SPECIFICATION


1x USB-C 3.1 (Gen. 1) port, transfer rate up to 5 Gbps

3x USB-A 3.0 port, transfer rate up to 5 Gbps

1x USB-C Power Delivery with profile 4 (up to 20V/3A, max. 60 W)

1x Ethernet GLAN RJ-45 port, 10/100/1000 Mbps

1x SD Card Reader (Spec. SD 4.0)

Graphic interface: 1x HDMI, 4K Ultra HD with max. resolution 3840x2160 / 30Hz

Resolution: 640x480, 800x600, 1024x768, 1280x720, 1280x768, 1280x800, 1280x1024,
1360x768, 1366x768, 1368x768, 1400x1050, 1600x1200, 1680x1050, 1920x1080,
1920x1200, 2048x1152 2048x1280 2048x1536 2560x1440 2560x1600 3840x2160

Mode: Extend, Mirror and Primary Display

Supported colors 16 / 32 bit

Powered through USB bus

1x AC/DC 5V Power Jack - If you connect the other USB devices to the docking station the
devices will be will draw the power from your laptop directly. Anyway, if these devices
requires more than 900mA you can encounter some device will not work properly. If this
happens we recommend you to order an extra power adapter (U3FLATDOCKPD-ADA)

Chipset: VL100 & VL813 & PS176 & RTL8153 & RTS5327

OS: Requires USB-C interface with "DisplayPort Alternate Mode" and „Power Delivery"
support (not all devices / systems with USB-C interface supports the standard) or
Thunderbolt 3 port – Windows 10 32/64bit, Mac OS X, Chrome OS and Android 6 (Google)
with Intel Broadwell Processor and R51 and higher

Product dimensions: 280 x 70 x 22 mm

Product weight: 198 g
DESCRIPTION OF THE DOCKING STATION
Left panel:
1. USB-A 3.0 port – for connecting USB devices
Front panel:
2. Input for external power adapter – you can connect AC/DC 5V power adapter for charging
of connected USB devices
3. SD Card Reader
4. USB-C 3.1 port – for connecting USB-C devices
5. Ethernet GLAN RJ-45 port – for connecting to the Ethernet network / router / switch /
HUB and the internet
6. 2x USB-A 3.0 port – for connecting USB devices
7. HDMI port – for connecting a HDMI monitor
8. USB-C Power Delivery port – for charging notebooks, tablets or smartphones with support
for Power Delivery. To this port you can connect an original or a universal AC power
adapter with USB Type-C connector, it ensures the constant charging of your notebook,
tablet or smartphone during your work.
9. Connecting cable with USB-C connector – for connecting of Docking station to a
notebook, tablet, PC or smartphone with USB-C port
