- Page 1 10” Portable DVD Player with USB & SD Card Slot MODEL NUMBER: 73848 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section 2-3. General Information & Safety Instructions Contents & Features 5-6. Controls Key Functions Getting Started • Basic DVD Operation • Connecting to a TV Charging the DVD player Using USB & SD slot • Memory Cards • USB Memory Stick 10-15. -
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality MAXTEK product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. -
Page 4: General Information & Safety Instructions
General information & Safety Instructions CAUTION: Safely secure any excess wiring to avoid trip hazards, tangling or possible damage to this product. This remote control is powered by 1 x ‘CR2025’ battery. Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. - Page 5 General information & Safety Instructions Please read the following safety information before use. C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN • To avoid risk of electric shock do not attempt to open this appliance. •...
-
Page 6: Contents & Features
Contents & Features Contents 1 x 10” DVD player 1 x Remote Control 1 x 9.5V Mains adaptor 1 x 12V In-car adaptor Please Note: 3.5mm to RCA cables and replacement accessories are available to purchase at: www.quesh.co.uk Features • 10” digital screen •... -
Page 7: Controls
Controls 01. 02. 03. Setup DVD/USB/CARD MODE Rewind Fast Forward Skip Back Skip Forward Play/Pause Menu/PCB Right, Vol+ Down Left, Vol- Audio Mute Open DC Power Port On/Off Switch AV In AV Out Headphone Port SD/MMC Card Slot USB Port After Sales Support UK/N.IRELAND HELPLINE N 01270 508538... -
Page 8: Remote Control
Remote Control SLOW NUMBER KEY Battery Installation/removal Please note: Battery type required is ‘CR2025’ After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk... -
Page 9: Key Functions
Key Functions The functions of each key are detailed below. The main function keys appear both on the remote control (RC) and the DVD player. Zoom To enlarge the picture (x2, x3, x4, x1/2, x1/3, x1/4) Mode DVD and external audio and video input conversion Number Key For inputting number digits Prev/Up... -
Page 10: Getting Started
Getting Started Basic DVD Operation • Before first time use, open the disc cover and carefully remove and discard the white cardboard dust cover from inside the deck marked “Warning: Please take out this card before playing”. • Remove all transparent protection from the DVD player. •... -
Page 11: Charging The Dvd Player
Charging the DVD Player Connect either adaptor to charge the unit via the ‘DC IN’ port. This will take approximately 6 hours to fully charge. A red LED will indicate that it is charging or in need of charging if it’s not connected to an adaptor. -
Page 12: Setup
System Setup Setup Press SETUP on the remote control or DVD player to enter the Setup Menu. Here you will find the following options: General Setup, Audio Setup, Dolby Digital Setup, Video Setup and Preference Page. You can navigate through the menus with the arrow buttons and select an option with the ‘OK’... -
Page 13: General Setup Options
System Setup General Setup Options TV Display Normal/PS (4:3 Pan & Scan) Normal/LB (4:3 16:9 Letterbox) Wide (16:9, 1.78:1) Change the aspect ratio of the video to see subtitles in full. Angle Mark Activate the option of multiple camera angles where available. OSD Lang English French... -
Page 14: Audio Setup Page
System Setup Audio Setup Page Select ‘Speaker Setup’ to access a further submenu. Downmix LT/RT Stereo The default setting is ‘Stereo’. Change this to ‘LT/RT’ (Left Total, Right Total) to compress the front, back and centre channels to stereo if the video is only available in surround sound and your experiencing missing or quiet audio. -
Page 15: Video Setup Page
System Setup Video Setup Page Select ‘Panel Quality’ to access a further submenu. Sharpness High Medium Change the digital sharpness of the image displayed on screen. Brightness -18 to +18 Control the brightness level of the screen. Contrast -16 to +16 Adjust the digital depth of shadows and highlights of the image displayed on screen. -
Page 16: Preference Page
System Setup Preference Page This menu is only available if there is no DVD in the player. TV Type AUTO NTSC This option control the signal output for when you are connecting to a specific type of display or TV (PAL = UK, NTSC = US). Audio, Subtitle, Disc Menu English French... - Page 17 System Setup Parental 1 KID SAFE 3 PG 4 PG 13 5 PGR 7 NC17 8 ADULT Set a video censorship rating limit to what DVD can be played through the system. Password Select ‘Password’ to access a further submenu. Password Mode This option will allow you to turn on or off the password.
-
Page 18: Connecting A Device (Av In)
Connecting a Device (AV IN) You can connect other devices to display on the DVD player via the ‘AV IN’ port. Connect the 3.5mm to RCA lead into the ‘AV IN’ port and the RCA end to the device you want to show on the screen such as a video camera. -
Page 19: Trouble Shooting
Trouble Shooting Adaptor Care In the unlikely situation of the In-car Adaptor failing to power the DVD player, please unscrew the connector cap and examine the fuse to see if it needs replacing. Body F3AL250V Fuse Connector Cap The F3AL250V fuse is available at all good automotive stores. •... -
Page 20: Resetting The Disc Reader
Trouble Shooting Resetting the Disc Reader Sometimes the DVD unit may take a bump and knock the alignment of the disc reader off it’s calibration. The DVD player will display either ‘LOADING’ for more than 10 seconds on the screen or ‘NO DISC’. Ribbon Data Cable DVD Spindle... -
Page 21: Unable To Connect To Tv
Trouble Shooting Unable to connect to TV If you are trying to connect the DVD player to an external screen and you are either getting sound and no picture or picture and poor sound you will be using an incorrect RCA cable. You will need a ‘4 pole 3.5mm to RCA cable’... - Page 22 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
-
Page 23: Warranty Card
Warranty Card 9” DVD Player with USB & SD Card Slot Model Number: 73848 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
