Page 1: Installation Guide
BACnet Gateway (435) Installation Guide Doc. No.: D007500, issue 1 2017-03-30... - Page 2 Copyright © 2017 Helvar Ltd. All rights reserved. No part of this document may be reproduced in any form or by any means – graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems – without the written permission of the publisher.
-
Page 3: Table Of Contents
Button and switches ..........................3 1.3. SYSTEM OVERVIEW ........................4 1.3.1. Helvar devices and DALI networks ....................... 5 1.3.2. BACnet/IP network ..........................5 2. HARDWARE GUIDE ..........................6 3. INSTALLATION ........................... 8 3.1. INSTALLING THE UNIT ......................8 3.2. CONNECTIONS AND WIRING ....................8 3.2.1. -
Page 5: Introduction
Introduction The 435 BACnet Gateway provides a simple interface to a Helvar router system and allows lighting system data to appear in a BACnet Building energy Management System (BeMS). Note: Typically, individual systems (energy control, lighting, boiler and air-conditioning systems, etc.) are measured separately for CO accountability. -
Page 6: Device Limits And Compatibility
The 435 BACnet Gateway has been specifically designed to expose the ‘router’, ‘group’ and ‘device’ parameters from Helvar routers in a designated workgroup through the TCP/IP network. The BACnet/IP BMS can use this information to control and monitor the lighting, energy and environmental conditions. -
Page 7: Front Panel Leds
1.2.2. Button and switches The BACnet Gateway is fitted with a recessed button for rebooting the unit, and with a bank of four DIP switches. The bank of DIP switches is not functional in this version. While the reset button does not erase any configuration, we recommend that you use it only if the software reboot fails. -
Page 8: System Overview
The BACnet Gateway provides direct interface between Helvar routers, including the devices connected to them (such as ballasts, LED drivers, luminaires and sensors), and a BACnet/IP BMS. Thus, the BACnet/IP BeMS can access the values recorded in the Helvar 905, 910 and 920 routers and in the DALI devices. -
Page 9: Helvar Devices And Dali Networks
It operates on a client/server principle: the BACnet Gateway is the server, and either a BACnet device or the BACnet Explorer is the client. The network uses standard cat 5e cabling to transfer ‘service’ requests from each client to the server, which performs the service and then reports the result to the client. -
Page 10: Hardware Guide
Hardware guide This hardware provides an interface between Helvar devices (with connected products) communicating via the DALI protocol and BACnet (BACnet/IP) BMS communicating via Ethernet protocol. General Weight: 330 g per unit, including DIN Rail clips 410 g shipped, including DIN Rail clips Power input: 9 VDC –... - Page 11 Dispose of the product and packaging according to WEEE Directive at an appropriate recycling centre. All parts are recyclable. The printed circuit board may be sent to any PCB recovery contractor to recover any appropriate metals. Helvar 435 BACnet Gateway: Installation Guide...
-
Page 12: Installation
Installation This section explains the process of fitting the 435 BACnet Gateway in the required position and location. It also describes how to connect the cables to ensure that the unit can communicate via the BACnet/IP BeMS network and the connected devices. Finally, it gives the specific wiring conventions used by the connected communications protocols and the hardware fitted to the unit. -
Page 13: Power Supply
‘crossover’ cable is required. RJ45 MALE FROM RJ45 SIGNAL COLOUR CODE TO RJ45 PIN NO. (EIA/TIA 568B) PIN NO. White/Orange Transmit+ Pin 1 Transmit– Orange Receive+ White/Green Blue White/Blue Receive– Green White/Brown Helvar 435 BACnet Gateway: Installation Guide... - Page 14 RJ45 MALE FROM RJ45 SIGNAL COLOUR CODE TO RJ45 PIN NO. (EIA/TIA 568B) PIN NO. Brown The image shows the flat side of RJ45 plug. Helvar | Data is subject to change without notice.
-
Page 15: Order Codes
Order Codes ORDER CODES DESCRIPTION BACnet Gateway AMR1 PSU 24 VDC 1 A power supply 435+AMR1 PSU Combined above 2 items sold as a pack Helvar 435 BACnet Gateway: Installation Guide...
