Service Manual
AC-N006R, AC-N006RH
AC-T006R, AC-T006RH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-N006R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ballu AC-N006R

Summary of Contents for Ballu AC-N006R

  • Page 1 Service Manual AC-N006R, AC-N006RH AC-T006R, AC-T006RH...
  • Page 2 ROBLEM POSSIBLE CAUSE SOLUTION Water leakage Rubber plug at the rear plate of the machine Put back the rubber plug. is out of place. Water tube inside the machine is not in the Check and reinstall or replace the water place or broken.
  • Page 3 PROBLEM POSSIBLE CAUSE SOLUTION Compressor works but Bad connection of the wires. Check and reconnect or replace. the fan doesn’t. Fan motor breaks down. Check and replace. Fan motor capacitor breaks down. Check and replace. P.C. board breaks down. Check and replace. Fan blade is stuck.
  • Page 4 PROBLEM POSSIBLE CAUSE SOLUTION Suction temperature & Room temperature is too low. Increase the room temperature. suction pressure are too Dusty Evaporator. Clean the evaporator. low. R.P.M. of the fan motor is low. Increase the R.P.M. of the motor. Air return of the evaporator is blocked. Remove the blockade.

  • Page 5: Replacing The Compressor

    How to? REPLACING THE COMPRESSOR Take off the overload protector and wires of the compressor. Take off the suction and discharging tubes. Unfasten the screws on the compressor. Take off the accessories for the compressor. Replace the defect compressor with a new one. Re-install the accessories, wires &...
  • Page 6 REPLACING THE DOWN MOTOR ( FOR CONDENSER) Take off the front & rear plates of the machine. Unscrew the front & rear fixers for the condenser. Take off the rear fixer. Take off the funnel of the condenser. Take off the defect motor and replace it with a new one.

  • Page 7: Replacing The Pump Motor

    REPLACING THE UP MOTOR CAPACITOR (FOR EVAPORATOR) Take off the rear plate of the unit. Unfasten the screws of the motor capacitor. Take off the motor capacitor and replace it with a new one. Re-install in the opposite steps. REPLACING THE FAN BLADE OF THE EVAPORATOR Take off the front &...

  • Page 8: Replacing The Microswitch

    REPLACING THE MICROSWITCH Take off the front and rear plates. Take off the wires for the micro switch. Take off the lever. Take off the micro switch. Replace the defect micro switch with a new one. Re-assemble in the opposite steps. REPLACING THE CONTROL PANEL Take off the front &...
