Summary of Contents for Rockwell 1732DS-IB8XOBV4
-
Page 1: Table Of Contents
Installation Instructions ArmorBlock Guard I/O DeviceNet Safety Modules Catalog Numbers 1732DS-IB8XOBV4, 1732DS-IB8 Topic Page Important User Information Environment and Enclosure Preventing Electrostatic Discharge Before You Begin Module Identification and Dimensions Observing Precautions for Correct Use Observing Precautions for Safe Use... -
Page 2: Important User Information
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software described in this manual. Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is prohibited. -
Page 3: Environment And Enclosure
ArmorBlock Guard I/O DeviceNet Safety Modules 3 Environment and Enclosure This equipment is intended for use in overvoltage Category II ATTENTION applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11. -
Page 4: Preventing Electrostatic Discharge
4 ArmorBlock Guard I/O DeviceNet Safety Modules Preventing Electrostatic Discharge This equipment is sensitive to electrostatic discharge, which can ATTENTION cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. •... -
Page 5: Before You Begin
Never use the products for an application involving serious risk to life or property without first verifying that the system as a whole has been designed to address the risks and that the Rockwell Automation product is properly rated and installed for the intended use within the overall equipment or system. - Page 6 6 ArmorBlock Guard I/O DeviceNet Safety Modules 1732DS-IB8XOBV4 Module Dimensions 68.7 mm 168.6 mm (6.64 in.) (2.71 in.) 31626 179 mm (7.05 in.) 1732DS-IB8 Module Dimensions 68.7 mm 168.6 mm (6.64 in.) (2.71 in.) 179 mm (7.05 in.) 31627 Publication...
-
Page 7: Observing Precautions For Correct Use
ArmorBlock Guard I/O DeviceNet Safety Modules 7 Observing Precautions for Correct Use Read this for information related to operating directions after reading the Guard I/O DeviceNet Safety User Manual, publication 1791DS-UM001. Do not use the unit in locations subject to the following: •... - Page 8 8 ArmorBlock Guard I/O DeviceNet Safety Modules • Use only appropriate components or devices complying with relevant safety standards corresponding to the required level of safety categories (safety integrity level). Conformity to requirements of safety category (safety integrity level) is determined as an entire system.
- Page 9 ArmorBlock Guard I/O DeviceNet Safety Modules 9 Controlling Devices - Sample Requirements Device Requirement Allen-Bradley Bulletin Safety Components Emergency Use approved devices with direct opening Bulletin 800F, 800T stop switch mechanism complying with IEC/EN 60947-5-1. Door Use approved devices with direct opening Bulletin 440K, 440G, or interlocking mechanism complying with IEC/EN...
-
Page 10: Install The Module
10 ArmorBlock Guard I/O DeviceNet Safety Modules Install the Module Read this section for installation-related information. Set MAC ID Set the MAC ID by using the rotary switches. The MAC ID is set to 63 by default. Wiring the Module Follow these guidelines when wiring the module: •... -
Page 11: Working With I/O Connectors
Working with I/O Connectors See the figure that shows connectors. The modules have M12 female I/O connectors. Input and Output Configuration Input Configuration Output Configuration (1732DS-IB8XOBV4 module only) Signal Test Output n+1 Signal Safe Input n+1 Output +24V DC Power... -
Page 12: Terminal Positions
Output +24V DC Power 44044 Drain Input +24V DC Power Female Input Power Common Output Power Common CAN-H 44043 1732DS-IB8XOBV4 module only. CAN_L Terminal Positions See the figure and table that show terminal positions. 44121 Publication 1732DS-IN001D-EN-P - September 2009... - Page 13 ArmorBlock Guard I/O DeviceNet Safety Modules 13 Terminal Positions 1732DS-IB8XOBV4 and 1732DS-IB8XOBV4 Module Only 1732DS-IB8 Modules Test Output 1 S+/24V DC Safety Input 1 Safety Output 1 (Switch 24V DC Common) Input Common L-/24V DC Common Safety Input 0 Safety Output 0...
-
Page 14: Interpret The Status Indicators
The input power is out of Check your configuration, yellow out of specification. wiring, and voltages and apply specification the changes. 24V DC Output Power Indicator (1732DS-IB8XOBV4 module only) State Status Description Recommended Action No power No power is applied. Apply power to this section. - Page 15 ArmorBlock Guard I/O DeviceNet Safety Modules 15 Module Status Indicator State Status Description Flashing Module needs commissioning due to Module is unconfigured. green missing, incomplete, or incorrect configuration Flashing Recoverable fault or user-initiated The module has detected a firmware update in progress recoverable fault or user-initiated firmware update is in progress.
- Page 16 16 ArmorBlock Guard I/O DeviceNet Safety Modules Network Status Indicator State Status Description Flashing One or more I/O The module detected a recoverable network fault connections in or user-initiated firmware update is in progress. timed-out state or user-initiated firmware update in progress Solid red Critical link failure The module detected an error that prevents it from...
- Page 17 ArmorBlock Guard I/O DeviceNet Safety Modules 17 Safety Output Status Indicator (1732DS-IB8XOBV4 module only) State Status Description Recommended Action Safety output The safety output is off Turn the safety output on or wait off or module or the module is being for the module to be configured.
-
Page 18: Specifications
18 ArmorBlock Guard I/O DeviceNet Safety Modules Specifications Technical Specifications - 1732DS-IB8XOBV4, 1732DS-IB8 Attribute 1732DS-IB8XOBV4, 1732DS-IB8 Safety Input Input type Current sinking Voltage, on-state input, min 11V DC Current, on-state input, min 3.3 mA Voltage, off-state input, max 5V DC Current, off-state, max 1.3 mA... - Page 19 8 A @ 40 °C (104°F) 6 A @ 60 °C (140 °F) outputs per module Pilot duty rating DC-14 Pilot Duty (1732DS-IB8XOBV4 module only) Number of outputs 4 dual channel Includes the presence of a single P stuck-high or M stuck-low short.
- Page 20 20 ArmorBlock Guard I/O DeviceNet Safety Modules General Specifications - 1732DS-IB8XOBV4, 1732DS-IB8 Attribute 1732DS-IB8XOBV4, 1732DS-IB8 Product temperature versus current derating -20 °C 40 °C 50 °C 60 °C 44199 Product Temperature Versus Current Derating (combined current from both input and output supplies)
- Page 21 ArmorBlock Guard I/O DeviceNet Safety Modules 21 Environmental Specifications - 1732DS-IB8XOBV4, 1732DS-IB8 Attribute 1732DS-IB8XOBV4, 1732DS-IB8 Temperature, operating -20…60 °C (-4…140 °F) IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal...
- Page 22 22 ArmorBlock Guard I/O DeviceNet Safety Modules Environmental Specifications - 1732DS-IB8XOBV4, 1732DS-IB8 Attribute 1732DS-IB8XOBV4, 1732DS-IB8 Conducted RF immunity 10V rms with 1 kHz sine-wave 80%AM from IEC 61000-4-6 150 kHz…80 MHz EFT/B immunity ±4 kV at 5 kHz on power ports IEC 61000-4-4 ±3 kV at 5 kHz on signal ports...
-
Page 23: Additional Resources
DNET-UM004 • Guard I/O DeviceNet Safety Modules User Manual, publication 1791DS-UM001 You can view or download publications at http://literature.rockwellautomation.com. To order paper copies of technical documentation, contact your local Rockwell Automation distributor or sales representative. Publication 1732DS-IN001D-EN-P - September 2009... - Page 24 New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
