Summary of Contents for Sonarcom ALL IN APP
- Page 1 ALL IN APP USER MANUAL Sint Ignatiusstraat 134 9120 Kallo (Beveren-Waas) Belgium +32 474 727 135 info@sonarcom.be www.sonarcom.be...
-
Page 2: Product Specifications
Echo amplitude transmission Update sounding measurement ca 6x/seconds Adjustable settings: Bottomfill on/off Autorange on/off Ping speed (5 settings) Full color settings possible ( bottom, background, highlevel, medium level, low level, text ) SONARCOM ALL IN APP Pagina 1... - Page 3 The battery voltage of the Bluetooth receiver on the shore (alarm setting possible) The actual latitude/longitude GPS position/coordinates of the baitboat The scale of the display All these indicators will be displayed in the Google Maps mode SONARCOM ALL IN APP Pagina 2...
- Page 4 Note: latitude and longitude must have a minus sign (-) when the latitude is west of London and longitude south of the meridian line. Example: W41.0011 should be inserted as -41.001. East 004.002 should be without any sign. South 61 degree should be inserted as -61 degrees, North 51 degrees should be inserted without any sign. SONARCOM ALL IN APP Pagina 3...
- Page 5 AP state standby: The autopilot is standby but not active yet. Load a spot and give full throttle for at least 5 seconds. AP state off: The autopilot is disabled. You have manual control of the boat. SONARCOM ALL IN APP Pagina 4...
-
Page 6: Boat Speed
Note: The autopilot has to settle during the first seconds and thus making large turns. Never steer the boat towards shore site, always towards a free area. Remember the autopilot will make a straight line to the spot, any obstruction between start point and waypoint will block the boat. SONARCOM ALL IN APP Pagina 5... - Page 7 You can specify on what level the voice alarm will be given when battery is low. Sound on/off Automatic or manual Bluetooth connection. SONARCOM ALL IN APP Pagina 6...
- Page 8 A long click on the SONAR mode button, in the bottom bar of the screen, will open the SONAR settings menu with following items: Bottom Fill: On/off will give a track over ground, the bottomline will be filled up. (Only on 200khz plot) SONARCOM ALL IN APP Pagina 7...
- Page 9 Text color all indications can be adjusted in color High/medium/low level colors 200 kHz and 455 kHz: each echo has 3 levels: max, medium and low. With adjusting those colors you will get a more detailed picture of the surface. SONARCOM ALL IN APP Pagina 8...
- Page 10 A long click on the Googlemaps mode button, in the bottom bar of the screen, will open the googlemaps settings menu with following items: Save googleSpots: To avoid adding spots, you can disable this feature Google Maps Terrain, Satellite, Normal: 3 modes of Google maps can be selected SONARCOM ALL IN APP Pagina 9...
- Page 11 Check Update. If needed the app will be updated. This is not every day, it’s useless to try to update every day the app. If a update is there, click this line, and when the message “Checking Update” comes, wait until the installation message will show up. SONARCOM ALL IN APP Pagina 10...
- Page 12 Select ‘searching devices’ and wait aprox 30 seconds when the app will show you the found BT module. Select ‘BaitBoatGPS’ to connect. Note: Sometimes the first time you won’t read “BaitBoatGPS” but a blank row. Just select this device and insert pin code 1234 SONARCOM ALL IN APP Pagina 11...
- Page 13 Note: keep the BT module close to the android device: the max distance is 5 meters, but this is depending on the sensitivity of the android device. When the BT link is there a short message will be given and in the upper taskbar the app-icon is visible. SONARCOM ALL IN APP Pagina 12...
