Summary of Contents for ATLAS LABS A-9
- Page 1 A-9 Antenna LTE, GPS, Wi-Fi, and Bluetooth Multi-Band Antenna Installation Guide A-9 Antenna Installation Guide October 2016...
- Page 2 ©2012 to 2016 Atlas Labs LLC. All Rights Reserved. Atlas Labs reserves the right to modify the equipment, its specification, or this manual without prior notice, in the interest of improving performance, reliability, or servicing. At the time of publication all data is correct for the operation of the equipment at the voltage and/or temperature referred to.
-
Page 3: Table Of Contents
1. Table of Contents Table of Contents ................................3 Product Overview................................4 1.1. Cellular Network Support ............................5 1.2. MIMO (Multiple-Input and Multiple-Output)....................5 Vehicle Installation................................6 2.1. Antenna Placement ..............................7 2.1.1. Coax Cable Lengths ............................8 2.2. Ground Plane ................................9 Antenna Mounting................................ -
Page 4: Product Overview
The A-9 incorporates specialized antenna elements for cellular, GPS, and Wi-Fi/Bluetooth frequencies in a single low-profile, sealed enclosure. Figure 1. The Atlas Labs A-9 antenna combines cellular LTE, GPS, and Wi-Fi/Bluetooth antennas in a low profile, sealed enclosure. Common applications include deployment of •... -
Page 5: Cellular Network Support
• T-Mobile • US Cellular The A-9 may be used with a wide variety of cellular technologies including, but not limited to LTE, HSPA/HSPA+, UMTS, EV-DO, GSM, and CDMA. 1.2. MIMO (Multip le-Input an d Mult iple-Outp ut) When used with 4G/LTE or other high bandwidth devices, two A-9 antennas should be used per transmitter with each A-9 mounted a minimum of 17 inches apart (based on single wavelength separation at 700 MHz) to meet MIMO requirements. -
Page 6: Vehicle Installation
2. Vehicle Installation Antenna placement is critical to achieving optimal RF (radio-frequency) performance. When planning vehicle installations, the following considerations should be made: • Mount antennas as high as possible on the vehicle, away from other antennas and with minimal obstruction on all sides. -
Page 7: Antenna Placement
2.1. Antenna Placement Optimal placement is along the centerline of the roof (Figure 1) or in parallel columns down the length of the vehicle (Figure 2), in a position resulting in the shortest cable length possible. Maintain at least 17” separation between antennas. -
Page 8: Coax Cable Lengths
Use the shortest length allowing enough distance for service loops at both the antenna and modem/radio. Low-loss feed cables may be obtained from Atlas Labs at various lengths, enabling installers to minimize cable runs without the necessity of specialty crimping tools. -
Page 9: Ground Plane
2.2. Ground P lane Transmitting antennas require an electrically conductive ground plane to allow proper signal propagation. Typically the vehicle’s metal frame functions as the ground plane, however some vehicles such as RVs, buses, and ambulances with fiberglass roofs will need a separate ground plane plate. Antenna Installation Guide | Page 9... -
Page 10: Antenna Mounting
3. Antenna Mounting The A-9 is a through-hole antenna, suitable for mounting on surfaces up to 3/8” thick. To install the A-9, perform the following: 1. Select appropriate position on vehicle roof ensuring clearance from obstructions and adequate distance from other antennas. Verify roof underside is clear of wires, cables, support posts, or other obstructions. -
Page 11: Appendix A - Service & Support
Product Warranty, RMA and Cont act Inf o rmation Atlas Labs LLC guarantees that every A-9 antenna will be free from physical defects in material and workmanship for one (1) year from the date of purchase when used within the limits set forth in this manual.
