Amprobe AT-1000 User Manual

Advanced wire tracer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

AT-1000

Advanced Wire

Tracer

Users Manual

Table of Contents

Need help?

Do you have a question about the AT-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Amprobe AT-1000

Page 1 AT-1000 Advanced Wire Tracer Users Manual...
Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 2 years from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
Page 4 R1000 Receiver x1000 Transmitter...
Page 5: Table Of Contents
AT-1000 CoNTENTS Advanced Wire Tracer Symbols ..............................introduction ............................. Safety precautions and Warnings ......................Unpacking and inspection ........................Component description .......................... R1000 Receiver ........................... x1000 Transmitter ..........................Replacing batteries: R1000 and x1000 ....................operation ..............................Tracing energized Wires ......................... locating opens ............................
Page 6: Safety Precautions And Warnings
AMpRobe has a history of providing safe, reliable equipment to trace energized wires, circuit breakers, tracing deenergized wires, and locating opens. The AT-1000 Advanced Tracing System combines these features in one versatile tool and is effective in solving most tracing problems.
Page 7: Unpacking And Inspection
“on” position. The battery indicator should flash. if the battery indicator remains “off”, replace the battery. Connections to the test circuit should be made after insertion of test leads into x1000. UNPACkINg ANd INSPECTIoN AT-1000 (US version) AT-1000E (Europe version) 1 x R1000 Receiver 1 x R1000 Receiver...
Page 8: X1000 Transmitter
The R1000 is designed to display the signal strength visually with a series of four led’s, and audibly by emitting a pulsed tone. The R1000 is turned “on” and “off”, as well as varying the amount of signal strength that is displayed, by the Sensitivity Range Switch (off, x1, x2, x3, x4, x5).
Page 9: Tracing Energized Wires
(see fig. 4). When using the C2902, always connect to ground first and disconnect from ground last. Switch the R1000 Receiver “on” by sliding the Sensitivity Range Switch” to position 3 and set the R1000 Mode Switch to “CURRenT Mode”. Verify that the x1000 Transmitter is generating a current signal by placing the R1000 tip against one of the cord set leads.
Page 10: Locating Opens
LoCATINg oPENS “opens” are deenergized conductors that are not connected to a source or a load, and therefore do not pass current. first verify that the conductor is deenergized, using a voltmeter, then verify that it is open, with respect to ground and/or adjacent conductors, using an ohmmeter. Using the C2902 Cord Set, connect the x1000 Transmitter to the open conductor and a separate ground as shown in fig.
Page 11 fig. 1: battery Replacement fig. 2b: C2902 Cordset fig. 2a: C2901 Cordset fig. 3: eU-200 Cordset...
Page 12 fig. 4: locating breakers fig. 5: Signal Attenuation...
Page 13 fig. 6: Tracing Conductors fig. 7: Tracing Wires...
Page 14 fig. 8: Tracing opens fig. 9: locating Shorts...
Page 15: Fuse Replacement
fig. 10a: back View fig. 10b: x1000 with front Cover Removed fig. 10: fuse Replacement...
Page 16: Specifications
Visit www.Amprobe.com for • Catalog • Application notes • product specifications • User manuals please Recycle...
