Attract EMT-1040 Maintenance Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EMT-1040
Common Trouble and processing Methods are listed as follow:
Serial NO.
Phenomenon
No Function
01
When Starting.
No function when
02
starting.
No Width
03
switchover.
Maintenance Service Manual
I. Trouble catalog
Description
The LCD isn't illuminating:
①Fuse melts (in the Power Source Box or
on the main PCB).
②Power supply circuit poorly connected.
③EMC Board fails.
④main PCB fails.
The LCD is illuminating：
①Mechanical switch fails or it's wire is
opened.
②Up or Down Stroke Photoelectricity
fails.
③Main PCB fails.
④Kneading is on without pressing any
key when starting and no response by
pressing other keys.
①The terminals of Width Inspection on
main PCB and wires are poorly connected.
②The terminals of Width Inspection on
massage mechanical and wires are poorly
connected.
③Width Inspection fails.
④Main PCB fails.
1
Maintenance Methods
① Replace Fuse.
② Replace Power Box.
③ Replace EMC Board.
④Replace main PCB.
①Replace mechanical switch or it's
wire.
②Replace Stroke Photoelecruicity.
③Replace the main PCB.
④Width Inspection Board of PCB
fails, replace it.
①&②Plug the terminal securely or
replace the wires.
③Replace Width Inspection.
④Replace the main PCB.
