- Page 1 Vista SmartCF Digital Video Transmission System VLS2-02RTCF3G Quick Installation Guide...
-
Page 3: Limited Warranty
Vista is not liable for any damages such as financial losses or delayed or terminated business resulting from the use or misuse of this manual, even if Vista or a representative of Vista was made aware of the possibility of such damage. - Page 4 Quick Installation Guide Vista This page is intentionally left blank. SmartCF...
-
Page 5: Table Of Contents
Vista Quick Installation Guide Table of Contents SmartCFRT Quick Installation Guide Front View and Description Rear View and Description Included in Delivery Optional Accessories Standard Switching for Control Inputs Wiring Variants for Voltage-monitored Control Inputs Initial Setup Operation SmartCF... - Page 6 Quick Installation Guide Vista This page is intentionally left blank. SmartCF...
-
Page 7: Smartcfrt Quick Installation Guide
Version Publication Date This quick installation guide describes the SmartCF device version 4.08 and was created in January 2014. See the installation CD or our website (http://www.vista-cctv.com) for the current firmware version. Commissioning Information on commissioning the device follows on page 9. -
Page 8: Front View And Description
Quick Installation Guide Vista Front View and Description Item Labeling/description Function Main power switch Switch On/Off During the device shutdown process, any ongoing write operations on the storage medium are first concluded before the video system is finally shut down. -
Page 9: Rear View And Description
Vista Quick Installation Guide Rear View and Description Item Labeling/description Function V in Video input 1: BNC socket for connecting colour or B/W video. Switching between CCIR/PAL and EIA/NTSC mode is automatic. V out Video output 1: Active loop through output - BNC socket - for direct connection of additional video systems/monitors. - Page 10 Quick Installation Guide Vista Labeling/description Type Function RS-232 Tx Serial TxD Use this terminal to connect 1 remote control camera or one other compatible device (e.g. matrix) with RS-232 RS-232 Rx Serial RxD interface. 12 V + Output, 12 V...
-
Page 11: Included In Delivery
Vista Quick Installation Guide Included in Delivery Component SmartCF SmartCF basic device External switching power supply with colour-coded wires for connection to SmartCF Crossover network cable USB connection cable Installation CD including all necessary software packages, software and device manuals in online format... -
Page 12: Standard Switching For Control Inputs
Quick Installation Guide Vista Standard Switching for Control Inputs The SmartCF has a number of control inputs (Al a/d, Control in1, Control in2, Aux in). However these inputs are not galvanically isolated from the operating voltage of the device. Depending on the configuration, these can be activated by "Normally closed" or "Normally opened" contacts. -
Page 13: Initial Setup Operation
Vista Quick Installation Guide Initial Setup Operation 1.7.1 Installation of SmartControl The scope of delivery (See "Included in Delivery" on page 7) for your SmartCF includes the installation CD. Install SmartControl to commission the device. To operate the software, the user requires read/write rights on the receiver PC (administrator rights). - Page 14 1.7.3 TCP/IP Crossover Connection from SmartControl to the Device Preparing the receiver PC Your Vista SmartCF can be accessed when in its default status or following a device reset using the following IP address: 192.168.31.95 Note: The precondition for communication via a TCP/IP crossover network cable between the SmartCF and the receiver PC with SmartControl is that the devices are located in the same IP address group (here: 192.168.31.x).
- Page 15 Vista Quick Installation Guide 1.7.4 Parameter settings for the device After establishing the connection to the device, click on the Setup button to open the Recorder settings dialogue window. Selected options for program settings User rights: User Network settings: Connections\Network (TCP/IP) 3G/UMTS programming (only with 3G/GPS Module): Connections\Wireless WAN (See "Programming of...
- Page 16 Quick Installation Guide Vista APN (Access Point Name): The APN access data should normally be in the following order: 1,"IP","<PROVIDER APN>" Example data for German providers: Vodafone:1,"IP","web.vodafone.de" T-Mobile: 1,"IP","internet.t-d1.de" or 1,"IP","internet.t-mobile" E-Plus: 1,"IP","internet.eplus.de" o2: 1,"IP","surfo2" Dial in number: The standard dial in number for Internet connections via 3G/UMTS or GPRS is *99#.
- Page 17 Vista Quick Installation Guide 1.7.6 Testing the Alarm After changing the settings, it is recommended that testing is carried out to confirm device operation. Note: As an example, an alarm via the Aux in1 input is described (see ”Aux in1” in "Rear View and Description"...
- Page 18 Quick Installation Guide Vista This page is intentionally left blank. SmartCF...
- Page 20 Vista Norbain SD Ltd 210 Wharfdale Winnersh Triangle Wokingham Berkshire RG41 5TP 8.3347 England Printed in Germany Phone: +44 (0) 118 912 5000 Quick Installation Guide 4.08 Fax: +44 (0) 118 912 5001...
