: (320) 693-7252 1-800-222-5463 Website: www.800cabline.com...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Read operator’s manual. Be thoroughly familiar with the controls, capabilities, and proper use of the equipment. NEVER ALLOW ANY RIDERS. Thoroughly inspect cab mounting periodically. Stay alert for hidden hazards and traffic. Avoid sudden starts, excessive speeds, and sudden stops when operating on hillside, rough ground and most off-the-road operations. - Page 3 John Deere X Series CAB MOUNTING INSTRUCTIONS Preparation of tractor 1) Remove the (4) carriage bolts from each side of the rear frame. See figure 1. Note – Bolts are not present on all machines. 2) Open mounting kit box and layout parts.
- Page 4 John Deere X Series CAB MOUNTING INSTRUCTIONS Installation of Cab Raise the cab using the lifting ears on the roof of the cab. Remove the shipping stands from the cab. 7) Install (4) rubber isolator bushings in the front and rear cab mounts. See Figures 7 and 8.
-
Page 5: Gas Engine
John Deere X Series CAB MOUNTING INSTRUCTIONS Electrical Hook-up 10) Open the windshield and lift the tractor hood. Remove the right side screen assembly from the tractor console. 11) Attach the relay assembly bracket to the tractor. GAS ENGINE - Remove the lower mounting screw from the muffler guard on the left side of the tractor. - Page 6 John Deere X Series CAB MOUNTING INSTRUCTIONS Figure 12 Figure 11 Installing Seal Panels 16) Install the lower left side air intake panel, #4-14672. Use (2) 1/4-20 x ¾ bolts, (4) ¼” flat washers, (2) ¼” lock washers and (2) 1/4-20 nuts. Do not tighten.
- Page 7 John Deere X Series CAB MOUNTING INSTRUCTIONS 18) Install the lower right filler panel, #4-14674. Use (2) 1/4-20 x ¾” bolts, (4) ¼” flat washers, (2) ¼” lock washers and (2) 1/4-20 nuts. With the hood closed, use the adjustment slots to get a good seal and secure. See figure 14. Heater mount screws and ground wire Figure 15...
- Page 8 John Deere X Series CAB MOUNTING INSTRUCTIONS 20) Drain the coolant from the tractor. Note: The cab includes an “H” shut off valve which allows coolant to return to the engine when the valve is in the closed position therefore not affecting bypass function.
- Page 9 John Deere X Series CAB MOUNTING INSTRUCTIONS Diesel Engines Steps 24-30 (See Figures 18 and 19) 23) Unplug the temperature sensor and remove the sensor from the thermostat housing. Set the sensor and seal washer aside for reinstallation. 24) Use pipe seal thread tape or liquid pipe seal compound on all threaded fittings. Install the provided aluminum fitting into the thermostat housing with the rubber O-ring washer.
- Page 10 John Deere X Series CAB MOUNTING INSTRUCTIONS Figure 19 30) Remove the top hose from the heater unit. Pour coolant into the hose and heater unit to remove all air from the system. Reinstall the hose to the heater unit. See figure 20.
- Page 11 Page 11 of 25...
- Page 12 Page 12 of 25...
- Page 13 Page 13 of 25...
- Page 14 Page 14 of 25...
- Page 15 Page 15 of 25...
- Page 16 Page 16 of 25...
- Page 17 Page 17 of 25...
- Page 18 Page 18 of 25...
- Page 19 Page 19 of 25...
- Page 20 Page 20 of 25...
- Page 21 Page 21 of 25...
- Page 22 Page 22 of 25...
- Page 23 Page 23 of 25...
- Page 24 Page 24 of 25...
- Page 25 Page 25 of 25...
