Summary of Contents for Lezyne MICRO WATCH
- Page 2 If this equipment does cause harmful interference to radio or television Lezyne is a trademark of Lezyne USA, Inc. and registered both in the United States and reception, which can be determined by turning the equipment off and on, the user is...
- Page 3 In no event shall Lezyne be liable for incidental or consequential damages for any traffic fines or citations, relating to or resulting from the use of this product or any of its parts. Lezyne assumes no liability for any accident, injury, death, loss, or other claim related to or resulting from the use of this product.
-
Page 4: Table Of Contents
– Mapping – Erase All – Installing GPS – Strava Live Segments – Erase Oldest – Turning on GPS – Lezyne Track – Memory – GPS Satellite Signal – Reset Trip 1 – Starting a Ride – Reset Trip 2 •... -
Page 5: Getting Started
GETTING STARTED Modes The Lezyne GPS Watch is not only a great cycling device for recording speed, distance and sensor information; it can also be used as a watch to track steps and running /hiking activities. Lifestyle, Hiking, Running Modes have preset data pages for popular metrics used during those activities. -
Page 6: Buttons
GETTING STARTED Buttons • Hold for 2 seconds to turn device ON. • Hold for 2 seconds to switch between Lifestyle, Biking, Hiking, and Running Modes or to turn OFF. • Press to scroll left through the data pages. • Press for back function in device menu. •... -
Page 7: Screen Icons
Select Start Ride / Start new Lap Backlight Pause / End Ride* Force Navigation Reroute* Scroll Down *Hold for 2 seconds Screen Icons Lezyne Track GPS Status Battery Status Power Sensor Phone Connection Heart Rate Sensor Sensor Status Cadence Sensor... - Page 8 GETTING STARTED Charging Before using your Lezyne GPS watch for the first time, fully charge the battery. It is also recommended to visit lezyne.com/gpsroot, setup a free account and update your GPS device to the latest firmware. 1. Remove exterior moisture.
-
Page 9: Turning On The Gps
GETTING STARTED Turning on the GPS Turn on your GPS and switch between Modes by holding the left button. You can choose the Modes - Lifestyle Press and hold for 2 - Hiking seconds to turn on - Running - Biking GPS Satellite Signal Before a recorded activity can start there must be status of a GPS signal present. -
Page 10: Starting An Activity
GETTING STARTED Starting an Activity 1. At least 1 GPS status dots will fill solid when ready. 2. Start recording by pressing the bottom right button. 3. Activity data is recorded when the timer is running. 4. Press the top right button or top Press to start left button... -
Page 11: Uploading A Ride To Your Computer
2. Connect your GPS Watch to a computer via the supplied Micro USB cable. 3. The watch will read like a USB drive with included folders 4. Within the Lezyne GPS folder find your .Fit ride files in the Activities folder to upload and share at www.lezyne.com/gpsroot... -
Page 12: Modes
GETTING STARTED Menu Screen Hold the top right button for two seconds to enter the device MENU. Menu options include*: • Alert • Phone • Info • Auto • Navigation • Strava • Bike • Sensors • Personal • Screen •... -
Page 13: Time Setup
TIME SETUP Time Format Time Format adjusts time display from 12hr to 24hr format. Press ENTER and use the right buttons to scroll for 12hr or 24hr. Press ENTER to make the selection. Time Zone Time Zone adjusts time based on your closest location. -
Page 14: Nd Time Zone
TIME SETUP Time Lifestyle Mode Only Time allows you to add another time zone. Turn this on and follow the same time setup steps on the previous page. Press ENTER and use the right buttons to scroll. Time Zone Time Zone adjusts time based on your closest location. -
Page 15: Screen Setup
SCREEN SETUP Screen Display Up to 5 data pages can be customized to show different data fields. To access the Screen menu: 1. Hold the top-right Menu button for 2 seconds. 2. Scroll to Screen and press Enter. 3. Here you can customize your pages and data fields. Data Pages Number of Data Pages: 1. - Page 16 SCREEN SETUP Page Customization There are three display options for each page. • 1 Line of Data • 2 Lines of Data • 3 Lines of Data To change the layout of a page: 1. After selecting No. of Pages, scroll up or down to the page number you want to customize and press the left ENTER button.
-
Page 17: Fields
SCREEN SETUP Data Selection Customization In the Fields Menu you can choose what data metrics to display for each data line. Scroll Up or Down to the field you want to change and press ENTER. Scroll Up or Down through the data metrics and press enter on preferred metric. *Running and Hiking modes Do Not display every data option* Data Field Options Distance... -
Page 18: Unit Format
SCREEN SETUP Watch Face Display Lifestyle Mode Only Change the main Watch Face clock numbers to Option 1 or Option 2. Press ENTER and scroll up or down, press ENTER to select the setting. Unit Format Display In Unit Format you can choose between Miles or Kilometers. -
Page 19: Personal Setup
SCREEN SETUP Notification Display In Notifications you can choose what font size is used to displayed phone notifications. Press ENTER and use the right buttons to scroll between large or small font. Use the ENTER button to select, use the BACK button to exit. PERSONAL SETUP Language Setting Sets your desired language. - Page 20 PERSONAL SETUP Weight Setting Setting your weight assists in calorie calculations. Press ENTER and use the right buttons to INCREASE or DECREASE. Use the ENTER button to make the selection. When done press the BACK button. Height Setting Setting your Height assists in calorie calculations. Press ENTER and use the right buttons to INCREASE or DECREASE.
-
Page 21: Height
This will start the search for the phone. 5. The GPS Ally App will show the Lezyne device you are looking to pair. Select the device and you will be prompted to enter a code from the device to pair with the app. -
Page 22: Phone Pairing
PHONE PAIRING Notifications Setup When the Lezyne GPS Watch is paired with the Lezyne Ally v2 App they can display Text, Email, and Call Notifications. * To enable this feature you must first make sure your phone notifications are turned on for Text and Email. -
Page 23: Navigation
NAVIGATION Navigation Setup When the Lezyne GPS Watch is paired with the Lezyne Ally v2 App you can get Turn-by- Turn directions. In the Lezyne Ally App, on the Navigation tab, you can search by: • Tapping the map on the location you’d like directions to. -
Page 24: Navigation
Go to Lezyne GPS Root. Saved Routes can be accessed from the Lezyne Ally v2 App and pushed to your GPS Watch for Turn-by-Turn directions. 1. Use the interactive map to search for and select a Start and Finishing point. -
Page 25: Mapping
MAPPING Breadcrumb Mapping After starting a ride with your Lezyne GPS Watch a Breadcrumb Map page will display where you have ridden. This helps give an idea of where you have been and can help assist navigating back to your starting point. -
Page 26: Strava Live Segments
STRAVA Strava Setup In the Lezyne GPS Root website or in the Lezyne Ally v2 App you can connect profiles with Strava to sync rides. While in the GPS Root or your Ally App you can manually sync rides to Strava or set Auto Sync in the App Settings tab. -
Page 27: Lezyne Track
3. Turn on Lezyne Track. 4. Type in or search through your contacts to add people to your share list. 5. Once you hit record on your Lezyne GPS a notice will be sent to the people in your contact list... - Page 28 SENSOR PAIRING Sensor Setup * Before pairing to a new sensor, see the manufacturer’s instruction manual on how to pair and calibrate with a new device. 1. In the Main Menu scroll to Sensors and press ENTER. Scroll to the sensor type you want to pair with and press ENTER.
-
Page 29: Sensor Pairing
SENSOR PAIRING Power Meter Setup * Before you pair your Power monitor, see the manufacturer’s instruction manual on how to set up, pair and calibrate the meter with devices. 1. In the Sensors menu scroll to Power and press ENTER. 2. -
Page 30: Wheel Size And Circumference
BIKE SETUP Wheel Circ (Circumference) Setup Setting your Wheel Circumference calibrates a paired Speed Sensor to accurately display your speed. This is also needed if using a speed sensor with an indoor trainer. *A paired Speed Sensor will take over the speed and distance recording instead of using the GPS signal. In the Main Menu, select Bike and press Enter. - Page 31 AUTO/PRESET NOTIFICATION SET UP Scroll Setting Auto Scroll pages on the device while recording. In the Main Menu, select Auto. Press ENTER and use the right buttons to select On or Off. Press ENTER to make the selection. Start/Stop (Pause) Setting The Auto Pause setting is an automatic Start/Stop feature that controls recording of the ride if you stop for a period of time.
- Page 32 AUTO/PRESET NOTIFICATION SET UP Lap Preset Notification Setup Lap preset allows you set a notification pop up based on Time or Distance goals and stores the data in your .fit file. In the Main Menu, select Auto. Press ENTER and use the right buttons to select Time or Distance.
-
Page 33: Alerts Set Up
ALERT SETUP Calories Alert Set up an Alert for when you reach a burned Calories Goal 1. When in the Main Menu scroll to Alerts and select Calories and press the left ENTER button. 2. Scroll up or down to set the desired goal. Sitting Time Alert Lifestyle Mode Only Set a Sitting Time Alert to notify you to get up and move! - Page 34 ALERT SETUP Step Goal Alert Lifestyle Mode Only Set an Alert to notify you for a Step Goal you want to hit. 1. In the Alert Menu, select Step Goal. Use the two right button to scroll up or down and press enter to select your preferred Step Goal alert.
- Page 35 ALERT SETUP Distance Alert Setup Distance alert gives you a pop up alert when you complete a set RIDE or RUN distance goal. In the Alert Menu, select Distance. Use the two right button to Increase or Decrease distance. Press enter to select your preferred Distance alert. Time Alert Setup Time alert gives you a pop up alert when you complete a set a RIDE or RUN goal for an amount of time.
- Page 36 ALERT SETUP Calories Alert Setup Calories alert gives you a pop up alert when you complete a set goal. In the Alert Menu, select Calories. Use the two right button to Increase or Decrease calories. Press enter to select your preferred Calories alert. To reset, select Off and repeat the steps for set up.
- Page 37 ALERT SETUP Maximum HR (Heart Rate) Alert Setup Maximum Heart Rate alert gives you a pop up alert when you above a set Heart Rate. In the Alert Menu, select Max HR. Use the two right button to Increase or Decrease max Heart Rate. Press enter to select your preferred max Hear Rate alert.
-
Page 38: Records
RECORDS Review Review lets you see the metric details of stored rides on the device. In the Main Menu select Records. Press ENTER and use the right buttons to select the ride you want to see by day and time. Press ENTER to make the selection. -
Page 39: Erase Oldest
RECORDS Erase Oldest Erase Oldest will delete the oldest ride recorded and stored on the device. This is for when you need more device memory and know the oldest file is not important but want to keep other rides. In the Main Menu select Records. Press ENTER on Erase Oldest and use the right buttons to select Yes or No. -
Page 40: Reset Trip 1
RECORDS Reset Trip 1 This allows you to delete the recorded distance in Trip 1. In the Main Menu select Records. Press ENTER on Reset Trip 1 and use the right buttons to select Yes or No. Press ENTER to make the selection. Reset Trip 2 This allows you to delete the recorded distance in Trip 2. -
Page 41: Reset Odo (Odometer)
Reset Odo (Odometer) This allows you to delete the accumulated distance on the Odometer. In the Main Menu select Records. Press ENTER on Reset Odo and use the right buttons to select Yes or No. Press ENTER to make the selection. INFO Device This indicates the device type. - Page 42 INFO HDOP, VDOP This is the quality of the GPS data. HDOP: Horizontal Dilution of Precession. VDOP: Vertical Dilution of Precession. Battery The current battery voltage.
- Page 43 INFO FCC ID FCC certification number for the device Industry Canada certification number The three existing compliance marks (C-Tick, A-Tick and RCM) are being consolidated into a single compliance mark—the RCM Bluetooth LE Software version of Bluetooth LE ANT+™ Software version of ANT+™...
-
Page 44: Specifications
SPECIFICATIONS Battery Type Rechargeable Lithium polymer, 900 mAhr Battery Life Up to 22hrs Memory Size Up to 200hrs (Power GPS) Up to 400hrs (Super GPS) Operating Temperature Range -20⁰C to 60⁰C (-4⁰F to 140⁰F) Charging Temperature Range 0⁰C to 45⁰C (32⁰F to 113⁰F) Water Rating IPX7 (Tested in water at 1 meter for 30 mins.)* *USB Plug Must Be Sealed Securely. -
Page 45: Data Metrics Explained
DATA METRICS EXPLAINED Ascent: The total measurement of elevation gained during a preset distance or time. current activity. Odometer: The accumulated distance of all recorded Auto Scroll: The device automatically scrolls through data activities. pages every 10 seconds. Pace: Consistent and continuous speed in walking or running Auto Start/Stop: During an activity this will automatically *Power - 10s Power: A 10 second average output of watts pause a recording when no movement is detected and will... -
Page 46: Troubleshooting
4. Follow the on screen instructions and do not disconnect your computer until the update is complete *In the Info Menu of the GPS Watch look for Firmware to see its current version. Support How to videos, manuals , FAQ can be found on the Support tab at http://www.lezyne.com/support-downloads.php • Videos describing and explaining the device •...
