Items
Dimensions ( W × H × D )
Mass
Power Input
Power Consumption
TV RF System
Colour System
Stereo System
Receiving Frequency
Intermediate
Frequency
Colour Sub
Carrier Frequency
Teletext System
LCD panel
Screen Size
Display Pixels
Audio Power Output
Speaker
Aerial terminal (VHF/UHF)
EXT-1 / EXT-2 (Input / Output)
EXT-3(Input)
EXT-4 (Input)
PC (RGB) Input
PC AUDIO input
Audio output
Subwoofer output
Headphone
Remote Control Unit
Design & specifications are subject to change without notice.
1-2 (No.YA221)
SPECIFICATION
61.4cm × 48.2cm × 24.0cm [Included stand]
61.4cm × 43.8cm × 7.9cm [TV only]
7.4kg [Included stand]
6.4kg [TV only]
AC100 to AC240 V, 50 Hz
108W (Standby: 3.0W)
Analog CCIR (B/G, I, D/K, L)
Digital DVB-T
PAL, SECAM, NTSC 3.58/4.43 [EXT only]
NICAM (B/G, I, D/K, L), A2 (B/G, D/K)
Analog VHF: 47 MHz - 470 MHz
UHF: 470 MHz - 862 MHz
Digital UHF: 474 MHz - 858 MHz
CATV 68 MHz - 174 MHz, 230 MHz - 470 MHz
VIF 38.9 MHz (B/G, I, D/K, L)
SIF 33.4 MHz (5.5 MHz: B/G)
32.9 MHz (6.0 MHz: I)
32.4 MHz (6.5 MHz: D/K, L)
PAL 4.43 MHz
SECAM 4.40625 MHz / 4.25MHz
NTSC 3.58 MHz / 4.43 MHz
Analog TOP, FLOF (Fastext level 2.5), WST(World Standard system)
Digital MHEG 5 UK profile
23V-inch wide aspect (16:9)
Diagonal : 58.3cm (H:50.8cm × V : 28.6cm)
Horizontal : 1366 dots × Vertical : 768 dots (W-XGA)
5W + 5W(10% THD)
3.4cm × 14.5cm oval type × 2
EU-type connector, 75Ω unbalanced, coaxial
21-pin Euro connector (SCART socket ) × 2
RCA pin jack × 3
Component Video
Y : 1V (p-p), Positive (Negative sync provided), 75 Ω
625p / 525p / 625i / 525i
Cb/Cr : 0.7V(p-p), 75 Ω
500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
Audio
Mini-DIN 4 pin × 1
S-Video
Y: 1V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286V (p-p) (Burst signal), 75 Ω
1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
Video
500mV (rms), High impedance, RCA pin jack × 2
Audio
D-sub 15pin × 1
R/G/B : 0.7V (p-p), 75Ω
HD / VD : 1V (p-p) to 5V (p-p), high impedance
< Available signal >
Horizontal : 30kHz - 69kHz
Vertical : 50Hz - 75Hz
[Resolution : 640 pixels × 400 pixels, 640 pixels × 480 pixels(VGA), 720 pixels
× 400 pixels, 800 pixels × 600 pixels(SVGA), 1024 pixels × 768 pixels(XGA),
1280 pixels × 720 pixels, 1360 pixels × 768 pixels(W-XGA)]
3.5mm stereo mini jack × 1
500mV (rms), Low impedance, RCA pin jack × 2
More than 0 to 1000mV (rms) (+2.2dBs), low impedance (80Hz when modulated
100%), RCA pin jack × 1
3.5mm stereo mini jack × 1
RM-C1895 (AA/R6 dry cell battery × 2)
