TX-NR575E / AV RECEIVER
Before Start .................................................... 2
What's in the box .............................................. 2
Part Names ..................................................... 3
Part Names....................................................... 3
Install .............................................................. 7
Installation procedure ....................................... 7
Step1: Speaker Layout ..................................... 8
Step2: Connect the Speakers ......................... 14
Initial Setup .................................................. 22
Playback ....................................................... 24
AV Component Playback ................................ 24
®
Playback ................................ 24
Network Functions .......................................... 25
USB Storage Device ....................................... 26
Listening To the AM/FM Radio ........................ 27
Multi-zone........................................................ 29
Listening Mode................................................ 30
For details about the Network Functions and listening
modes, and information regarding the advanced settings,
refer to the "Advanced Manual" available on our website. To
view it, access it through the following URL or QR code.
http://www.onkyo.com/manual/txnr575e/adv/en.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-NR575E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo TX-NR575E

Summary of Contents for Onkyo TX-NR575E

  • Page 1: Table Of Contents

    TX-NR575E / AV RECEIVER Before Start ............ 2 USB Storage Device ........26 What's in the box ..........2 Listening To the AM/FM Radio ......27 Part Names ............. 3 Multi-zone............29 Part Names............3 Listening Mode..........30 Install .............. 7 For details about the Network Functions and listening Installation procedure ........

  • Page 2: Before Start

    > Before Start > Part Names > Install > Initial Setup > Playback What's in the box 1. Main unit (1) 2. Remote controller (RC-911R) (1), Batteries (AAA/R03) 3. Speaker setup microphone (1) 0 Used during Initial Setup. 4. Indoor FM antenna (1) 5.

  • Page 3: Part Names

    > Before Start > Part Names > Install > Initial Setup > Playback Part Names                   Front Panel turned off completely. 8. Display (P4) 1.
  • Page 4 > Before Start > Part Names > Install > Initial Setup > Playback 15.PHONES jack: Headphones with a standard plug (Ø1/      4"/ 6.3 mm) are connected. 16.Input selector buttons: Switches the input to be played. 17.SETUP MIC jack: The supplied speaker setup microphone is connected.
  • Page 5 > Before Start > Part Names > Install > Initial Setup > Playback           90° 180°       Rear Panel 8. Power cord 9. GND terminal: The ground wire of the turntable is connected. 1.
  • Page 6 > Before Start > Part Names > Install > Initial Setup > Playback Remote Controller  1. Í ON/STANDBY button 2. Input selector buttons: Switches the input to be played. 3. Q button: Press during play to display the QUICK MENU on the TV and display to adjust sound quality, etc.

  • Page 7: Install

    > Before Start > Part Names > Install > Initial Setup > Playback Installation procedure This unit can be used in a number of ways, depending on the layout of the speakers you are installing, and the connections made to external devices. Read the following to help make the installation process smoother.

  • Page 8: Step1: Speaker Layout

    > Before Start > Part Names > Install > Initial Setup > Playback Step1: Speaker Layout 7.1 Channel System Front speakers output front stereo sound and a center speaker outputs center sound such as dialogs and vocals. Surround speakers create back sound field. Powered subwoofer reproduces bass sounds and creates rich sound field.
  • Page 9 > Before Start > Part Names > Install > Initial Setup > Playback 5.1.2 Channel System-1 (Front High Speakers/Rear High Speakers) This is a basic 5.1-channel system consisting of front speakers, a center speaker, surround speakers, and a powered subwoofer, with the addition of front height speakers or rear high speakers, which are both types of height speakers.
  • Page 10 > Before Start > Part Names > Install > Initial Setup > Playback 5.1.2 Channel System-2 (Ceiling Speakers) This is a basic 5.1-channel system consisting of front speakers, a center speaker, surround speakers, and a powered subwoofer, with the addition of top front speakers, top middle speakers, or top rear speakers, which are types of height speakers.
  • Page 11 > Before Start > Part Names > Install > Initial Setup > Playback 5.1.2 Channel System-3 (Dolby Enabled Speakers (Dolby Speakers)) This is a basic 5.1-channel system consisting of front speakers, a center speaker, surround speakers, and a powered subwoofer, with the addition of Dolby enabled speakers (front) or Dolby enabled speakers (surround), which are both types of height speakers.
  • Page 12 > Before Start > Part Names > Install > Initial Setup > Playback Bi-Amping the Speakers It is possible to connect front speakers supporting Bi- amping to improve quality of the bass and treble. The maximum number of channels available with this connection is 5.1 because Bi-Amping speakers require one amplifier for the tweeter jacks and one amplifier for the woofer jacks.
  • Page 13 > Before Start > Part Names > Install > Initial Setup > Playback Speaker combinations 0 In any of the combinations, up to two powered subwoofers can be connected. SURROUND Speaker Channels FRONT CENTER SURROUND BACK HEIGHT Bi-Amp ZONE 2 2.1 ch 3.1 ch 4.1 ch...

  • Page 14: Step2: Connect The Speakers

    > Before Start > Part Names > Install > Initial Setup > Playback Step2: Connect the Speakers Standard Connections (Pages 8 to 11) Make correct connection between the unit's jacks and speaker's jacks (+ to + and – to –) for each channel. If connection is wrong, reverse phase may make bass output poor.
  • Page 15 > Before Start > Part Names > Install > Initial Setup > Playback Connecting with Bi-Amping Speakers (Page 12) 0 Refer to "Standard Connections (Pages 8 to 11)" (P14) to connect the center speaker, surround speakers, and powered subwoofer. Make sure you remove the jumper bar fitted between the woofer jacks and tweeter jacks of the front speakers.

  • Page 16: Step3: Connect The Tv & Av Components

    > Before Start > Part Names > Install > Initial Setup > Playback Step3: Connect the TV & AV Components 1. Connect the TV To ARC TV For a TV that supports the ARC (Audio Return Channel) (*) feature, use an HDMI cable and connect according to illustration "a".
  • Page 17 > Before Start > Part Names > Install > Initial Setup > Playback 2. Connect the HDMI AV Component This is an example of connection with an AV component that has an HDMI jack. With connection to an AV component that conforms with the CEC (Consumer Electronics Control) standard, you can use features such as the HDMI CEC feature (*) that links with the input selector, and the HDMI Standby Through feature which allows you to...
  • Page 18 > Before Start > Part Names > Install > Initial Setup > Playback 3. Connect the Non-HDMI AV Component This is an example of connection with an AV component that does not have an HDMI jack. Make the connections to the AV component to match the jacks it has.
  • Page 19 > Before Start > Part Names > Install > Initial Setup > Playback 4. Connect the Audio Component Example of a connection with an audio component. Connect a CD player using a digital optical cable or analog audio cable. You can also connect a turntable that has an MM-type cartridge to the PHONO jack.
  • Page 20 > Before Start > Part Names > Install > Initial Setup > Playback 5. Multi-zone Connection You can enjoy audio in the separate room by, for example, playing a Blu-ray Disc player in the main room (where this unit is located) and listening to internet radio in the separate room (ZONE 2).
  • Page 21 > Before Start > Part Names > Install > Initial Setup > Playback 6. Connect Other Cables Antenna Hookup Move the antenna around while playing the radio to find the position with the best reception. Use a thumb tack or similar to attach the indoor FM antenna to a wall.

  • Page 22: Initial Setup

    > Before Start > Part Names > Install > Initial Setup > Playback Initial Setup with Auto Start-up Wizard Initial Setup Starts Automatically When you turn the unit on for the first time after purchasing it, Initial Setup is automatically shown on the TV to enable you to make settings required for startup using simple operations following onscreen guidance.
  • Page 23 > Before Start > Part Names > Install > Initial Setup > Playback The speakers emit the test tone at high volume during The image on the screen changes as you choose the If you select "Scan Networks", there are a further two measurement, so be careful of your surroundings.

  • Page 24: Playback

    BLUETOOTH wireless technology, the password is requested, enter "0000". INPUT jack on the front panel, press sound produced on this unit may slightly 0 This unit is displayed as "Onkyo TX- AUX. be behind the sound played on the NR575E XXXXXX".

  • Page 25: Network Functions

    > Before Start > Part Names > Install > Initial Setup > Playback Network Functions INPUT Basic Operations Spotify application on your smartphone to display a list of Network Functions on or tablet and create a Spotify premium the TV. By connecting this unit to the network you account.

  • Page 26: Usb Storage Device

    > Before Start > Part Names > Install > Initial Setup > Playback USB Storage Device INPUT Basic Operations 5. Press ENTER on the remote controller again in the next screen. The list of You can play music files stored on a USB folders and music files on the USB storage device.

  • Page 27: Listening To The Am/Fm Radio

    > Before Start > Part Names > Install > Initial Setup > Playback Listening To the AM/FM Radio You can receive AM and FM radio stations ST" indicator lights. 3. While pressing the cursors (b) on on this unit with the built-in tuner. Perform the remote controller, select the desired When FM broadcasts reception is poor: the following procedure when the unit is on.
  • Page 28 > Before Start > Part Names > Install > Initial Setup > Playback ∫ Using RDS road music) / Light M (Light classics) / Classics (Serious classics) / Other M RDS stands for Radio Data System and is (Other music) / Weather / Finance / a method of transmitting data in FM radio Children (Children’s programmes) / signals.

  • Page 29: Multi-Zone

    > Before Start > Part Names > Install > Initial Setup > Playback Multi-zone ZONE 2 on the remote controller. Alternatively press OFF on the main unit. Playing in ZONE 2 only: If you turn the unit to standby during multi- zone playback, the Z2 indicator is dimmed and the playback mode is switched to playback in a separate room only.

  • Page 30: Listening Mode

    > Before Start > Part Names > Install > Initial Setup > Playback Listening Mode This unit is equipped with a variety of Dolby Digital/DTS Modes display and analog video circuits. Checking the Input Format and listening modes, and you can select the Listening Mode When the input signal is a digital surround optimum listening mode for movies, TV,...
  • Page 31 United States and other countries. DSD and the Direct Stream Digital logo are trademarks of Sony Corporation. AccuEQ and Music Optimizer are trademarks of Onkyo Corporation. “All other trademarks are the property of their respective owners.” ® The Wi-Fi CERTIFIED Logo is a certification mark of Wi-Fi Alliance “Toutes les autres marques commerciales sont la propriété...
  • Page 32 The above-mentioned information is subject to change without prior notice. Visit the Onkyo web site for the latest update. F1701-0 (C) Copyright 2017 Onkyo & Pioneer Corporation Japan. All rights reserved. http://www.onkyo.com/privacy/ Printed in Malaysia / Imprimé en Malaisie * 2 9 4 0 2 7 6 1 *...
