Summary of Contents for Sewell HD-Link HL13
- Page 1 HDlink HL13 HDMI over IP User Manual...
- Page 2 Sender (Tx) IR Out Front Back Reset DC 5V HDMI In Cat5e/6 Out Status...
- Page 3 Media Player Setup HDMI HDMI IR Transmitter IR Receiver Cat5e/6 Media Device Display HDlink HDlink Transmitter Receiver...
- Page 4 Box Contents (1) User Manual (1) HD Link IP Sender (1) HD Link IP Receiver (2) DC 5V Power Adapter (1) IR Transmitter (1) IR Receiver...
- Page 5 Receiver (Rx) IR In Front Back Reset DC 5V HDMI Out Cat5e/6 In Status...
- Page 6 Local Network Setup HDMI IR Receiver HDMI Cat5e/6 Display HDlink IR Transmitter Receiver Display HDlink HDlink Media Device Receiver Transmitter HDlink Display Receiver...
- Page 7 Specs -A single Cat5e/6 cable will transmit your HDMI and IR signals -Distance: 100m (for best results, we recommend using Cat6) -Resolution: up to 1080p@60Hz -Data Rate: 2.25Gbps -TCP/IP distribution...
- Page 8 What is TCP/IP? The HD Link IP uses the reliability and flexibility of TCP/IP networking protocols to extend HDMI signals over long distances (up to 330 feet) and can use new or existing network infrastructure. Point-to-point connections can be made with Cat5e/6 (or better) cables and video distribution just requires a simple gigabit switch.
- Page 9 Need Help? Phone 800. 709. 1345 Email support@sewelldirect.com Chat sewelldirect.com/support Live support available Monday through Friday 9AM-8PM EST...
