30" electric built-in single and double ovens
Table of Contents

Advertisement

Available languages

Available languages

Product dimensions

Single oven
28-3/8"
(72.1 cm) max.
recessed width
27-1/2"
(69.9 cm)
recessed
height
23"
29-3/4" (75.6 cm)
(58.4 cm)
overall width
max.
recessed

Cutout dimensions

30" (76.2 cm) min.
cabinet width
27-3/4"
(70.5 cm)
min.
cutout
height
28-1/2"
(72.4 cm)
cutout width
Single oven
undercounter
(without cooktop
installed above)
23-1/4"
(59.1 cm) min.
cutout depth
23" (58.4 cm)
recessed oven
depth
recessed
cabinet
oven
Cabinet side view
Cabinet filler kits are available from your dealer.
Use a matching color kit if oven is smaller than
your cabinet opening.
Single oven filler height is 3-5/16" (8.4 cm)
Black
— 4378941
White
— 4378942
Almond — 4378943
Double oven filler height is 6-5/16" (16 cm)
Black
— 4378947
White
— 4378948
Almond — 4378949
Page 1
(72.1 cm) max.
recessed width
29"
(73.7 cm)
max.
overall
height
49-1/2"
(125.7 cm)
recessed
height
23"
(58.4 cm)
max.
recessed
depth
1-1/2"
(3.8 cm) min.
top of cutout
to underside
of countertop
49-3/4"
(126.4 cm)
min.
cutout
height
5-1/4" (13.3 cm)
bottom of cutout
to floor
1-1/2" (3.8 cm)
min. bottom of
cutout to top of
cabinet door
oven
front
27-3/4"
(70.5 cm)
min.
cutout
height
1-1/2"
(3.8 cm)
min.
bottom of
cutout to
top of
cabinet
door
Double oven
28-3/8"
(129.5 cm)
29-3/4" (75.6 cm)
overall width
30" (76.2 cm)
min. cabinet
1" (2.5 cm) top
of cutout to
bottom of upper
cabinet door
28-1/2"
(72.4 cm)
cutout
width
14-3/4"
(37.5 cm)
bottom
of cutout
to floor
Double oven
30" (76.2 cm) min.
cabinet width
1" (2.5 cm) top
of cutout to
bottom of upper
cabinet door
28-1/2"
(72.4 cm)
cutout
width
32"
(81.3 cm)
bottom of
cutout to
floor
Single oven

Before you start...

Your safety and the safety of others are
very important.
We have provided many important safety
messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential
hazards that can kill or hurt you and
others.
All safety messages will follow the safety alert
51"
symbol and either the word "DANGER" or
"WARNING". These words mean:
max.
overall
DANGER
height
You can be killed or seriously injured if you
don't immediately follow instructions.
WARNING
You can be killed or seriously injured if you
don't follow instructions.
All safety messages will tell you what the
potential hazard is, tell you how to reduce the
chance of injury, and tell you what can happen if
the instructions are not followed.
Important: Observe all governing codes
and ordinances.
Proper installation is your responsibility.
Have a qualified technician install this oven.
Oven location should be away from strong
draft areas, such as windows, doors and
strong heating vents.
Cabinet opening dimensions that are shown
must be used. Given dimensions provide
minimum clearance.
Recessed installation area must provide
complete enclosure around the recessed
portion of the oven.
Electrical ground is required. See "Electrical
requirements."
Electrical supply junction box should be
located 3 inches (7.6 cm) maximum below the
support surface when oven is installed in a
wall cabinet. Drill a 1-inch minimum (2.5 cm)
diameter hole in the right rear or left rear
corner of the support surface to pass the
appliance cable through to the junction box.
For undercounter installation, it is
recommended that the junction box be
located in the adjacent right or left cabinet. If
installing the junction box on rear wall behind
oven, junction box must be recessed and
located in the upper or lower right or left
corner of cabinet.
It is the customer's responsibility:
To contact a qualified electrical installer.
To assure that the electrical installation is
adequate and in conformance with National
Electrical Code, ANSI/NFPA 70 — latest
latest edition*, or Canadian Electrical Code,
C22.1-1982 and C22.2 No. 01982 (or latest
edition)** and all local codes and
ordinances.
Copies of the standards listed may be obtained from:
* National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
** CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
Tool needed:

Parts supplied:

Phillips
screwdriver
4 screws (double oven)
