Model/Modelo/Modèle
16929 Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
WARNING: THIS FAUCET IS NOT TO BE USED WITH PORTABLE DISHWASHERS! / ADVERTENCIA: ¡SESTA LLAVE NO SE DEBE UTILIZAR CON
MAQUINAS LAVAPLATOS PORTATILES! / AVERTISSEMENT: ON NE DOIT PAS BRANCHER UN LAVE-VAISSELE PORTATIF SUR CE ROBINET!
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant
de débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
SINGLE HANDLE PULLOUT KITCHEN FAUCET
LLAVE DE AGUA (GRIFOS) DESLIZABLES PARA
LA COCINA, DE MANIJA SENCILLA
ROBINET D'ÉVIER DE CUISINE À UNE POIGNÉE À
BEC RÉTRACTABLE
US. Pat. 4,043,359, 3,786,995, 4,562,960, 4,593,430, 4,089,347, 4,218,785, 4,765,365, 4,696,322
5,771,934, 5,960,832
1
? ?
3/18/08 Rev. C
Advertisement
Table of Contents
Summary of Contents for Delta Kitchen 16929 Series
- Page 1 LA COCINA, DE MANIJA SENCILLA ROBINET D’ÉVIER DE CUISINE À UNE POIGNÉE À BEC RÉTRACTABLE Model/Modelo/Modèle 16929 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. WARNING: THIS FAUCET IS NOT TO BE USED WITH PORTABLE DISHWASHERS! / ADVERTENCIA: ¡SESTA LLAVE NO SE DEBE UTILIZAR CON...
- Page 2 CLEANING AND CARE Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel. LIFETIME FAUCET AND FINISH LIMITED WARRANTY All parts and finishes of the Delta ®...
- Page 3 RP47666 RP47286L Set Screw Handle w/Set Screw and Button Tornillo de Presión Manija con Tornillo de Ajuste y Botón Vis de calage Manette avec Vis de Calage et Bouton RP46127 Button Botón Bouton RP1050L Casquete Embase avec anneau de réglage RP61 Cam Assembly RP12301...
- Page 4 MAINTENANCE Backflow Protection System If faucet leaks from under handle: Your Delta Faucet pull-out spout incorporates a Remove handle and ensure cap (1) is tight. backflow protection system that has been tested to be in compliance with ASME A112.18.3 and If leak persists–SHUT OFF WATER SUPPLIES.
- Page 5 Note: Make sure baseplate is oriented as shown. Nota: Asegúrese que la chapa de base está orientada como se muestra. Note : assurez-vous que la plaque de base est orientée comme le montre la figure. FOR DECK MOUNT STYLE (Discard small round base and gasket) Place baseplate shanks (1) through mounting holes in deck.
- Page 6 FOR CENTER MOUNT STYLE Make sure hex opening (1) on hub base (2) is properly aligned with the hex Push faucet as far back on sink as possible. Secure to sink with key inside of hub. Install round escutcheon (3) and base ring (4) onto mounting bracket (8) and nut (9).
- Page 7 1/2" (12.7mm) IPS CAUTION: Extreme care must be exercised in bending copper inlet tubes Pass hose (1) through faucet (2). to avoid kinking. Follow these instructions exactly. Kinked tubes will void the warranty. Snap clip (3) to hose. Be sure clip is oriented as illustrated. Gently push tubes (1) to the back of the mounting bracket (2).
- Page 8 Funnel Not Included No se Incluye el Embudo. 14" Entonnoir non inclus (356 mm) Min. Pull the hose assembly (1) out of the spout and be sure to hold the end of For models with soap dispenser. Remove nut and gasket (1). Insert body the hose down into the sink.
