Summary of Contents for Smart-M HDR-8x8-XT
- Page 1 HDR‐8x8‐XT User Manual 4K Ultra-HD 8X8 HDBaseT HDMI Matrix with POE Distribute 8 4K HDMI sources to 8 local monitors and 8 remote displays via HDBaseT (CAT5e/6/7) with IR, RS-232, and TCP/IP control support Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WHAT'S IN THE BOX? INTRODUCTION FEATURES APPLICATIONS TECHNICAL SPECIFICATIONS FRONT PANEL FUNCTIONS EDID REAR PANEL REMOTE CONTROL IR CONTROL SYSTEM 9-10 HDBaseT RECEIVER HARDWARE INSTALLATION POWER OVER ETHERNET (POE) RS-232 CONTROL GLOBAL IR CONTROL HDBaseT LAN SERVING ESTABLISHING AN RS-232 CONNECTION LIMITED WARRANTY STATEMENT WHAT’S IN THE BOX? -
Page 3: Introduction
INTRODUCTION The HDR-8x8-XT with simultaneous CAT5e/6/7 and HDMI outputs connects eight HDMI input sources to sixteen displays. This matrix features eight mirrored HDMI outputs, providing 8 HDMI output ports and 8 CAT-Cable output ports simultaneously. The HDR-8x8-XT supports the transmission of video (resolutions up to 1080p Full HD and 4Kx2K@30Hz) and supports high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio. -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS VIDEO and AUDIO Format HDMI 1.4 Video Bandwidth 297MHz[10.2Gbps] Input Resolution Up to 4K (3840x2160 @ 30Hz) Output Resolution Up to 4K (3840x2160 @ 30Hz) HDMI Connector Type A 19 pin female RJ-45 Connector WE/SS 8P8C Audio Connectors 3.5mm, Coaxial CONTROL Front Panel... -
Page 5: Front Panel Functions
FRONT PANEL FUNCTIONS Figure 5-1 1. LCM: Displays all information regarding individual input settings/output settings and EDID manage- ment 2. IR: IR Receiver window (accepts only the HDR 8x8 -XT remote control signal ). POWER: Press this button to power the device on/off. The LED will illuminate green when the power is on, red when it is in 'Standby' mode. -
Page 6: Edid
EDID EDID. What is it and what is it used for? Under normal circumstances, a source device (digital and analog) will require information about a con- nected device/display to assess what resolutions and features it can produce. Using this information from the display, the source can then cater its output to send only resolutions and features that are com- patible with the attached device/display. -
Page 7: Rear Panel
REAR PANEL Figure 7-1 1. GND: Connect the Housing to ground. 2. IR Matrix IR EXT: if the panel sensor is obstructed or the unit is installed in a closed area out of infrared line of sight, the IR RX receiver included can be inserted into the IR EXT port at the rear to extend the IR sensor range and en- able local control of the matrix. -
Page 8: Remote Control
REMOTE CONTROL 1. Power on /Standby： Press this button for power on the matrix or set it to standby mode. 2. Input port selection area： Press these buttons to select input 1-8. Press forward/backward button will cycle from input 1-8. 3. -
Page 9: Ir Control System
IR CONTROL SYSTEM (IR Call-back of Matrix and Source Devices) The matrix is not only a switcher and extender of multiple HDMI signals to multiple HDMI receivers lo- cated remotely, it also passes IR control signals through the IR call-back system to the matrix and HDMI sources for full, independent control of all connected inputs from output locations. - Page 10 IR CONTROL SYSTEM (Continued) Figure 10-1 At Matrix end: Insert the 3.5mm jacks of the IR TX Emitters included with the unit into the IR TX Emitter ports at the rear of the matrix according to input. The IR signal is added to the HDMI of the input device so, for example, if the user is watching Blu-ray on input 1, the IR signal will be directed through the IR TX1 socket to control the device.
-
Page 11: Hdbaset Receiver
HDBaseT RECEIVER Figure 11-1 1. OUTPUT LED: The output status indicating lamp. This red LED illuminates when the TV plugs in with HDMI cable. 2. HDMI OUT: HDMI output port. This slot is where you connect the HDTV or monitor with HDMI cable. 3. -
Page 12: Hardware Installation
IR RX, use double-sided adhesive tape to stick emitters at each display at a desired place that will receive a remote signal. 7. For power, plug in the source first, followed by the HDR-8X8-XT Matrix (power supply included), fol- lowed by the display receivers, followed by each output connected. -
Page 13: Power Over Ethernet (Poe)
POWER OVER ETHERNET (POE) This system can run with only the HDR-8X8-XT powered, RXs do not need to be powered. Figure 13-1 RS-232 CONTROL Supports Bidirectional RS232 control functions. This system provides 8 channels of RS232 pass through functions. Connected equipment can be controlled through these channels. - Page 14 GLOBAL IR CONTROL Use the IR All input port to control all TVs at the same time. Figure 14-1 The IR Blaster (IR TX) connect to the IR All output port, At the far end can use DVD Remote control DVD, but not at the same time.
- Page 15 HDBaseT LAN SERVING The matrix has an Ethernet port that when connected to the Internet will provide Internet connections to the 8 CAT5e/6/7 Output ports. Figure 15-1...
- Page 16 ESTABLISHING AN RS-232 CONNECTION Before you start: Controlling a Smart-AVI device via RS-232 requires an RS-232 card installed on your computer or a USB to RS-232 adapter. Below are instructions on how to create an RS-232 connection between a PC and the Smart-AVI device.
- Page 17 LIMITED WARRANTY STATEMENT A. Extent of limited warranty Smart‐AVI Technologies, Inc. warrants to the end‐user customers that the Smart‐AVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. Smart‐AVI limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. Improper or inadequate maintenance or modifications b. Operations outside product specifications c. Mechanical abuse and exposure to severe conditions If Smart‐AVI receives, during applicable warranty period, a notice of defect, Smart‐AVI will at its discretion replace or repair defective product. If Smart‐AVI is unable to replace or repair defective product covered by the Smart‐AVI warranty within reasonable period of time, Smart‐AVI shall refund the cost of the product. Smart‐AVI shall have no obligation to repair, replace or refund unit until customer returns defective product to Smart‐AVI. Any replacement product could be new or like new, provided that it has functionality at least equal to that of the product being replaced. Smart‐AVI limited warranty is valid in any country where the covered product is distributed by Smart‐AVI. B. Limitations of warranty To the extant allowed by local law, neither Smart‐AVI nor its third party suppliers make any other warranty or condition of any kind whether expressed or implied with respect to the Smart‐AVI product, and specifically disclaim implied warranties or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. C. Limitations of liability ...
- Page 18 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no war‐ ranty of any kind with regard to this material, including but not limited to, implied warranties of merchant‐ ability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for inci‐ dental or consequential damages in connection with the furnishing, performance or use of this material. No part of this document may be photocopied, reproduced, or translated into another language without prior written consent from SmartAVI Technologies, Inc. 20161024 ...
