Page 1 V.A.S. Compressor Operating Manual...
Page 2 American-made steel core transformer. As all Fredenstein products, the OPA2 is not a copy of an older design, but a completely new circuitry manufactured in SMT technology. Matched and integrated dual input transistors guarantee vastly improved specifications compared to older designs.
Page 3: Installation
Comp and then to a grounded mains outlet. The power ON/OFF switch is located on the back panel near the power cable connector (IEC). After the unit is powered on, the PWR indicator on the front panel will be illuminated. Fredenstein V.A.S Comp Manual V1.1 Oct. 2, 2014 Page 2...
Page 4 Connectors: INSERT Standard TRS insert connector (Ring = Output, Tip = Input) to insert effect equipment or inject different signals into the side-chain Fredenstein V.A.S Comp Manual V1.1 Oct. 2, 2014 Page 3...
Page 5: Operation
Fredenstein V.A.S. Compressor Operation: Like most FET compressors, the Fredenstein V.A.S. Compressor features a fixed threshold. The compression depth is controlled by changing the input gain. Increasing the input gain will cause the compressor to apply an increased gain reduction. The compressor Make-up control is used to compensate for the gain reduction.
Page 6 Contact Info: Fredenstein Professional Audio by Orion Communication 7F-1, No. 582, Ruei Guang Rd. Neihu District Taipei 114 Taiwan Phone : + 886-2-2657-2618 Email : info@fredenstein.com www.fredenstein.com...
