5/05/2010 Ver:1.4
NIGHT VISION WATERPROOF CAMERA
P R O D U C T
M A N U A L
CONTENTS
Page
1. KEY FEATURES ................2.
2. INSTALLATION ..................3.
3. WIRING INSTRUCTIONS ..3
*Thank you for choosing this product as part of your security solution.
CC-4824H3/H6
Page
4. SPECIFICATIONS.............. 4
P.1
Advertisement
Summary of Contents for Ameba CC-4824H3
- Page 1 5/05/2010 Ver:1.4 NIGHT VISION WATERPROOF CAMERA P R O D U C T M A N U A L CC-4824H3/H6 CONTENTS Page Page 1. KEY FEATURES ....2. 4. SPECIFICATIONS....4 2. INSTALLATION ....3. 3. WIRING INSTRUCTIONS ..3 *Thank you for choosing this product as part of your security solution.
- Page 2 1. KEY FEATURES a. 1/3” Sony H.Q.1 CCD Indoor/Outdoor Camera. b. Leading Technology to meet IP68 Standard for Water Proof. (IPx8 means testing 3 feet under water for 2 hours) c. Built-in High Intensity Infra-Red Led for clear crisp night vision. d.
- Page 3 3. INSTALLATION CONFIGURATION Sun-shield adjustment/Bracket installation * Sun-shield is designed to move forward or backward based on applications. Use a screwdriver to loosen the 4 screws on the sunshield by rotating anti-clockwise. Adjust sun shield. Fasten screws after adjustment. * Bracket installation shown as below. Select a location or angle that can support the total weight of the camera properly.
- Page 4 DC 12V +/- 10% 340mA POWER CONSUMPTION -10C ~ 50C OPERATION TEMP. LENS TYPE 3.6mm / F2.0 6.0mm / F1.8 DIMENSION 60mm(W) x 65mm(H) x 120mm(D) WEIGHT (g) Note: Design and specifications are subject to change without prior notice. By Ameba Technology...
