Printer manual
* If your printer is not shown in this picture diagram, please contact your supplier.
We would like to inform you about the fact that this RAVAS product is 100 % recyclable on the basis that the parts
are processed and disposed off in the right manner.
More information can be found on our website www.ravas.com.
Rev.20150617
Printing/typographical errors and model changes reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Ravas PR-INT-MX-RAVAS-ABLE
- Page 1 * If your printer is not shown in this picture diagram, please contact your supplier. We would like to inform you about the fact that this RAVAS product is 100 % recyclable on the basis that the parts are processed and disposed off in the right manner.
-
Page 2: Table Of Contents
Printer manual PRINTER Page PR-INT-MX-RAVAS-ABLE Picture Paper change Inkt ribbon change paper rolls PR-INT-TH-RAVAS-MPP8250 Picture Paper change paper rolls PR-INT-TH-XTRA Picture Paper change paper rolls PR-EXT-TH-RAVAS-7810V Picture Paper change paper rolls PR-EXT-MX-MCPK6701 Picture Paper change Inkt ribbon change paper rolls... - Page 3 Printer manual PR-ZEBRA-GK420D Picture Paper change paper rolls PR-EXT-TH-BLT-3” Picture Paper change paper rolls Page 3 of 26...
-
Page 4: Pr-Int-Mx-Ravas-Able
Printer manual PR-INT-MX-RAVAS-ABLE Picture Paper change Drawing 1 Drawing 2 Turn off the weighing system. In order to open, move the left key (see drawing 1) to the right. At the same time pull the printer door towards you. -
Page 5: Inkt Ribbon Change
The ink ribbon pops out and can be changed (see drawing 4). drawing 3 drawing 4 Picture inkt ribbon Paper rolls Order nr.: Description: Dimensions: PRP-PAP-RAVAS-57-50-12 paper, single, white 57xØ50xØ12 mm. PRP-PAP-RAVAS-57-50-12-DOUBLE paper, double, white/yellow 57xØ50xØ12 mm. Page 5 of 26... -
Page 6: Pr-Int-Th-Ravas-Mpp8250
Printer manual PR-INT-TH-RAVAS-MPP8250 Picture Paper change Drawing 1 Drawing 2 In order to open, pull the lever until the lid is released from its locked position. To avoid damage, do not use eccesive force. See drawing 1 and 2. -
Page 7: Paper Rolls
Close the lid by applying equal amounts of pressure on each side ensuring the lid is in locked position. Tear off the spare paper. Paper rolls Order nr.: Description: Dimensions: PRP-PAP-INT-TH-RAVAS Thermal paper, white 57xØ50xØ18 mm. PRP-PAP-CU-ST-TH-RAVAS Thermal, self adhesive, white 57xØ50xØ12 mm. Page 7 of 26... -
Page 8: Pr-Int-Th-Xtra
Printer manual PR-INT-TH-XTRA Picture Paper change Picture 1 Picture 2 Page 8 of 26... -
Page 9: Paper Rolls
Close the lid by applying equal amounts of pressure on each side ensuring the lid is in locked position. See picture 4. Tear off the spare paper. Paper rolls Order nr.: Description: Dimensions: PRP-PAP-TH-RAVAS-58-32-12 Thermal paper, white 58xØ32xØ12 mm. Page 9 of 26... -
Page 10: Pr-Ext-Th-Ravas-7810V
Printer manual PR-EXT-TH-RAVAS-7810V Picture Paper change In order to open, pull the lever until the lid is released from its locked position. To avoid damage, do not use eccesive force. Remove the empty paper roll from the holder. ... -
Page 11: Pr-Ext-Mx-Mcpk6701
Printer manual PR-EXT-MX-MCPK6701 Picture Paper change Drawing 1 Drawing 2 In order to open, squeeze the lid carefully sideways and pull it up. To avoid damage, do not use eccesive force. Page 11 of 26... -
Page 12: Inkt Ribbon Change
Printer manual Remove the remaining paper using the Paper Feed button, do not pull paper out of the rear of the printer mechanism. Reel off a few centimetres from a new roll of paper and check that the end has a clean straight edge (see ... -
Page 13: Paper Rolls
Printer manual Picture 3 Picture 4 Paper rolls Order nr.: Description: Dimensions: PRP-PAP-RAVAS-57-50-12 paper, single, white 57xØ50xØ12 mm. PRP-PAP-RAVAS-57-50-12-DOUBLE paper, double, white/yellow 57xØ50xØ12 mm. Page 13 of 26... -
Page 14: Pr-Star
Printer manual PR-STAR Picture Paper change Turn off the power of the printer. Cut the Roll Paper end straight and square. Hold the roll so that the paper comes from the bottom. Attach the Roll Paper to the Holders Paper by slipping one side of the roll onto the Hub and ... -
Page 15: Inkt Ribbon Change
Printer manual Inkt ribbon change Turn off the printer power. In order to open, lift the lid (see drawing 1) upwards. NOTE: Be careful not to touch the print head immediately after printing, because it can get very hot. Drawing 1 To remove the old inkt ribbon, Hold the spool and lift gently, rotating it until the ribbon sags. -
Page 16: Paper Rolls
Printer manual Drawing 2 Unwind ribbon so that the spools are separated as shown in drawing 3. Drawing 3 Hold the ribbon taut as shown with the drive pins facing down and slide the ribbon between the print head and the platen. While keeping the ribbon taut, wrap one side around the black ribbon guide on the end of the platen and drop one spool on the spool shaft. -
Page 17: Pr-Star-Pin
Printer manual PRP-PAP-STAR-2 paper, double, friction feed, white/yellow 114xØ70xØ12 mm. PR-STAR-PIN Picture Paper change Turn off the power of the printer. To remove the old paper, cut the paper close to the slot and use the feed button until paper has ... -
Page 18: Inkt Ribbon Change
Printer manual Drawing 1 Insert the paper squarely into the paper insertion slot until the ALARM lamp goes out. Then, hold down the FEED switch to advance the paper 8 lines, and release the switch when 8-line feeding is completed. -
Page 19: Paper Rolls
Printer manual To remove the old inkt ribbon, Hold the spool and lift gently, rotating it until the ribbon sags. Push the ribbon detecting lever out, lift the spool until it comes off the shaft. Remove the second spool in a similar manner. (See drawing 2). (Do not apply excessive force when lifting spools.). Drawing 2 Unwind ribbon so that the spools are separated as shown in drawing 3. -
Page 20: Pr-Tm-295
Printer manual PR-TM-295 Picture Paper loading Use only the specified type of paper for this printer. Do not use inappropriate types of paper, or it could cause malfunction or damage of the printer. The following procedure describes how to print on paper. Before trying to print,be sure to install a ribbon cassette into the printer using the procedure under “inkt ribbon change”... - Page 21 Printer manual Though paper can be inserted either from the front or side of the printer, front paper insertion may result in paper jams, depending on the condition of the paper. Because of this, it is recommended that you always insert paper from the side. This printer is equipped with paper sensors, so you do not have to perform any special procedure to align the location from which printing should start.
-
Page 22: Inkt Ribbon Change
Printer manual Inkt ribbon change Push straight up on the ridged locations on the sides of the printer cover to remove it from the printer. Make sure that the printer’s paper release is activated (the paper is not held in place by the paper ... -
Page 23: Paper
Printer manual Hold the ribbon cassette so that the ribbon is facing down, install the cassette into the slip printer as shown in the illustration. Press gently but firmly on the cassette until it snaps securely into place. Rotate the knob on the cassette again to take up any slack. - Page 24 Printer manual PR-ZEBRA-GK420D Under construction Page 24 of 26...
- Page 25 Printer manual PR-EXT-TH-BLT-3” Changing paper Turn off the printer Push the blue button to open the cover, afterwards lift this cover. Page 25 of 26...
- Page 26 Printer manual Position the roll as shown below. Make sure the paper is place facing the correct side. Please note: only use 3 inch paper rolls! Pull a little piece of paper out of the printer, afterwards push the middle of the cover to close. ...
