3. Appearance of Smart R-400 Necklace hole Top side Tag Read Indicator Right side Power button Battery Status LED, RFID Ant Position Low-battery LED Power LED Bluetooth LED Left side Brand logo Battery Position Customizable Left side Reset button Bottom/Micro USB Page ...
4. Description Power ON/OFF Press more than 2 second, power ON/OFF Charge Description and Alarmed lack of Bettary LED Red light on during battery charging, Green light on after Full Charged, Lack of battery when the blinking Red lights. Power ON Display and RFID reading Display process When power ON, Green light ON.
6. How to use on PC (BT Mode) ☞ Demo Application File Name. - Reader@Express V3.6.3 for Windows.zip ☞ Operating System - Window 7 32bit Page 8...
Page 9
Windows 7 (32bit) 1. Smart R-400 Device ON 2. Control Panel > Device and Printer > Additional device > Choose the “Blue Angel” or “SmarTerminal” Device Page 9...
Page 10
Windows 7 (32bit) 3. Pin Number is “0000” 4. Check the connection with Bluetooth Page 10...
Page 11
Windows 7 (32bit) 5. Check the Port Number (Will need it) Page 11...
Page 12
Windows 7 (32bit) 6. Run the “Reader@Express V3.6.3 for Windows” Page 12...
Page 13
Windows 7 (32bit) 6. Choose the Port Number ( 7. Set up USB Mode (in COM port box) The Top of the Left ), Confirm the RFID activation. side Play “reader program” Check the USB Box. And reset R400 device and program. Page ...
Page 14
Windows 7 (32bit) Caution – Set POWER level less than 27 from Combo box and use. – Please do not assign USB COMport number over comport # 10, the application many not recognize the device if comport number is over 10. (11,12,13,ete..) –...
7. How to use on Android (BT Mode) ☞ Demo Application File Name. - 9.4.4 Android(Bluetooth) Host Library SDK for Impinj.zip ☞ Operating System - Android Page 15...
Page 16
Android • This Application is not on the Android Market because it’s SDK sample program for developer. User can install it from PC by following instruction. 2. Prepare your Android Smart phone and its USB data 1. Smart R-400 Device ON cable.
Page 17
Android 3. Connect your Smart Phone to 4. Makes “APK” Folder in the Android phone folder, PC thru data cable added ‘ReaderApiBlueDemo.apk’. Page 17...
8. How to change USB mode (from BT Mode) IndyTool v2.4.2. Please install (To use USB Mode, please find attached file and install USB driver) Indytool After installation of on your computer is completed, please execute a program. Connecting to Host device, SM-R400 can set-up Bluetooth Mode or USB Mode. You can update Firmware only USB Mode. Please change to USB mode refer to as below because SM-R400 basically support Bluetooth mode.
Page 22
8. How to change USB mode (from BT Mode) To change USB Mode, please click on “Register Access” tab. Switch option Mac > OEM Please change Write Address 0 > A0 (on Write option) Please put “0” in Data Window and Click on Write button. (If you want to change B/T Mode, put “0”...
8. How to change USB mode (from BT Mode) If you complete setting, please restart SM-R400 unit. (Press the button at least 2 seconds.) Also please shut down IndyTool program to click on “Disconnect” button. To connect SM-R400 and your computer thru USB cable and turn on SM-R400. After turn on R400 and play the IndyTool program.
2. Double click on the BT ICON to run Bluetooth ICON displays at the tray icon. Devices search engine. 3. Check mark on ‘My device is set up and ready to 4. Double click on SmarTerminal be found.’ and hit next. Page 24...
9. Using IndyTool (BT Mode or USB Mode operation.) 5. Input ‘0000’ for Passkey and hit next 6. Outgoing Com Port is now set 7. IndyTool(RFID APP) uses Outgoing Com Port 8. When checking the Com Port for this terminal from device m anager, Com6 is set as Sierra NMEA Port, so it requires B T device Outgoing Port to change another port that is 1 di git.
9. Using IndyTool (BT Mode or USB Mode operation.) 9. Double click on BT Outgoing COM6 from device manager. 10. Rerun the device manager or check the changed BT Outgoing Click ‘Advanced’ from Properties and change COM PORT to 9 COM 9 port 11.
9. Using IndyTool (BT Mode or USB Mode operation.) 13. When it connects properly, ‘connect success’ message will display. From 14. Type can be changed to OEM Register Access tab, BT mode and USB mode can be changed. 15. Under the Read, put ‘A0’ for Address and hit read. 16.
9. Using IndyTool (BT Mode or USB Mode operation.) 17. After the reset, it disconnects and R400 turns its power off 18. Plug the USB cable to T8 and turn the R400 on, the message ‘Found New Hardware R2000’ will display on the tray icon. 19.
9. Using IndyTool (BT Mode or USB Mode operation.) 22. Continue 21. Use the provided ImpinJi Driver from ‘Include this location in the search’ Check UsbHarve.sys for Impinj RFID MAC device installed in 23. Click Finish USB driver from Device Manager. Page ...
Page 30
9. Using IndyTool (BT Mode or USB Mode operation.) 25. Run IndyTool 2.4.2, click on the Connect button. On the top right, with ‘via USB message’ check the USB Mode connection and OEM A0 Read value is 00000000 Page 30...
10. Using IndyTool v2.4.2, Data write method in the TAG EPC 1. After the R400 operation, choose ‘Read’ for the Tag acc 2. For Tag Access, Write. For Memory Bank, set EPC, ess from the Tag Access tab. For Memory Bank, choose Offset as 2, Count as 1~6, Value as 1word (2Byte) for EPC, Offset 2, count 1~6.
Page 32
10. Using IndyTool v2.4.2, Data write method in the TAG EPC 3. Change the Tag Access as Read and hit Execute button, so that you can see the written Data from the right window screen. Page 32...
Resolve Error If you see this error sign Copy and Paste cpl.dll rest of the .dll files rfid.dll rfid.reader.api.dll rfid.reader.serial.port.dll rfidtx.dll Page 33...
