Summary of Contents for Nextiva AudioCodes Mediant 500
- Page 1 1 | P a g e AudioCodes Installation Guide nextiva.com/support...
-
Page 2: Table Of Contents
Mounting the Mediant 500 on a server rack ....................2 Installing the Mediant Series SBC ........................3 Status Lights ..............................5 Logging in to the Web Interface from a connected computer ..............5 Provisioning the Device ............................6 Factory Reset ................................9 © Nextiva, All Rights Reserved... -
Page 3: Installation
• 19 in. Rack Mounting Kit Mounting the AudioCodes Mediant 500 on a Server Rack You can install the Mediant 500 on to a standard server rack using the supplied 19 in. Rack Mounting Kit, which consists of two mounting brackets, one left and one right mounting bracket, and screws. -
Page 4: Installing The Mediant Series Sbc
2. Connect one end of a second Ethernet cable to one of the other LAN ports on the front of the Mediant 500. Connect the other end of the cable to the computer you are using to configure the device. © Nextiva, All Rights Reserved... - Page 5 Connection (Figure 1-3). Figure 1-3: PBX with a PRI Connection Network Diagram 3. Connect one end of the AC power cable to the back of the Mediant 500 and the other end to a three-pronged power source. © Nextiva, All Rights Reserved...
-
Page 6: Status Lights
NOTE: If you have already provisioned the Mediant 500, you will have to enter 192.168.1.1 as the IP Address to access it. 3. Log in with Admin as the Username and Admin as the Password. © Nextiva, All Rights Reserved... -
Page 7: Provisioning The Device
6 | P a g e Provisioning the Device By default, the AudioCodes Mediant 500 should be prepared to auto-provision before you receive it. But if the device should ever be reset to factory defaults, then provisioning the device may become necessary. - Page 8 10. Click Load CLI Script File to the right of Choose File, and then click OK when the pop-up message appears saying the device will reset. After a few seconds, the Mediant 500 restarts. Proceed to the next step quickly to avoid having to reboot the Mediant 500 again. © Nextiva, All Rights Reserved...
- Page 9 6. Click Call Routing Status on the left side of the screen. If the Mediant 500 is properly provisioned, Proxy Set ID 2 should display bt.voipdnsservers.com (208.73.144.74) in the IP Address column and OK in the State column (Figure 2-4). Figure 2-4: The Call Routing Status Screen © Nextiva, All Rights Reserved...
-
Page 10: Factory Reset
6. Click Restore Defaults in the middle of the screen (Figure 3-1). A pop-up message appears warning you that you may lose connection to the device. Click OK to confirm you want to restore the default settings. Figure 3-1: The Configuration File Screen © Nextiva, All Rights Reserved... - Page 11 After the Mediant 500 has been restored to factory defaults, please contact Nextiva Support to make sure the custom tags in your Nextiva account are correct, and then upload the skinny config file using the instructions in the Provisioning section.
