- Page 1 INTEGRITY TREADMILL Assembly Instructions (INTDX, INTSX, Club Series) 1006193-0001 REV AB...
- Page 3 User and Service Documents Link Operation Manuals and other Product Information available at https://www.lftechsupport.com/web/document-library/documents https://www.lftechsupport.com/web/document-library/documents https://www.lftechsupport.com/web/document-library/documents https://www.lftechsupport.com/web/document-library/documents https://www.lftechsupport.com/web/document-library/documents https://www.lftechsupport.com/web/document-library/documents Trobareu el manual de funcionament i altra informació de producte a https://www.lftechsupport.com/web/document-library/documents Mae Llawlyfrau Gweithredu a Gwybodaeth Arall am Beiriannau ar gael yn https://www.lftechsupport.com/web/document-library/documents Die Betriebsanleitung und andere Produktinformationen erhalten Sie unter https://www.lftechsupport.com/web/document-library/documents...
- Page 4 Corporate Headquarters Columbia Centre III, 9525 West Bryn Mawr Avenue, Rosemont, Illinois 60018 • U.S.A. 847.288.3300 • FAX: 847.288.3703 Service phone number: 800.351.3737 (toll-free within U.S.A., Canada) Global Website: www.lifefitness.com International Offices United Kingdom & Ireland AMERICAS Life Fitness UK LTD North America Belgium Life Fitness Benelux NV...
-
Page 5: Table Of Contents
Table of Contents Getting Started Attach Console...........26 Secure Ferrite to Console to Base Power IMPORTANT SAFETY INSTRUCTIONS....6 Cable...............26 CONSIGNÉS DE SÉCURITÉ Route E-Stop Cable..........27 IMPORTANTES..........8 Attach Lower Plastics to Bridge......27 Set-Up..............10 Electrical Power Requirements......10 Attach Rear Cover..........28 Attach End Caps..........28 Grounding Instructions........10 Attach Side... -
Page 6: Getting Started
Getting Started IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using Life Fitness products. Warning: Health-related injuries may result from incorrect or excessive use of exercise equipment. Life Fitness STRONGLY recommends seeing a physician for a complete medical exam before undertaking an exercise program, particularly if the user has a family history of high blood pressure or heart disease, is over the age of 45, smokes, has high cholesterol, is obese, or has not exercised regularly in the past year.If, at any time while exercising, the user experiences faintness, dizziness, pain, or shortness of breath, he or she must stop well immediately. - Page 7 • Do not allow other people to interfere in any way with the user or equipment during a workout. • Allow LCD consoles to “normalize” with respect to temperature for one hour before plugging the unit in and using. • The product should never be left unattended when plugged in. Disconnect from the electrical outlet when not in use, and before putting on or taking off parts.
-
Page 8: Importantes
CONSIGNÉS DE SÉCURITÉ IMPORTANTES • AVERTISSEMENT:Des problèmes de santé peuvent être causés par une utilisation incorrecte ou excessive de l équipement. LIFEFITNESS recommande FORTEMENT de consulter un médecin pour subir un examen médical complet avant de commencer tout programme d exercice, et tout particulièrement si l utilisateur a des antécédents familiaux d hypertension ou de troubles cardiaques, s il a plus de 45 ans, s il fume, s il a du cholestérol, s il est obèse ou n apas fait d exercice régulièrement depuis un an. - Page 9 • Ne pas placer les mains sous l appareil ou dans l appareil, et ne pas le renverser sur le côté pendant le fonction- nement. • Cet appareil n est pas destiné à être utilisé par des personnes ou des enfants présentant des capacités physiques, sensorielles ou mentales réduites, ou encore un manque d expérience et de connaissances, sauf en cas de supervision ou d instructions relatives à...
-
Page 10: Set-Up
Set-Up Read the entire manual before setting up the treadmill. Place the treadmill where it will be used before beginning the setup procedure. Electrical Power Requirements The Life Fitness Treadmill requires a dedicated* line with isolated neutral according to the electrical configurations listed in the chart below. -
Page 11: How To Position And Stabilize The Treadmill
How to Position and Stabilize the Treadmill Follow all safety instructions. Move the treadmill to the location in which it will be used. Note: See How to Adjust and Tension the Striding Belt to center the striding belt. Safety Clearances The following information is supplied as regional reference data regarding safety clearances around the exterior of the treadmill. -
Page 12: Power Switch
Power Switch Located on the front panel at the base of the treadmill, the ON/OFF switch has two positions: "l" (one) for ON and "0" (zero) for OFF. Turning the Unit On To turn the treadmill on, locate the ON/OFF power switch at the front of the treadmill and turn it ON. Stride Sensor Auto-Shutoff System The Stride Sensor auto-shutoff system detects whether a user is on the belt/deck. -
Page 13: Power Cord Routing
Power Cord Routing Warning: Make sure the power cord is unplugged before attempting to route it around or through the treadmill. The power cord can be run to the user-front left or right sides. Excess power cord can be bundled and tied to the pre-installed clips located under the front of the treadmill. -
Page 14: Product Overview
Product Overview INTDX & Club Series Item Description Console Speed Up/Down Arrows Cup Holder Contact Heart Rate Sensors Walking Belt Incline Up/Down Arrows Emergency Stop Magnet Emergency Stop Lanyard Page 14 of 32... -
Page 15: Intsx
INTSX Item Description Console Cup Holder Contact Heart Rate Sensors Walking Belt Emergency Stop Magnet Emergency Stop Lanyard Mounting and Dismounting the Treadmill Use the handrails to enhance stability when mounting or dismounting a treadmill. Never mount or dismount the treadmill while the running belt is moving. -
Page 16: Service And Technical Data
Service and Technical Data Preventive Maintenance Tips Life Fitness products are backed by the engineering excellence and reliability of Life Fitness and are one of the most rugged and trouble-free pieces of exercise equipment on the market today. Note: Safety of the equipment can be maintained only if the equipment is examined regularly for damage or wear. Keep the equipment out of use until defective parts are repaired or replaced. -
Page 17: Preventive Maintenance Schedule
Preventive Maintenance Schedule Item Weekly Monthly Biannually Console Overlays Clean Inspect Bottle Holders / Accessory Clean Inspect Trays Console Mounting Bolts Inspect Hardware Inspect Frame Clean Inspect Plastic Covers Clean Inspect Lifepulse Sensors Clean / Inspect Striding Belt Centered Inspect Emergency Stop Magnet Clean / Inspect Motor Cover... - Page 18 Striding belt slips off- center. Probable Cause Corrective Action Check levelers and level treadmill. Check striding belt & Floor surface is uneven. re-tension as necessary. Refer to How to Adjust and Tension the Striding Belt. Maximum speed is reduced. Probable Cause Corrective Action User is pushing striding belt.
-
Page 19: Strap
Unit resets randomly or pauses. Probable Cause Corrective Action Plug treadmill into an appropriate circuit. Refer to Grounding Instructions. Note: In North America use a dedicated 20 amp Power source is insufficient. circuit for Commercial Units or a 15 amp circuit for Consumer Units. -
Page 20: Belt
Abnormally elevated heart rate readings Probable Cause Corrective Action Electromagnetic interference from television sets and/or antennas. Electromagnetic interference from cell phones. Move the exercise equipment a few inches away from the Electromagnetic interference from computers. probable cause, or move the probable cause a few inches away from the exercise equipment, until the heart rate Electromagnetic interference from cars. -
Page 21: Belt
3. If the striding belt has moved to the right, the second person turns the right tension bolt a quarter-turn clockwise and then turns the left tension bolt a quarter-turn counter-clockwise to make the striding belt track back to the center of the roller. -
Page 22: Hardware And Required Attach Uprights
Assembly Hardware and Required Tools Hardware M8 X 20 FLANGE HEX HEAD CAP SCREW M4.2 X 19 PHILLIPS PAN HEAD SCREW M6 X 16 PHILLIPS PAN HEAD SCREW GROMMET M5 X 14 PHILLIPS PAN HEAD SCREW M5 X 16 PHILLIPS PAN HEAD SCREW Required Tools: •... -
Page 23: Secure Grounding Braid Cable To Base Frame
Secure Grounding Braid Cable to Base Frame Description Qty. Grounding Braid Cable M5 X 16 Phillips Pan Head Screw 2.8 Nm (2.0 ft. lbs.) Attach Bridge Weldment to Uprights 1. Attach bridge weldment to uprights. Description Bridge Weldment M8 X 20 Flange Hex Head Cap Screw 2. -
Page 24: Attach Bridge Weldment To Secure Grounding Braid Cable To Uprights
Secure Grounding Braid Cable to Uprights Description Qty. Grounding Braid Cable M5 X 16 Phillips Pan Head Screw 2.8 Nm (2.0 ft. lbs.) Connect Cables INTDX & Club Series Bases: Connect Heart Rate Cables and Keypad Cables. INTSX Bases: Connect Heart Rate Cables. Page 24 of 32... -
Page 25: Connect Base Cables
Connect Base Cables 1. Connect cables from left upright to the SIB. Note: Prior to handling electronics or cables, the installer should touch the metal frame of the unit to discharge static build up. This reduces the risk of damaging control electronics due to electrostatic discharge. Description Cable, Console Power Cable, Console to Base Signal... -
Page 26: Base To Console Cable Connections
Base to Console Cable Connections Description Console to Base Power Note: Initial console production units have a right-angle connector. Bullhorn (Speed / Incline ) Keypad Switches Lifepulse Base Signal Attach Console Description Qty. Console M5 X 14 Phillips Pan Head Screw 1.9 Nm (1.4 ft. -
Page 27: Route E-Stop Cable
Route E-Stop Cable Description Qty. E-Stop Cable Attach Lower Plastics to Bridge 1. Attach lower bridge plastics to upper bridge plastics. Description Bridge Plastics, Lower M6 X 16 Phillips Pan Head Screw 4 Nm (3 ft. lbs.) 2. Secure lower bridge plastics to user arms. Attach emergency stop magnet. Description M4.2 X 19 Phillips Pan Head Screw... -
Page 28: Attach Rear Cover
3. Insert cup holders. Description Cup Holder Attach Rear Cover Description Qty. Rear Cover M4.2 X 19 Phillips Pan Head Screw 1.5 Nm (1.1 ft. lbs.) Attach End Caps Description Qty. End Cap, Right End Cap, Left M4.2 X 19 Phillips Pan Head Screw Grommet 1.5 Nm (1.1 ft. -
Page 29: Attach Side Shrouds
Attach Side Shrouds Description Qty. Side Shroud, Right Side Shroud, Left M4.2 X 19 Phillips Pan Head Screw Grommet 1.5 Nm (1.1 ft.lbs.) Attach Motor Side Shrouds Snap the motor side shrouds to the base frame. Description Qty. Motor Side Shroud, Right Motor Side Shroud, Left Attach Front Shroud 1. -
Page 30: Attach Anti-Slip Rails
2. Tightly secure the two bottom screws to the base. Description M4.2 X 19 Phillips Pan Head Screw Grommet 1.5 Nm (1.1 ft. lbs.) Attach Anti-Slip Rails Note: Push the anti-slip rail forward to lock into place. Secure with the screw. Description Qty. -
Page 31: Attach Motor Cover
Attach Motor Cover 1. Snap the Tinnerman clips on the motor cover into place. Description Motor Cover 2. Securely tighten the two top screws of the front shroud. Torque screws to 1.5 Nm (1.1 ft. lbs.). Page 31 of 32... -
Page 32: Specifications Specifications
Specifications Specifications Heavy / Commercial (INTDX, INTSX) Designed Use Home (Club Series) Maximum User Weight 400 lbs. / 181 kg 0.5 - 14.0 MPH (0.8 - 23 KPH) in 0.1 increments (INTDX, INTSX) Speed Range 0.5 - 12.0 MPH (0.8 - 19 KPH) in 0.1 increments (Club Series) 0% - 15% (INTDX) Elevation Range 0% - 10% (INTSX)
