- Page 1 USE R M A NUA L...
- Page 2 Welcome to the world of X2 PREMIUM NANO User’s Manual 812X2VV160101...
-
Page 3: Safety Instructions
General Safety Information SAFETY INSTRUCTIONS This OTT has been manufactured to meet international safety standards. Please read the following safety instructions carefully before you handle the STB. ■ MAIN SUPPLY AC95-250V~,50/60Hz ■ OVERLOADING Do not overload a wall outlet, extension cord or adapter as this may result in electric shock or fire. ■... - Page 4 General Safety Information ■ LOCATION Keep the OTT indoors and away from potential hazards, such as houseplants, rain and direct sunlight. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifier) that product heat. ■...
-
Page 5: Table Of Contents
Contents Before Your Begin ----------------------------------------4 Main Menu ------------------------------------------------19 General Features --------------------------------4 Menu Contents ----------------------------------19 Accessories ---------------------------------------4 System Setup -----------------------------------20 General Description of Your OTT ------------4 5.2.1 Account Setting ---------------------------------20 2.1.1 Front Panel ----------------------------------------5 5.2.2 Network (Wi-Fi Setting) -----------------------21 2.1.2 Rear Panel -----------------------------------------6 5.2.2 Network (PPoE Setting) ----------------------21... -
Page 6: Before Your Begin
Before Your Begin 1.1 GENERAL FEATURES Reception of High definition and standard definition digital TV Channel through Internet TV Service. ● ● Multiple output resolution modes: 1080p, 1080i, 720p, 576p, 576i HDMI output ● Supported H.264. ● Internet TV Channel Memory up to: 3,000. ●... -
Page 7: Front Panel
Before Your Begin 2.1 GENERAL DESCRIPTION OF YOUR PREMIUM NANO 2.1.1 FRONT PANEL ■ IR Sensor: Receives the IR commands from remote control unit. ■ DISPLAY: Display for Channel Name and other information’s. ■ CH (▲/▼) Buttons: Changes channels or move cursor up/down. -
Page 8: Rear Panel
Before Your Begin 2.1 GENERAL DESCRIPTION OF YOUR PREMIUM NANO 2.1.2 REAR PANEL ■ POWER: Connect to the AC mains power adapter. The input AC voltage range is 95V to 250V, 50/60Hz power supply. ■ ETHERNET: Connect to RJ45 Cable. -
Page 9: Remote Control Unit
Before Your Begin 2.1 GENERAL DESCRIPTION OF YOUR PREMIUM NANO 2.1.3 REMOTE CONTROL UNIT INSERT BATTERIES Before using the remote control unit, first time please insert the batteries according to the instructions below: Open the battery compartment on the back of the Remote Control Unit. -
Page 10: Remote Control Unit
Before Your Begin 2.1 GENERAL DESCRIPTION OF YOUR PREMIUM NANO 2.1.3 REMOTE CONTROL UNIT To Enter Standby Mode: Standby/On, Standby/Off Mute Audio to Zero with one button press Play the video files from USB To change the TV Screen mode between 1080i,1080p,720, DISPLAY NTSC &... -
Page 11: Remote Control Unit
Before Your Begin 2.1 GENERAL DESCRIPTION OF YOUR PREMIUM NANO 2.1.3 REMOTE CONTROL UNIT Connect to Wireless Network Wi-Fi Show the information INFO When watching a channel, change channels or move to the next higher or lower item in the menu... -
Page 12: Connections
Do not install the OTT in the places as follows: Vibrating place, direct sunrays, humid place, too high or low temperature, and no ventilated place. CONNECTING THE PREMIUM NANO (OTT) TO HIGH DEFINITION TV To connect OTT with your TV, you can use following connection via HD cable. -
Page 13: Connecting To A/V Normal
Connections 3.2 CONNECTING YOUR PREMIUM NANO (Normal TV) CONNECTING THE PREMIUM NANO (OTT) TO NORMAL TV To connect OTT with your TV, you can use following connection via RCA (1X3) A/V Cable. Connecting to TV with AV Cable (Audio / Video / Input) - Normal / Basic Quality... -
Page 14: Other Connect
Connections 3.3 CONNECTING YOUR PREMIUM NANO (Other Connect) CONNECT TO EXTERNAL SENSOR, ETHERNET CABLE OR Wi-Fi ANTENNA (OPTIONAL) Wi-Fi Antenna / IR Digital Sensor / Optional Ethernet Connect to the Optional Cable Power Supply... -
Page 15: Usb Connect
Connections 3.4 CONNECTING YOUR PREMIUM NANO (USB Connect) CONNECT TO USB DEVICE (EXTERNAL USB H.D.D., USB FLASH DISK) OPTIONAL USB Flash Disk or External H.D.D. or other Media Player... -
Page 16: All Connection
Connections 3.5 CONNECTING YOUR PREMIUM NANO (All Connection) Wi-Fi Antenna RJ45 Cable External IR Digital Sensor HD TV AV TV Power Supply Digital Amplifier... -
Page 17: Getting Started
Getting Started 4.1 FAST OPERATION Once OTT start working, the boot logo will display on screen, when boot logo disappears then ■ you need do follows. ■ 1-Press Wi-Fi button on RCU to select your home Wi-Fi network. ■ 2-Go to Menu – Settings – Account – Start Login – Press OK. ■... -
Page 18: Wireless Connection (Wi
CONNECT OK! will show on top right of screen. NOTES: ■ Your PREMIUM NANO support Wireless Network. ■ Once you connect into Wi-Fi Network the PREMIN NANO will save the Network Key and will make auto connection to network (WHEN NETWORK ACTIVE AND ON RANGE). -
Page 19: Online Software Update
Getting Started 4.3 ONLINE SOFTWARE UPDATE We suggest you to check for software update every period due new software will improve and fix some small bugs (If Appears). -
Page 20: Online Software Update
Getting Started 4.3 ONLINE SOFTWARE UPDATE Following steps how to operate software update through internet service. ■ Make sure you already connected to active internet service. ■ Menu – Setting – System Setting – Internet S/W Update - Press OK. ■... -
Page 21: Main Menu
Main Menu 5.1 MENU CONTENTS PREMIUM NANO MENU CONTENTS 7 LISTS AS FOLLOWS ■ System Setup ■ Internet Apps ■ Online Movies ■ Internet TV ■ TV Episodes ■ Listen Music Live Radio ■... -
Page 22: System Setup
Main Menu 5.2 SYSTEM SETUP This list contents: 5.2.1 ACCOUNT (ACCOUNT SETTING) 1 - CURRENT USER CODE: You can check your current account period time (Start active & End date). 2 - RENEW USER CODE: Once your User Code period EXPIRED, please make following steps: Take CLEAR photo of Account Setting page and send ■... -
Page 23: Network (Wi-Fi Setting)
Main Menu 5.2 SYSTEM SETUP 5.2.2 NETWORK (NETWORK SETTING) ■ Wi-Fi SETTING To check the Wi-Fi network list and connect into Wi-Fi networks for more details. ■ PPOE SETTING To test current internet if active or not, this service optional. -
Page 24: Network (Network Setting)
Wired connection. 2 - WIRED / Wi-Fi To change the connection from WIRED into Wi-Fi you need to disconnect the cable out from RJ45 Port on Premium Nano rear panel before switching into Wi-Fi connection. -
Page 25: Av Setting
■ TV STANDARDS: For modify HD output resolution to TV from 576i up to 1080p-60Hz, be noticed the default resolution of Premium Nano it’s 1080i-60Hz. ■ TV RATIO: This function to change the screen type to match the TV between 4:3 type and 16:9 TV type ■... -
Page 26: Menu Setting
Main Menu 5.2 SYSTEM SETUP 5.2.4 MENU (SETTING) ■ TRANSPARENCY To modify the transparent of menu lists. ■ OSD TIMEOUT This functions for menu lists disappear time on screen. ■ MENU LANGUAGE You can select your preferred language to show on all menu between (English, Arabic, Farsi, French, German, Italian, Portuguese, Russian and Spanish) -
Page 27: Time Setting
■ TIME: This filed can’t modify until change the Mode: Manual. ■ TIME ZONE: You can select your current time zone, Premium Nano will update the time once connect to active internet service, this filed can’t modify on Mode: Manual. -
Page 28: Software Upgrade
■ File Path press OK to select software update file. ■ Press Start and wait few minutes until Premium Nano restart. NOTE: Please be careful to keep the power on and power cord plugged in during software update. If the power is off during the software update,... -
Page 29: Factory Reset
Main Menu 5.2 SYSTEM SETUP 5.2.7 FACTORY (RESET): To return all settings of Premium Nano into factory condition in case of wrong enter settings or any FAILURE, once you select Factory reset all settings will return into factory settings. 5.2.8 SYSTEM (SETTING): To show the current software details and Internet S/W Update. -
Page 30: Usb File
5.3.1 USB FILE You can add your Music, Videos, Picture, Text once you add your file into USB Disk then you can play it directly on your Premium Nano. 5.3.2 WEATHER Show your preferred city weather condition Green (ADD) ●... -
Page 31: Youtube
Main Menu 5.3 INTERNET APPS 5.3.3 YOUTUBE To show the YouTube videos. 5.3.4 GOOGLE MAPS To show countries live Satellite maps. -
Page 32: Local Iptv
Main Menu 5.3 INTERNET APPS 5.3.5 LOCAL IPTV To add user IPTV links ■ Add your links into iptvlist.txt ■ Press RED Import to copy the user IPTV list into internal memory. Once the list uploaded, it will not disappear ■... -
Page 33: Internet Tv
Main Menu 5.5 INTERNET TV This Service available only when USER CODE active, if your USER CODE Expired this service will disable, To Operate this service press OK and wait few seconds to connect into our FTP Servers to check your OTT. User Code active and download the Internet TV list. -
Page 34: Listen Music
Main Menu 5.7 LISTEN MUSIC This Service available only when USER CODE active, if your USER CODE Expired this service will disable, TV Series include various Music Albums, select the song and press OK to start the music you would like to listen it online also you can add the songs you like to listen it later by press Recall (Add/ Del Fav.) to add the Song into Fav. -
Page 35: Live Radio
Main Menu 5.8 LIVE RADIO This Service available only when USER CODE active, if your USER CODE Expired this service will disable, TV Series include various Internet Radios, select the radio station and press OK to start the web radio you would like to listen it online also you can add the radio stations you like to listen it later by press Recall (Add/ Del Fav.) to add the radio station into Fav. -
Page 36: Troubleshooting
Troubleshooting Digital communications involve the simultaneous transfer and processing of large amounts of data. digital TV OTT are “close relatives” to personal computers, and their lifestyle is somehow similar. That means that it may also happen to OTT that it “hangs up” like a PC without prior warning and without a visible reason. If this should happen please disconnect the unit from the wall outlet. -
Page 37: Specifications
Speciation's VIDEO DECODING PARAMETERS MPEG-2 ISO/IEC 13818-2 MP@ML & MP@HL MPEG-4 Part10, AVC High profile level 4.1 Aspect Ratio 4:3, 16:9, Resolution Max.1920x1080p AUDIO DECODING PARAMETERS Audio Decoding ISO/IEC 13818-3 Layer I & II & III Operating Mode Mono, Stereo, AC3 down- mixing Sampling Frequency 32, 44.1, 48KHz BASEBAND VIDEO/AUDIO OUTPUT... -
Page 38: Specifications
Speciation's FRONT PANEL GENERAL DATA 4 Digits LED Channel No. Display Input Power Voltage AC95~250V, 50/60Hz 3 Buttons Standby, Ch. Down/Up Power Consumption Standby Minimum power IR Sensor 8KHz Dimension (W x D x H) 112.5 X 815 X 25.80MM USB (Side) Port USB A type connector Weight... -
Page 39: Easy & Quick Installation
Easy & Quick Installation Now, your Premium Nano is ready for your use!
