Summary of Contents for Empertech KB-C30PT
-
Page 3: Table Of Contents
Contents Features ..............................1 Functional components ........................2 Front Panel ............................2 Rear Panel ............................3 Operation ............................... 4 Equalizer Controls ..........................4 Manual Priority Terminals ......................... 4 Connectios ............................4 Microphone1 ..........................4 Balanced operation ........................4 Unbalanced operation ........................4 Microphone2 .......................... -
Page 4: Features
Features 2 microphone inputs; gain control for MIC 1, level adjustable from microphone to aux input One Aux / CD input, switchable Independent volume control for all the inputs, and master volume control With 6KHz, 1kHz, and 150Hz tone control ... -
Page 5: Functional Components
Functional components Front Panel 1. MIC1/TEL Volume 18.DIR-UP 2. MIC2 Volume 19.Back/Backward 3. AUX/CD/MP3/FM Volume 20.Next/Forward 4. Bass 150Hz 21.Play/Pause 5. Middle 1KHz 22.Stop 6. Treble 6KHz 23.LCD Display 7. Master Volume 8. Signal LED 9. -10dB LED 10. Power Switch 11. -
Page 6: Rear Panel
Rear Panel 1. Appliance inlet 2. Fuse used in inlet 3. Ground screw 4. Manual Priority terminals 5. Speakers output terminals 6. AUX Input 7. CD Input 8. AUX/CD Selector Switch 9. AUX Music on Hold Volume Control 10. MIC2 Input-unbalanced 11. -
Page 7: Operation
Operation Equal ntrols izer Co Three different controls for three frequency bands. Those volume controls will increase or decrease bass and treble or add some presence to the sound. Manual Priority Terminals These two terminals, when shorted, will mute incoming signal from AUX and CD inputs, thus giving priority to the Telephone Paging and Microphone. -
Page 8: Microphone2
Microphone2 Mic2 input is a Unbalanced standard 1/4〃mono jack on the rear panel . Wiring is as follows AUX/CD Connection AUX/CD input is two phono sockets .These inputs are configured as AUX Or CD inputs MP3 /TUNER Selection The built-in MP3 /TUNER can work proper when switching to CD,MP3,Tuner on rear panel. -
Page 9: Manual Priority Terminals
Manual Priority Terminals These two terminals, when shorted, will mute incoming signal from AUX and CD inputs, thus giving priority to the Telephone Paging and Microphone. These are especially useful when a table microphone with switch is part of the installation. Speaker Terminals These terminals are offering 3 low voltage outputs 4Ω, 8Ω, 16Ω... -
Page 10: Music On Hold
Music on Hold This output will feed music on your telephone system for people waiting to be answered. A dedicated input should be available on your telephone system. Please refer to a qualified technician if you can’t identify this input. Outgoing signal should be connected to G and H. Volume control is located next to the terminal in order to provided proper level of music on the phone system. -
Page 11: Specifications
Specifications Model KB-C30PT KB-C60PT Parameter Output Power Fuse T1AL 250V T1.6AL 250V THD at Rated Power <2.5% 4Ω, 8Ω, 16Ω, 70V/100 V( 70V/100V choose 1 of these 2 ) Speaker Outputs 100Hz – 20 kHz Frequency Response 3mV @ 600 Ω... -
Page 12: Block Diagram
Block Diagram...
