① 85V-242VAC，50-60HZ；power consumption ≤4W
② 24VDC/AC power consumption≤4W ；
③ 220VAC±10% 50HZ；power consumption≤4W
2.11、working circumstance ：
Environment temperature:0～50℃，humidity ≤85％,no corrode and strong electromagnetism
disturb；
2.12、Product authentication：
XMT*-808 series temperature meter acquire CE authentication and ROHS Environmental
Protection authentication.
About XMT*808 series intelligence temperature controller，we mark specific
model on each piece. According to on site control request by itself ,client should contrast
the meaning of the product model code carefully before use and choose，to avoid wrong
use or wrong model selection.,or you can telephone to consult.
3.2 Product code
XMT 8
□ □
（1） (2) (3) (4) (5)
（1） The External dimension：
Blank：160×80×120
（2） Control Mode： '8' ：four key set, two row LED display,，fuzzy control.
（3） Additional alarm： '0' ：no alarm ；
（4） Signal input type： '8' ：freely exchange signal
（5） Suffix：
Main control output method：
'Blank' ：relay's open and closed contact output；
'A' ：Single-phase over-zero spark pulse；
'A3' ：Three-phase over-zero spark pulse;
'B' ：Single-phase shift-phase spark pulse；
'B3' ：Three-phase shift-phase spark pulse；
'C' ：0～10mA or 4～20mA constant electric current output
Saling hotline：+86-574-62833904
Yuyao gongyi meter co.,LTD
Ⅲ、Model selection
Model selection instruction
8
□□
Installation hole 152×76；
A：96×96×110 Installation hole 92×92；
D：72×72×110 Installation hole 68×68；
E： 48×96×110 Installation hole 44×92；
F：96×48×110 Installation hole 92×44；
S：80×160×120 Installation hole 76×156
G：48×48×110 Installation hole 44×44
'3' ：two group alarms '5' ：voice alarm
technical consultation：+86-574-62830724
'1' ：one group alarm；
5
Fax：+86-574-62814210
