WAP 100AC Wireless Access Point • Setup Guide

Overview

The Extron WAP 100AC wireless access point is easily installed and supports the full spectrum of Wi-Fi channels. For more complete
procedures, see the WAP 100AC User Guide at

Setup Overview and Checklist

Get Ready
… Obtain the following network information about the WAP 100AC from your network administrator:
… DHCP status (on or off). If DHCP is off, you also require:
…
IP address
(default 192.168.1.1)
… User name — by default, this is admin.
… Password — by default, this is extron.
… Make a note of the MAC address. This can be found on the WAP 100AC rear panel label.

Mount and Cable the WAP 100AC

ATTENTION:
• Do not power on the WAP 100AC until you have read the Attention in the Power Supply section of the WAP 100AC User
Guide.
• Ne branchez pas le WAP 100AC avant d'avoir lu la mise en garde dans la section « sources d'alimentation » du WAP
100AC User Guide.
… Decide where to mount the WAP 100AC
… Prepare the mounting site. Do not finish mounting the unit until all the cables are in place.
… Use Ethernet cable to connect the WAP 100AC to a power injector or the network.
… If you are not using Power over Ethernet (PoE), connect a 12 VDC power power supply.
NOTE: The WAP 100AC can use a 12 VDC, minimum 1.0 A power supply or a PoE+ (802.3at compliant) power injector.
Extron recommends using PoE.
… Complete the mounting of the WAP 100AC.

Set up the WAP 100AC for Network Communication

… Connect the PC that you will use for setup to the same Ethernet subnetwork as the WAP 100AC.
… Use the WAP 100AC Web pages to configure the WAP 100AC network settings.
Mounting
ATTENTION:
All structural steps and electrical installation must be performed by qualified personnel in accordance with local and
•
national building codes and electrical codes.
Toute étape structurelle et installation électrique, doit être effectuée par un personnel qualifié, conformément aux codes
•
du bâtiment, aux codes incendie et sécurité, et aux codes électriques, locaux et nationaux.
Consider the Mounting Location
Consider these issues to determine a suitable position to mount the WAP 100AC for optimal performance:
Walls, ceilings, and objects such as filing cabinets can decrease signal strength. Take into account the number, thickness,
•
and location of walls and ceilings.
Wireless signals are weakened less by dry wall than many other materials, such as brick or metal.
•
Interference from electrical devices that generate RF noise (for example, microwaves or cordless phones) can also weaken
•
the signal.
Two or more WAP 100AC units can be used to wirelessly connect networks or to enlarge the wireless area beyond the area
•
that can be served by a single access point.
www.extron.com
.
…
Subnet mask
(default 255.255.255.0)
Product Category
…
Gateway
