- Page 1 REFRIGERATORS & FREEZERS MANUAL OF INSTRUCTIONS FOR USE AND INSTALLATION...
- Page 2 Foreword Our compliments on having chosen one of our products, which are the result of the technological experience and continuous research in order to obtain a product which is superior in terms of safety, reliability and performance. This manual contains all the information and advice necessary to operate with maximum safety and efficiency.
-
Page 3: Installation
CONTROLS After receiving the apparatus you should check immediately if there are damages caused during transportation. Unpack the apparatus and make sure that the accessories are enclosed. In case of damages during the transportation make your reservations to the truck driver; within three days you should confirm your reservations with registered mail to the transport company with a copy of the letter STUDIO 54 or the authorized re-sale. -
Page 4: Cleaning And Maintenance
START-UP Connect the apparatus to the electrical power line (220/50) after having checked the voltage (allowance ± 10%) and switch it on by the main switch. CLEANING & MAINTENANCE Wash the inside of the refrigerator with water and neutral detergent. Then dry it carefully and position the slides and shelves according to your needs (at least every six months) Adjust the thermostat or the control board according to enclosure on the desired working temperature (from +15˚C to -2˚C for... -
Page 5: Electrical Wiring
DIAGNOSTICS The alarm condition is always signalled by the buzzer (if present) and by the led of the alarm icon. The alarm signal produced by a faulty thermostat probe (referred to probe 1) is shown as E1 on the instrument display. The alarm signal produced by a faulty evaporator probe (probe 2) is shown as E2 on the instrument display, but from the “Machine Status”... - Page 6 CONDITIONS OF USE PERMITED USE For safety reasons the instrument must be installed and used according to the instruction provided and in the particular, under normal conditions, parts bearing dangerous voltage levels must not be accessible. The device must be adequately protected from water and dust as per the application and must also be accessible via the use of tools (with the exception of the frontlet).
- Page 7 TECHNICAL DATA Frontal panel protection: IP65 Casing: plastic body in resin type PC+ABS UL94 V-0, inspection window in Polycarbonate, buttons in the thermoplastic resin. Dimensions: frontal panel 74x32 mm, depth 60 mm. Installation: on panel, with drilling template 71x29 mm (+0.2/-0.1 mm).
